Precision 130
Cutting Process Charts
Art# H-0071
Revision:
Issue Date:
Manual No.:
AB
01 August, 2024
0-5697
Thermal-Dynamics.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Precision 130 and is the answer not in the manual?

Questions and answers

Related Manuals for Thermal Dynamics Precision 130

Summary of Contents for Thermal Dynamics Precision 130

  • Page 1 ® Precision 130 Cutting Process Charts Art# H-0071 Revision: Issue Date: Manual No.: 01 August, 2024 0-5697 Thermal-Dynamics.com...
  • Page 2 ® WE APPRECIATE YOUR BUSINESS! Congratulations on your new Thermal Dynamics product. We are proud to have you as our customer and will strive to provide you with the best service and reliability in the industry. This product is backed by our extensive warranty and world-wide service network. To locate your nearest distributor visit us on the web at www.thermal-dynamics.com.
  • Page 3 Read and understand this entire Manual and your employer’s safety practices before installing, operating, or servicing the equipment. While the information contained in this Manual represents the Manufacturer’s best judgment, the Manufacturer assumes no liability for its use. Precision 130 Distributor Cutting Process No. 0-5697 Published by: Thermal Dynamics Corporation.
  • Page 4 This Page Intentionally Blank.
  • Page 5 TABLE OF CONTENTS TORCH OPERATION ........................7 Torch Parts Selection ..........................7 Pre-Setting Power Supply Controls ....................7 Recommended Cutting Speeds .......................7 1.01 Dry Cutting Mild Steel 30-130 Amp ................13 1.02 Dry Cutting Stainless Steel 30-130 Amp ..............23 1.03 Dry Cutting Aluminum 30-130 Amp ................35 APPENDIX 1: TORCH .......................46 Appendix 1.01 Torch Consumables Charts ................
  • Page 6 This Page Intentionally Blank...
  • Page 7 TORCH OPERATION Torch Parts Selection The application will determine which torch parts must be used. Refer to the cut charts for the proper torch parts to install for a selected application. NOTE! Do not interchange parts. Make sure all torch parts correspond with the plasma and shield gases in use for the application.
  • Page 8 Materials used to create cut charts NOTE! For all cut charts, the following materials were used: • A36 for Mild Steel • 6061 for Aluminum • 304 for Stainless Steel With other variations of materials, the cut parameters can change slightly. DANGER Hydrogen Detonation is Possible When Cutting Aluminum in or Under Water DO NOT cut aluminum alloys that contain lithium, in underwater applications or where water is involved (like with a water...
  • Page 9 Direction of Cut The plasma gas stream swirls as it leaves the torch to maintain a stable arc column. This swirl effect results in one side of a cut being more square than the other. Viewed along the direction of travel, the right side of the cut is more square than the left. Clockwise Left Side Cut Angle...
  • Page 10 Bevel Cutting Definitions Bevel Angle The angle between the center line of the torch and a line that is perpendicular to the workpiece. If the torch is perpendicular to the workpiece, the Bevel Angle is zero. The maximum Bevel Angle is 45°.
  • Page 11 Torch Height Control (THC) WITH Elevation Height Elevation Height Measured from Ignition Height Piercing Moving the Plate Over Pierce Work Puddle Height Delay Before Main Torch Height Controlled Arc Voltage Control with Main Arc Voltage Initial Height Sense Piercing Time Transfer Detected Lead-in...
  • Page 12 This Page Intentionally Blank TORCH DATA for P130 0-5697...
  • Page 13 1.01 Dry Cutting Mild Steel 30-130 Amp Flow Rates (SLPM / SCFH) Mild Steel Preflow 4 / 8 16 / 33 Cutflow 15 / 32 O₂ Plasma / O₂ Shield Art # A-14889 Plasma Gas Shield Cup Shield Cap Electrode Cartridge Shield Gas Distributor Distributor...
  • Page 14 Flow Rates (SLPM / SCFH) Mild Steel Preflow 30 / 63 Cutflow 6 / 14 12 / 26 O₂ Plasma / Air Shield Art # A-14890 Plasma Gas Shield Cup Shield Cap Electrode Cartridge Shield Gas Distributor Distributor 22-1016 22-1025 22-1272 22-1051 22-1041...
