FLF525
INSTRUCTION MANUAL
Texto en español, página 14
WE'RE HERE TO HELP
Want to watch a video that
shows how easy this DIY
project will be?
Watch it now at:
SANUS.com/3255
Get it right the first time.
HeightFinder™ shows you
where to drill.
Check it out at:
SANUS.com/1171
Our US-based install experts
are standing by to help.
Call us at:
+1 (888) 333-9952
Or, chat at:
SANUS.com/chatSV
Advertisement
Table of Contents
Related Manuals for LEGRAND Sanus FLF525
Summary of Contents for LEGRAND Sanus FLF525
- Page 1 FLF525 INSTRUCTION MANUAL Texto en español, página 14 WE’RE HERE TO HELP Want to watch a video that Get it right the first time. Our US-based install experts shows how easy this DIY HeightFinder™ shows you are standing by to help. project will be? where to drill.
-
Page 2: Wall Construction
IMPORTANT SAFETY INSTRUCTIONS – PLEASE READ MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS CAUTION: Avoid potential personal injuries and property damage! • This product is designed ONLY to be installed into wood studs, solid concrete or concrete block — DO NOT INSTALL INTO DRYWALL ALONE — DRYWALL ALONE WILL NOT HOLD THE WEIGHT OF YOUR TV •... -
Page 3: Before You Begin
Dimensions TV INTERFACE 7.87in 200mm 15.75in 3.94in 400mm 100mm 23.62in 600mm MAX WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 16.00in 406.4mm DOWN 1.77in 45mm 10.36in 263.1mm SIMULATED 75" 25.0in 634mm FLAT SCREEN TV FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED SIDE VIEW RETRACTED 27.38in 2.38in... -
Page 4: Supplied Parts And Hardware
Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do NOTE: Not all hardware included will be used. not return the damaged item to your dealer;... - Page 5 STEP 1 Attach TV Bracket to TV 1.1 TV Screw Diameter 1 .2 Determine TV Screw Length and Spacers Only one screw size TV Screw fits your TV. Flat Back TV Washer TV Bracket CAUTION [TV brackets lay flat on your TV] MINIMUM NO SPACER NEEDED...
- Page 6 NOTE : Vertical TV support includes height positions for optimal installation. Example: Position is the LOWEST your TV will hang on the arm assembly Position is the HIGHEST your TV will hang on the arm assembly TV LOWER ON ARM TV HIGHER ON ARM Position the vertical TV support...
- Page 7 STEP 2 Attach Wall Plate Save bracket covers for STEP 3. For WOOD STUD INSTALLATIONS, follow STEP 2A on PAGE 8 CAUTION: Avoid potential personal injury or property damage! Min. Wood Stud Depth: nominal 102 mm (4 in.) ½ • Drywall covering the wall must not exceed 5/8 in. (16 mm) actual 89 mm (3 in.) •...
-
Page 8: Wood Stud Installation
STEP 2A Wood Stud Installation 2 ¾ in. (70 mm) 7/32 in. (5.5 mm) CAUTION: Avoid potential personal injury or property damage! IMPORTANT: Be sure to drill into the center of the stud. Improper use could reduce the holding power of the lag bolt Tighten the lag bolts only until the washers are pulled FIRMLY... - Page 9 STEP 2B Solid Concrete or Concrete Block Installation 3 in. (7.6 cm) 3/8 in. (10 mm) CAUTION: Never drill into the mortar between blocks. 002862.eps CAUTION: CAUTION: Be sure the anchors C1 are seated flush with the concrete surface. Avoid potential personal injury or property damage! Improper use could reduce the holding power of the lag bolt Fischer UX10 x 60R C1 - included in the Concrete Installation Kit CMK1.
- Page 10 STEP 3 Hang TV onto Wall Plate HEAVY! You may need assistance with this step. Height Adjust CAUTION: Use two people to hang the TV, to visually ensure TV bracket is hung onto Avoid potential personal injury or property damage! Locking screw arm assembly at your desired height slot.
-
Page 11: Manage Cables
Manage Cables IMPORTANT: Fully extend arm assembly to ensure enough slack in cables. Remove cable covers by loosening the end (a), then sliding off (b). 2. Route your cables through the arms 3. Reattach cable covers over the cables. -
Page 12: Tilt Adjustment
TV Adjustments TILT ADJUSTMENT Your TV should adjust easily when moved, then stay in place. If your TV is too loose or too tight, adjust the side tension knob NOTE: Once your TV is in place, tighten the tension knob to prevent unwanted movement. -
Page 13: Removing The Tv
EXTEND / RETRACT — ONLY IF NECESSARY Your TV should adjust easily when moved, then stay in place. ONLY if needed, adjust the extension/ retraction arm tension with screw using hex key CAUTION: Avoid potential personal injury or property damage! DO NOT remove bolts , only turn enough for slight adjustment. - Page 14 INSTRUCCIONES IMPORTANTES DE SEGURIDAD ESPAÑOL – – LEA TODO ESTE MANUAL ANTES DE UTILIZAR ESTE PRODUCTO GUARDE ESTAS INSTRUCCIONES Lea atentamente estas instrucciones en su totalidad para asegurarse de que está familiarizado con el sencillo proceso de instalación. Consulte igualmente el manual de su televisor para conocer si existen requisitos especiales para el montaje de su aparato. Si no entiende las instrucciones o si tiene dudas acerca de la seguridad de la instalación, el montaje o el uso del producto, póngase en contacto con el Servicio de Atención al Cliente o llame a nuestro servicio técnico al número 1-888-333-9952 .
- Page 15 1,3 Arme las placas de sujeción del televisor 1. Centre los soportes horizontales del televisor sobre el patrón de orificios del aparato y adjuntar libremente combinando los tornillos que eligió para su televisor. 2. Coloque el soporte vertical del televisor sobre los soportes horizontales y adjuntar libremente con los tornillos NOTA: El soporte de TV vertical (05) incluye posiciones de altura para una instalación óptima.
- Page 16 Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice or obligation of any kind. Legrand makes no representation of warranty, expressed or implied, regarding the information contained herein.
