Modem Use IRQ
This determines the IRQ in which the MODEM can use.
The settings are: 3, 4, 5, 7, 9, 10, 11, NA.
Power Button Function
Pressing the power button for more than 4 seconds forces the system to enter the Soft-Off state.
The settings are: Delay 4 Sec, Instant-Off.

Wake Up Events

Please refer to section 3-8-1
3-8-1 Wake up Events
CMOS Setup Utility – Copyright(C) 1984-2004 Award Software
VGA
LPT & COM
HDD & FDD
PCI Master
Wake-Up on Ring/LAN
Wake-Up on PCI PME
PS2 KB Wakeup Selection
PS2KB Wakeup from S3/S4/S5
Wake-Up on RTC Alarm
x Date of Month Alarm
x Time (hh:mm:ss) Alarm
> IRQs Activities
↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit
F5:Previous Values
Wake Up On Ring/PME (V2DP not support)
During Disabled, the system will ignore any incoming call from the modem. During Enabled,
the system will boot up if there's an incoming call from the modem.
Wake-Up on RTC Alarm (V2DP not support)
This function is for setting date and time for your computer to boot up. During Disabled, you
cannot use this function. During Enabled, choose the Date and Time Alarm:
Date(of month) Alarm
You can choose which month the system will boot up. Set to 0, to boot every day.
Time(hh:mm:ss) Alarm
You can choose what hour, minute and second the system will boot up.
Note: If you have change the setting, you must let the system boot up until it goes to the
operating system, before this function will work.
IRQs Activities
Please refer to section 3-8-1.1
Wake Up Events
OFF
LPT/COM
ON
OFF
Disabled
Disabled
Hot Key
Disabled
Disabled
0
0 : 0 : 0
Press Enter
F6:Optimized Defaults
30
Item Help
Menu Level >>
F1:General Help
F7:Standard Defaults