  • Page 15 Flow Rates (SLPM / SCFH) Mild Steel Preflow 30 / 63 Cutflow 6 / 14 12 / 26 Air / Air Art # A-14890 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode Cartridge Distributor 21-1016 21-1025 21-1272 21-1051 21-1041 21-1069 21-1020...
  • Page 16 Flow Rates (SLPM / SCFH) Mild Steel Preflow 44 / 94 Cutflow 10 / 21 25 / 52 O₂ Plasma / Air Shield Art # A-14891 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode Cartridge Distributor 22-1016 22-1026 22-1272 22-1152 22-1041...
  • Page 17 Flow Rates (SLPM / SCFH) Mild Steel Preflow 38 / 81 100A Straight Cutflow 16 / 35 27 / 58 O₂ Plasma / Air Shield Art # A-14892 Plasma Gas Shield Gas Shield Cup Shield Cap Electrode Cartridge Distributor Distributor 22-1016 22-1027 22-1272...
  • Page 18 Flow Rates (SLPM / SCFH) Mild Steel Preflow 38 / 81 100A Bevel Cut Cutflow 16 / 35 27 / 58 O₂ Plasma / Air Shield Art # A-15191 Shield Gas Plasma Gas Shield Cup Shield Cap Electrode / Tube Cartridge Distributor Distributor...
  • Page 19 Flow Rates (SLPM / SCFH) Mild Steel Preflow 46 / 97 130A Cutflow 17 / 36 26 / 55 O₂ Plasma / Air Shield Art # A-14893 Plasma Gas Shield Gas Shield Cup Shield Cap Electrode Cartridge Distributor Distributor 22-1016 22-1032 22-1287 22-1100...
  • Page 20 Flow Rates (SLPM / SCFH) Mild Steel Preflow 46 / 97 130A Cutflow 17 / 36 26 / 55 Air / Air Art # A-14893 Plasma Gas Shield Gas Shield Cup Shield Cap Electrode Cartridge Distributor Distributor 21-1016 21-1032 21-1287 21-1100 21-1041 21-1099...
  • Page 21 Flow Rates (SLPM / SCFH) Chart is for Customer Settings Preflow Make Copies as Desired Cutflow Plasma Gas Shield Cup Shield Cap Electrode Cartridge Shield Gas Distributor Distributor Gas Control Torch Height Control (THC) CNC Control Max Kerf Thick- Pilot/ Pierce Elevation Control...
  • Page 22 This Page Intentionally Blank TORCH DATA for P130 0-5697...
  • Page 23 1.02 Dry Cutting Stainless Steel 30-130 Amp Flow Rates (SLPM / SCFH) Stainless Steel Preflow 22 / 47 Cutflow 40/ 85 Air Plasma / Air Shield Art # A-14901 Plasma Gas Shield Cup Shield Cap Electrode Cartridge Shield Gas Distributor Distributor 22-1016 22-1033...
  • Page 24 Flow Rates (SLPM / SCFH) Stainless Steel H₂O (GPH N₂ (SLPM / SCFH) / LPH) Preflow 9 / 19 5 / 19 Cutflow 28 / 59 5/ 19 N2 Plasma / H₂O Shield Art # A-14902 Plasma Gas Shield Gas Shield Cup Shield Cap Electrode...
  • Page 25 Flow Rates (SLPM / SCFH) Stainless Steel Preflow 60 / 127 Cutflow 49 / 104 Air Plasma / Air Shield Art # A-14903 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode Cartridge Distributor 22-1016 22-1034 22-1274 22-1060 22-1041 22-1078 22-1020 Gas Control...
  • Page 26 Flow Rates (SLPM / SCFH) Stainless Steel H₂O (GPH N₂ (SLPM / SCFH) / LPH) Preflow 17 / 37 4 / 15 Cutflow 18 / 38 4/ 15 N2 Plasma / H₂O Shield Art # A-14904 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode...
