I N S T A L L A T I O N I N S T R U C T I O N S
Above Wall
Above Cart/Ceiling
Below Cart/Ceiling
Below Wall
ConferenceSHOT® Fusion™Above/Below Mount
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
FCA800K
Advertisement
Related Manuals for LEGRAND Chief ConferenceSHOT Fusion FCA800K
Summary of Contents for LEGRAND Chief ConferenceSHOT Fusion FCA800K
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Above Wall Above Cart/Ceiling Below Cart/Ceiling Below Wall ConferenceSHOT® Fusion™Above/Below Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description...
-
Page 2: Important Safety Instructions
The information contained in this document is subject to change without notice or obligation of any kind. Legrand standard weight limit of mounting system - makes no representation of warranty, expressed or implied, (weight of FCA800K shelf + shelf components) regarding the information contained herein. - Page 3 Installation Instructions FCA800K DIMENSIONS - FCA800K...
- Page 4 FCA800K Installation Instructions DIMENSIONS - FCA800K (CONTINUED)
-
Page 5: Tools Required For Installation
Installation Instructions FCA800K LEGEND Tighten Fastener Phillips Screwdriver Apretar elemento de fijación Destornillador Phillips Befestigungsteil festziehen Kreuzschlitzschraubendreher Apertar fixador Chave de fendas Phillips Serrare il fissaggio Cacciavite a stella Bevestiging vastdraaien Kruiskopschroevendraaier Serrez les fixations Tournevis à pointe cruciforme Loosen Fastener Open-Ended Wrench Aflojar elemento de fijación Llave de boca... -
Page 6: Assembly And Installation
FCA800K Installation Instructions ASSEMBLY AND INSTALLATION Assembling Shelf to Upright Bracket CAUTION: Slide bracket with caution so that the bracket does not scratch or damage the wall! Attach camera bracket (D) to upright bracket (A) using two 1/4-20 x 1/2” button head machine screws (L). (See Figure Slide main bracket (B) behind wall mount rails until shelf 1) or (See Figure 2) bracket (C) rests on top of wall mount rail. - Page 7 Installation Instructions FCA800K (For maximum extension) Use #10-32 x 3/8” button head Attaching Shelf to Cart/Ceiling Mount cap screw (Q) and small washer (K) to secure adapter plate IMPORTANT ! : If installing to a 2x1 display cart using (A) to main bracket (B). (See Figure 5) the FCA623 accessory, proceed to “Installing to FCA623 (For maximum extension) Use two #10-24 lock nuts (J) to Accessory”...
- Page 8 FCA800K Installation Instructions Installing to FCA623 Accessory NOTE: Refer to Table 2 and dimension drawings on pages 3- 4 to determine the extension level based on extension IMPORTANT ! : Steps 6-10 only apply if installing to distance from mount center. FCA623 accessory.
- Page 9 Installation Instructions FCA800K 13. (For minimum extension) Slide upright bracket behind Slide second shelf bracket (C) underneath lower rail on wall main bracket. (See Figure 12) mount, lining up holes on shelf bracket (C) to holes on main bracket (B). (See Figure 14) 14.
- Page 10 FCA800K Installation Instructions Attaching Shelf to Cart/Ceiling Mount (For maximum extension) Use #10-32 x 3/8” button head cap screw (Q) and small washer (K) to secure adapter plate IMPORTANT ! : If installing to a 2x1 display cart using (H) to main bracket (B). (See Figure 15) the FCA623 accessory, proceed to “Installing to FCA623 (For maximum extension) Use two #10-24 lock nuts (J) to Accessory”...
- Page 11 Installation Instructions FCA800K Installing to FCA623 Accessory NOTE: Refer to Table 4 and dimension drawings on pages 3- 4 to determine the extension level based on extension NOTE: Steps 6-10 only apply if installing to FCA623 distance from mount center. accessory.
- Page 12 FCA800K Installation Instructions Height Adjustment Camera Loosen hardware used to attach main bracket (B) to upright (not included) bracket (A). (See Figure 23) Adjust shelf height as desired. (See Figure 23) NOTE: For all above display installations, it is recommended that the shelf be positioned so that it rests on top of display to help ensure an even mount.
- Page 13 Installation Instructions FCA800K...
- Page 14 FCA800K Installation Instructions...
- Page 15 Installation Instructions FCA800K...
- Page 16 P +31 (0) 495 580 852 F +31 (0) 495 580 845 Asia Pacific A Office No. 918 on 9/F, Shatin Galleria 8800-003283 Rev00 18-24 Shan Mei Street 2021 Legrand Fotan, Shatin, Hong Kong www.legrandav.com P 852 2145 4099 04/2021 F 852 2145 4477...
