Hardware installation

2-1 Hardware installation Steps

Before using your computer, you had better complete the following steps:
1. Check motherboard setting
2. Install CPU
3. Install Memory
4. Install Expansion cards
5. Connect Ribbon cables, Panel wires, and power supply
6. Setup BIOS
7. Install software driver & utility

2-2 Checking Motherboard's Jumper Setting

(1) CPU Front Side Bus Frequency Setting (2-pin) : JP2, JP3
JP2
OFF
OFF
ON
Note: CPU Front Side Bus Frequency also can setting step by step in BIOS SETUP,
please refer page
(2) CMOS RAM Clear (3-pin) : JBAT
A battery must be used to retain the motherboard configuration in CMOS RAM short 1-2
pins of JBAT to store the CMOS data.
To clear the CMOS, follow the procedure below:
1. Turn off the system and unplug the AC power
2. Remove ATX power cable from ATX power connector
3. Locate JBAT and short pins 2-3 for a few seconds
4. Return JBAT to its normal setting by shorting pins 1-2
5. Connect ATX power cable back to ATX power connector
Chapter 2
JP3 CPU CLK
ON 100MHz
OFF 133MHz
OFF 166MHz
JP2
1
2
100MHz
CPU Front Side Bus Frequency Setting
33 Miscellaneous Control in Host Clock at Next.
(Default)
JP3 JP2 JP3 JP2 JP3
1 1
2 2
133MHz 166MHz
(Default)