  • Page 27 Flow Rates (SLPM / SCFH) Stainless Steel Preflow 66 / 139 Cutflow 52 / 110 Air Plasma / Air Shield Art # A-14905 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode Cartridge Distributor 22-1016 22-1035 22-1274 22-1061 22-1041 22-1079 22-1020 Gas Control...
  • Page 28 Flow Rates (SLPM / SCFH) Stainless Steel H₂O (GPH / N₂ (SLPM / SCFH) LPH) Preflow 15 / 31 5 / 19 Cutflow 8 / 17 5/ 19 N2 Plasma / H₂O Shield Art # A-14907 Shield Plasma Gas Shield Cup Electrode Cartridge Shield Gas Distributor...
  • Page 29 Flow Rates (SLPM / SCFH) Stainless Steel N₂ 100A Preflow - / - 62 / 132 Cutflow 24 / 51 51 / 107 H35 Plasma / N₂ Shield Art # A-14907 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode Cartridge Distributor...
  • Page 30 Flow Rates (SLPM / SCFH) Stainless Steel H₂O (GPH N₂ (SLPM / SCFH) / LPH) Preflow 17 / 35 7 / 26 100A Cutflow 14 / 29 7/ 26 N2 Plasma / H₂O Shield Art # A-14908 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode...
  • Page 31 Flow Rates (SLPM / SCFH) Stainless Steel N₂ 130A Preflow - / - 43 / 90 Cutflow 45 / 90 26 / 55 H35 Plasma / N₂ Shield Art # A-14909 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode Cartridge Distributor...
  • Page 32 Flow Rates (SLPM / SCFH) Stainless Steel H₂O (GPH N₂ (SLPM / SCFH) / LPH) Preflow 17 / 35 7 / 28 130A Cutflow 20 / 42 7 / 28 N2 Plasma / H₂O Shield Art # A-14910 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor...
  • Page 33 Flow Rates (SLPM / SCFH) Chart is for Customer Settings Preflow Make Copies as Desired Cutflow Shield Gas Plasma Gas Shield Cup Shield Cap Electrode Cartridge Distributor Distributor Gas Control Torch Height Control (THC) CNC Control Max Kerf Thick- Pilot/ Shield Pierce Elevation...
  • Page 34 This Page Intentionally Blank TORCH DATA for P130 0-5697...
  • Page 35 1.03 Dry Cutting Aluminum 30-130 Amp Flow Rates (SLPM / SCFH) Aluminum Preflow 19 / 40 Cutflow 40 / 85 Air Plasma / Air Shield Art # A-14919 Shield Plasma Gas Shield Cup Electrode Cartridge Shield Gas Distributor Distributor 22-1016 22-1033 22-1274 22-1059...
  • Page 36 Flow Rates (SLPM / SCFH) Aluminum H₂O (GPH / N₂ (SLPM / SCFH) LPH) Preflow 9 / 19 4 / 15 Cutflow 21 / 44 4 / 15 N2 Plasma / H₂O Shield Art # A-14920 Plasma Gas Shield Gas Shield Cup Shield Cap Electrode...
  • Page 37 Flow Rates (SLPM / SCFH) Aluminum Preflow 60 / 128 Cutflow 50 / 106 Air Plasma / Air Shield Art # A-14921 Plasma Gas Shield Gas Shield Cup Shield Cap Electrode Cartridge Distributor Distributor 22-1016 22-1034 22-1274 22-1060 22-1041 22-1078 22-1020 Gas Control Torch Height Control (THC)
  • Page 38 Flow Rates (SLPM / SCFH) Aluminum H₂O (GPH / N₂ (SLPM / SCFH) LPH) Preflow 26 / 56 4 / 15 Cutflow 18 / 38 4 / 15 N2 Plasma / H₂O Shield Art # A-14922 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode...
  • Page 39 Aluminum Flow Rates (SLPM / SCFH) Preflow 66 / 139 Cutflow 52 / 110 Air Plasma / Air Shield Art # A-14923 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode Cartridge Distributor 22-1016 22-1035 22-1274 22-1061 22-1041 22-1079 22-1020 Gas Control Torch Height Control (THC)
  • Page 40 Flow Rates (SLPM / SCFH) Aluminum H₂O (GPH / N₂ (SLPM / SCFH) LPH) Preflow 15 / 31 5 / 19 Cutflow 8 / 17 5 / 19 N2 Plasma / H₂O Shield Art # A-14924 Plasma Gas Shield Gas Shield Cup Shield Cap Electrode...
