Philco PTB 66 EMW User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REFRIGERATOR
USER'S MANUAL
PTB 66 EMW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTB 66 EMW and is the answer not in the manual?

Questions and answers

Related Manuals for Philco PTB 66 EMW

Summary of Contents for Philco PTB 66 EMW

  • Page 1 REFRIGERATOR USER’S MANUAL PTB 66 EMW...
  • Page 2 Dear customer, Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all the instructions in this user‘s manual. Icon Type Meaning WARNING Serious injury or death risk RISK OF ELECTRIC SHOCK Dangerous voltage risk FIRE Warning;...

  • Page 3: Table Of Contents

    CONTENTS PART 1: IMPORTANT SAFETY INSTRUCTIONS ....................2 PART 2: FOR EU STANDARD ..........................7 PART 3: ENVIRONMENTAL PROTECTION .......................8 PART 4: INSTALL INSTRUCTION ........................9 PART 5: DOOR RIGHT-LEFT CHANGE ......................11 PART 6: MOVING THE APPLIANCE ........................13 PART 7: LEVELING FEET ..........................13 PART 8: TIPS FOR SAVING ENERGY ......................13 PART 9: PRODUCT OVERVIEW ........................14 PART 10: OPERATION INSTRUCTIONS ......................15...

  • Page 4: Part 1: Important Safety Instructions

    PART 1: IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS WARNING: RISK OF FIRE / FLAMMABLE MATERIAL REFRIGERANT AND CYCLOPENTANE FOAMING MATERIAL USED FOR THE APPLIANCE ARE FLAMMABLE. THEREFORE, WHEN THE APPLIANCE IS SCRAPPED, IT SHALL BE KEPT AWAY FROM ANY FIRE SOURCE AND BE RECOVERED BY A SPECIAL RECOVERING COMPANY WITH CORRESPONDING QUALIFICATION OTHER THAN BE DISPOSED BY...
  • Page 5 WARNING: KEEP VENTILATION OPENINGS, IN THE APPLIANCE ENCLOSURE OR IN THE BUILT-IN STRUCTURE,CLEAR OF OBSTRUCTION. WARNING: DO NOT USE MECHANICAL DEVICES OR OTHER MEANS TO ACCELERATE THE DEFROSTING PROCESS, OTHER THAN THOSE RECOMMENDED BY THE MANUFACTURER. WARNING: DO NOT DAMAGE THE REFRIGERANT CIRCUIT. WARNING: DO NOT USE ELECTRICAL APPLIANCES INSIDE THE FOOD STORAGE COMPARTMENTS OF THE APPLIANCE, UNLESS THEY ARE OF THE TYPE RECOMMENDED BY THE...

  • Page 6: Daily Use

    FOR A FREESTANDING APPLIANCE: THIS REFRIGERATING APPLIANCE IS NOT INTENDED TO BE USED AS A BUILT-IN APPLIANCE. CAUTION Daily use DO NOT PULL THE POWER CORD WHEN PULLING THE POWER PLUG OF THE REFRIGERATOR. PLEASE FIRMLY GRASP THE PLUG AND PULL OUT IT FROM THE SOCKET DIRECTLY. TO ENSURE SAFE USE, DO NOT DAMAGE THE POWER CORD OR USE THE POWER CORD WHEN IT IS DAMAGED OR WORN.
  • Page 7 THE GAPS BETWEEN REFRIGERATOR DOORS AND BETWEEN DOORS AND REFRIGERATOR BODY ARE SMALL, BE NOTED NOT TO PUT YOUR HAND IN THESE AREAS TO PREVENT FROM SQUEEZING THE FINGER. PLEASE BE GENTLE WHEN CLOSE THE REFRIGERATOR DOOR TO AVOID FALLING ARTICLES. DO NOT PICK FOODS OR CONTAINERS WITH WET HANDS IN THE FREEZING CHAMBER WHEN THE REFRIGERATOR IS RUNNING, ESPECIALLY METAL CONTAINERS IN ORDER TO...
  • Page 8 DO NOT STORE BEER, BEVERAGE OR OTHER FLUID CONTAINED IN BOTTLES OR ENCLOSED CONTAINERS IN THE FREEZING CHAMBER OF THE REFRIGERATOR; OR OTHERWISE THE BOTTLES OR ENCLOSED CONTAINERS MAY CRACK DUE TO FREEZING TO CAUSE DAMAGES. WARNING CONNECT TO POTABLE WATER SUPPLY ONLY. (SUITABLE FOR ICE CUBE MAKER) (*) TO PREVENT CHILDREN FROM BEING ENTRAPPED, THE KEYS MUST BE KEEP OUT OF REACH OF CHILDREN AND NOT IN THE...

  • Page 9: Part 2: For Eu Standard

    PART 2: FOR EU STANDARD This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

  • Page 10: Part 3: Environmental Protection

    WARNING Risk of child entrapment. Before you throw away your old refrigerator or freezer: 1. Take off the doors. 2. Leave the shelves in place so that children may not easily climb inside. PART 3: ENVIRONMENTAL PROTECTION Disposing of old electrical devices in an environmentally-friendly manner This crossed-out wheeled bin symbol indicates that waste electrical and electronic products (WEEE) should be disposed of separately from the municipal waste stream.

  • Page 11: Part 4: Install Instruction

    PART 4: INSTALL INSTRUCTION Before first use Remove the exterior and interior packing, wipe the outside thoroughly with a soft dry cloth and the inside with a wet, lukewarm cloth. Avoid placing the cabinet in a narrow recess or near any heat source, direct sunlight, or moisture. Too small of a distance from adjacent items may result in the degradation of freezing capability and increased electricity costs.
  • Page 12 Connecting the appliance After installing the product, please let it stay for more than 2 hours before turning on the power, otherwise it will lead to a decrease in cooling capacity or a damage to the product. Allow the appliance to run empty for 24 hours so the compartment can cool to the appropriate temperature. CAUTION The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the rating plate.

