Onchip Device Function - JETWAY V2DP - REV 1.0 User Manual

OnChip IDE Channal0/Channel1
The integrated peripheral controller contains an IDE interface with support for two IDE
channels. Select Enabled to activate each channel separately. The settings are: Enabled and
Disabled.
Primary/Secondary Master/Slave PIO
The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of
the four IDE devices that the onboard IDE interface supports. Modes 0 through 4 provide
successively increased performance. In Auto mode, the system automatically determines the
best mode for each device. The settings are: Auto, Mode 0, Mode 1, Mode 2, Mode 3, Mode
4.
Primary/Secondary Master/Slave UDMA
Ultra DMA/33 implementation is possible only if your IDE hard drive supports it and the
operating environment includes a DMA driver (Windows 95 OSR2 or a third-party IDE bus
master driver). If your hard drive and your system software both support Ultra DMA/33 and
Ultra DMA/66, select Auto to enable BIOS support. The settings are: Auto, Disabled.
IDE HDD Block Mode
Block mode is also called block transfer, multiple commands, or multiple sector read/write. If
your IDE hard drive supports block mode (most new drives do), select Enabled for automatic
detection of the optimal number of block read/writes per sector the drive can support. The
settings are: Enabled, Disabled.

3-7-2 OnChip Device Function

CMOS Setup Utility – Copyright(C) 1984-2004 Award Software
VIA LAN Function
VIA LAN Boot ROM
AC97 Sound Device
Game Port Address
Midi Port Address
Midi Port IRQ
AC97 Modem Device
USB Host Controller
USB 2.0 Support
USB Keyboard Legacy Support
↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit
F5:Previous Values
AC97 Sound Device
This item allows you to decide to enable/disable the chipset family to support AC97 Audio.
The settings are: Enabled, Disabled.
Game Port Address/Midi Port Address
This will determine which Address the Game Port/Midi Port will use.
OnChip Device Function
Enabled
for V4DP and V2DP
Disabled
Auto
201
Disabled
10
Auto
Enabled
Enabled
Disabled
F6:Optimized Defaults
27
Item Help
Menu Level >>
F1:General Help
F7:Standard Defaults