  • Page 41 Flow Rates (SLPM / SCFH) Aluminum N₂ Preflow - / - 62 / 132 100A Cutflow 24 / 51 51 / 107 H35 Plasma / N₂ Shield Art # A-14925 Plasma Gas Shield Cup Shield Cap Electrode Cartridge Shield Gas Distributor Distributor 22-1016 22-1036...
  • Page 42 Flow Rates (SLPM / SCFH) Aluminum H₂O (GPH N₂ (SLPM / SCFH) / LPH) Preflow 17 / 35 7 / 26 100A Cutflow 14 / 29 7 / 26 N2 Plasma / H₂O Shield Art # A-14926 Plasma Gas Shield Gas Shield Cup Shield Cap Electrode...
  • Page 43 Flow Rates (SLPM / SCFH) Aluminum N₂ 130A Preflow - / - 43 / 90 Cutflow 45 / 95 26 / 55 H35 Plasma / N₂ Shield Art # A-14927 Plasma Gas Shield Cup Shield Cap Shield Gas Distributor Electrode Cartridge Distributor 22-1016...
  • Page 44 Flow Rates (SLPM / SCFH) Aluminum H₂O (GPH N₂ (SLPM / SCFH) / LPH) 130A Preflow 17 / 35 7 / 28 Cutflow 20 / 42 7 / 28 N2 Plasma / H₂O Shield Art # A-14928 Plasma Gas Shield Gas Shield Cup Shield Cap Electrode...
  • Page 45 Flow Rates (SLPM / SCFH) Chart is for Customer Settings Preflow Make Copies as Desired Cutflow Plasma Gas Shield Gas Shield Cup Shield Cap Electrode Cartridge Distributor Distributor Gas Control Torch Height Control (THC) CNC Control Max Kerf Thick- Pilot/ Shield Pierce Elevation...
  • Page 46 This Page Intentionally Blank TORCH DATA for P130 0-5697...
  • Page 47 Appendix 1: Torch Appendix 1.01 Torch Consumables Charts 0-5697 TORCH DATA for P130...
  • Page 48 Appendix 1.02 Torch Assembly Parts List Returns If a product must be returned for service, contact your authorized distributor. Materials returned without proper authoriza- tion will not be accepted. Ordering Information Order replacement parts by catalog number and complete description of the part or assembly. Also include the model and serial number of the machine or torch.
  • Page 49 Consumables O-Rings (up to 150 Amps) Shield Cap Tips Up to 100 Amps Electrode O-Ring 9-9039 O-Ring 9-9035 O-Ring 9-9061 O-Ring 9-9060 150 Amp Tip O-Ring 9-9038 O-Ring 9-9060 Art # A-07161_AD Consumable Assembly Video Links 30-130A MS, 30-130A SS and AL https://www.youtube.com/watch?v=JLkgjJ8F5eE 100A bevel parts https://www.youtube.com/watch?v=5Se_YOX3DGM...
  • Page 50 Appendix 1.03 Torch Consumables Installation WARNINGS Do not install consumables into the Cartridge while the Cartridge is attached to the Torch Head. Keep foreign materials out of the consumables and Cartridge. Handle all parts carefully to avoid damage, which may a ect torch performance. Art # A-03887 1.
  • Page 51 2. Remove the Removal Tool from the Cartridge and install the assembled Cartridge onto the Torch Head. 3. Align and install the torch cartridge onto the torch body. Turn the locking collar by hand only stopping anywhere within the length of that slot. Art # A-14038 4.
  • Page 52 Torch Replacement Parts Standard Cutting Torch Description Catalog Number Torch Head Assembly 22-1002 Coolant Check Valve Assembly 9-4846 Torch Positioning Tube (includes hardware kit 9-4847) 9-4700 Positioning Tube Hardware Kit (O-Ring) 9-4847 Plasma & Shield Leads Assembly (to Torch Valve) 4-3026 Ohmic Clip (not shown) 9-9388...