  • Page 13: Part 5: Door Right-Left Change

    PART 5: DOOR RIGHT-LEFT CHANGE List of tools to be provided by the user Cross screwdriver Thin-blade screwdriver Masking tape 1. Fix the door by tapes. 2. Dismantle hole caps, the upper hinge cover, fitting screws of upper hinge, and remove the upper hinge, please keep the door vertical in whole process for avoiding falling down.
  • Page 14 4. Remove the lower hinge assembly and levelling foot. Lower hinge assembly Leveling foot 5. Install the lower hinge and levelling foot on lower left side of cabinet and lower right side respectively. Leveling foot Lower hinge assembly 6. Put the door on lower hinge vertically, and validate the gas tightness of door gasket, then install the upper hinge by fitting screws and the hinge cover, finally cover the hole caps on upper right side.

  • Page 15: Part 6: Moving The Appliance

    PART 6: MOVING THE APPLIANCE 1. Remove all items from the appliance. 2. Pull the power plug out, insert and fix it into the power plug hook at the rear or on top of the appliance. 3. Tape parts such as shelves and the door to prevent from falling off while moving the appliance. 4.

  • Page 16: Part 9: Product Overview

    PART 9: PRODUCT OVERVIEW Parts and functions 1 Thermostat knob 2 Small door 3 Drain tray 4 Shelf 5 Fence ice cube box on the position supplied by manufacturer. Otherwise, it will cause problems such the performance and life of the appliance are reduced. And the manufacturer does not provide basic appliance warrant.

  • Page 17: Part 10: Operation Instructions

    PART 10: OPERATION INSTRUCTIONS Use and functions OFF”: UnitOff MIN”: Less Cool Temperature MED”: Normal Operation(adequate for most situations) MAX”: Coolest Temperature During high ambient temperatures e.g. on hot summer days. It may be necessary to set the thermostat to the Coolest setting(position“MAX”).This may cause the compressor running continuously in order to maintain a low temperature in the cabinet.

  • Page 18: Part 11: Storing Food

    PART 11: STORING FOOD Cooling compartment To reduce moisture and subsequent ice build-up, never put liquid into the fridge compartment in unsealed containers. Frost tends to concentrate in the coolest parts of the evaporator. Storing uncovered liquids results in a more frequent need for defrosting. Never put warm foods in the fridge compartment.

  • Page 19: Part 12: Maintenance And Cleaning

    PART 12: MAINTENANCE AND CLEANING CAUTION Disconnect the appliance from the electrical supply before undertaking any routine maintenance. Allow at least 5 minutes before restarting the appliance, as frequent starting may damage the compressor. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
  • Page 20 Defrosting 1. Power off the refrigerator. 2. Remove the food from the refrigerator and place it properly to prevent food from melting. 3. Clear the drain pipe (to use soft materials to prevent damage to the liner), Prepare the water containers for defrosting.

  • Page 21: Part 13: Troubleshooting

    PART 13: TROUBLESHOOTING The following simple issues can be handled by the user. Please call the after-sale service department if the issues are not solved. Problem Possible Causes Solution Not operate and the plug is not firmly inserted. the circuit tripped. Compressor working for a long time long working time.
  • Page 22 Certain sounds can be heard during normal use of the refrigerator, which do not affect its correct operation. Sounds, which can be easily prevented: feet. Alternatively, place pads made of soft material under the rear rollers, especially when the appliance is placed on tiles.

  • Page 23: Part 14: Product Information Sheet

    Product Information Sheet COMMISSION DELEGATED REGULATION (EU) 2019/2016 with regard to energy labelling of refrigerating appliances Supplier's name or trademark: PHILCO Supplier's address: PHILCO, U Sanitasu 1621, 25101 Říčany, CZ Model identifier: PTB 66 EMW Type of refrigerating appliance: Low-noise appliance:...
  • Page 24 Minimum duration of the guarantee offered by the manufacturer: 24 months Additional information: Weblink to the manufacturer's website, where the information in point 4(a) Annex of Commission Regulation (EU) 2019/2019 is found: www.philco.cz EN - 22 Copyright © 2025, Fast ČR, a. s.

  • Page 25: Technical Information

    When contacting our authorized service, have the model designation, serial number and defect description available. To download documents, visit www.philco.cz. To report a defect and obtain additional service information, visit https://philco.cz/podpora-a-servis. Subject to change without notice. EN - 23 Copyright © 2025, Fast ČR, a. s.

  • Page 26: Instructions And Information Regarding The Disposal Of Used Packaging Materials

    INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS Dispose of packaging material at a public waste disposal site. DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste.
  • Page 27 NOTES/POZNÁMKY/NOTATKI/MEGJEGYZÉS...
  • Page 28 Výrobce/Manufacturer: Fast ČR, a.s. U Sanitasu 1621 Říčany 251 01, CZECH REPUBLIC Distributor: FAST PLUS, a.s. Vlčie hrdlo 324/90 821 07 Bratislava, SLOVAKIA Distributor: FAST POLAND Sp. z o. o. Kwietniowa 36 05-090 Wypędy, POLAND Distributor: FAST HUNGARY Kft. H-2310 Szigetszentmiklós Kántor utca 10, HUNGARY is pending or registered trademark of Electrolux Home EN - 1...
