BSF517 -B3

INSTRUCTION MANUAL

MANUEL D'INSTRUCTIONS

Texte français page 12

Need help?

Do you have a question about the Sanus Elite BSF517-B3 and is the answer not in the manual?

Questions and answers

Summary of Contents for LEGRAND Sanus Elite BSF517-B3

Page 1 BSF517 -B3 INSTRUCTION MANUAL MANUEL D’INSTRUCTIONS Texte français page 12 WE’RE HERE TO HELP NOUS POUVONS VOUS AIDER ! Recommended placement Want to watch a video that shows Get it right the ﬁrst time! Our US-based install experts are how easy this DIY project will be? HeightFinder shows you where to drill.
Page 2: Wall Construction
IMPORTANT SAFETY INSTRUCTIONS – PLEASE READ MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS Please read through these instructions completely to be sure you’re comfortable with this easy install process. Check your TV owner’s manual to see if there are any special requirements for mounting your TV. If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service: +1 (800) 359-5520.
Page 3: Before You Begin
Dimensions TV INTERFACE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 2.95in 7deg 75mm 2.0in 51mm 7.9in HEIGHT ADJUST UP 200mm 90deg 90deg 10.6in 268mm 7.87in 3.94in 200mm 2.95in 75mm 100mm 5deg 17.0in 433mm 3.94in 2.00in TOP VIEW - RETRACTED 100mm 50.8mm 8.8in...
Page 4: Supplied Parts And Hardware
Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
Page 5 STEP 1 Attach TV Bracket to TV 1.1 Select TV Screw Diameter 1.2 Select TV Screw Length and Spacers Only one screw size fits your TV. NO SPACER SPACER NEEDED • Flat Back TV • Flat Back TV • Rounded or Irregular Back TV with extra space needed [for deep inset holes or cable interference] [TV brackets NOT resting flat on your TV]...
Page 6: Wood Stud Installation
STEP 2A Attach Wall Plate Wood Stud Installation CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1½ x 3½ in. (38 x 89 mm) ●...
Page 7 STEP 2B Attach Wall Plate Solid Concrete or Concrete Block Installation CAUTION: Avoid potential personal injury or property damage! ● Mount wall plate directly onto concrete surface (no wall covering) ● Minimum solid concrete thickness: 8 in. (203 mm) ● Minimum concrete block size: 8 x 8 x 16 in.
Page 8 STEP 3 Hang TV onto Wall Plate HEAVY! You may need assistance with this step. CAUTION: Avoid potential personal injury or property damage! Locking screw must be installed to secure the TV to the arm assembly...
Page 9: Manage Cables
Manage Cables IMPORTANT: Fully extend arm assembly to ensure enough slack in cables. 1. Slide to remove the cable covers 2. Route your cables through the arm assembly 3. Reattach the cable covers over the cables.
Page 10: Tilt Adjustment
TV Adjustments TILT ADJUSTMENT Your TV should adjust easily when moved, then stay in place. If your TV is too loose or too tight, adjust the side tension knob by hand. NOTE: Once your TV is in place, tighten the tension knob prevent unwanted movement.
Page 11: Height Adjustment
HEIGHT ADJUSTMENT . Remove the TV (see below). . Remove screw . Adjust the position of the hanging tab Slide tab UP to LOWER your TV. Slide tab DOWN to RAISE your TV. . Secure with screw . Rehang your TV (STEP 3 on PAGE 8). To LOWER Your TV To RAISE...
Page 12 CONSIGNES DE SÉCURITÉ IMPORTANTES Français – CONSERVEZ CES INSTRUCTIONS – VEUILLEZ LIRE ENTIÈREMENT LE MANUEL AVANT D’UTILISER CE PRODUIT Veuillez lire au complet ces instructions pour vous assurer d’être à l’aise avec ce processus d’installation facile. Veuillez également consulter le manuel du propriétaire de votre téléviseur pour savoir si son installation présente des exigences particulières.
Page 13: Avant De Commencer
Dimensions PAGE 3 Avant de commencer Retirez le support de votre téléviseur...s'il est installé, bien sûr. Installez tous les accessoires que vous prévoyez d'ajouter à votre téléviseur. Vérifiez les manuels d'installation de tous ces accessoires pour savoir s'ils doivent être INSTALLÉS AVANT de monter le téléviseur.
Page 14 1-3 Fixez le support de téléviseur PAGE 5 REMARQUE : la languette de suspension est orientée vers le HAUT de votre téléviseur. CONSEIL : Avant d'installer le support TV , voir réglage de la hauteur à la PAGE 11. ATTENTION : Évitez les risques de blessures corporelles ou de dommages matériels ! N’utilisez PAS d’...
Page 15: Gestion Des Câbles
ÉTAPE 3 Accrochez le téléviseur sur la plaque murale PAGE 8 LOURD ! Vous aurez besoin de quelqu’un pour vous aider à cette étape. ATTENTION : Évitez les risques de blessures corporelles ou de dommages matériels ! Cette vis de blocage doit être installée afin de fixer le téléviseur sur l' e nsemble de la plaque murale Gestion des câbles PAGE 9...
Page 16 Legrand AV Inc. and its affiliated corporations and subsidiaries (collectively, “Legrand”), intend to make this manual accurate and complete. However, Legrand makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice or obligation of any kind. Legrand makes no representation of warranty, expressed or implied, regarding the information contained herein.
