Silvan Selecta SQUATPAK Instruction Manual

400l sprayer
Hide thumbs

Advertisement

Table of Contents

INSTRUCTION MANUAL
SQUATPAK 400L SPRAYER
MANSQ400
REV A 14/03/25
SQ400-S10R-1
SILVAN AUSTRALIA PTY. LTD.
ABN 48 099 851 144
AUSTRALIA
NEW ZEALAND
VICTORIA (HEAD OFFICE)
Telephone: +64 (07) 8496030
SILVAN SERVICE SUPPORT
Telephone: +61 (03) 9215 2700
www.silvannz.co.nz
PH 1300 745 826 (AUST) OR 0508 745 826 (N.Z)
1300 745826
email:
support@silvanaust.com
www.silvan.com.au
silvan.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SQUATPAK and is the answer not in the manual?

Questions and answers

Related Manuals for Silvan Selecta SQUATPAK

Summary of Contents for Silvan Selecta SQUATPAK

  • Page 1 INSTRUCTION MANUAL SQUATPAK 400L SPRAYER MANSQ400 REV A 14/03/25 SQ400-S10R-1 SILVAN AUSTRALIA PTY. LTD. ABN 48 099 851 144 AUSTRALIA NEW ZEALAND VICTORIA (HEAD OFFICE) Telephone: +64 (07) 8496030 SILVAN SERVICE SUPPORT Telephone: +61 (03) 9215 2700 www.silvannz.co.nz PH 1300 745 826 (AUST) OR 0508 745 826 (N.Z)

  • Page 2: Warranty Exclusions

    Silvan Warranty Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

  • Page 3: Safety Instructions

    Safety Instructions Before attempting to operate or install the sprayer carefully read and take note of the following safety warnings. Failure to comply with these warnings may result in serious injury or death. Warning! This sprayer is designed and manufactured solely for the purpose of applying agricultural chemicals to plants.

  • Page 4: Specifications

    Specifications GENERAL The Silvan Squatpak is a portable sprayer designed for the application of chemicals to agricultural crops, plants and weeds. The tank, pump and fittings are corrosion resistant and are suitable for applying weedicides, herbicides, insecticides, fungicides, organic and green formulations.
  • Page 5 Specifications FILTRATION In line suction filter and basket strainer beneath the tank lid to eliminate coarse debris. DIMENSIONS Product Code Length Width Height Weight SQ400-S10R-1 1060mm 940mm 1010mm 43kg To calculate the weight of the sprayer including water, add 1kg to the dry weight for every litre of water. E.g. The laden weight of the TP250-S10R-1 sprayer with 250L of water is 38 + 250 = 283kg...

  • Page 6: Installation

    Installation FITTING INSTRUCTIONS Position the sprayer in a way that minimises contamination to the operator. With the pump away from operator the risk of contamination due to hose failure can be minimised. It is recommended that the sprayer be securely attached to the vehicle or trailer.

  • Page 7: Operation

    Operation DDP-555 12V PUMP OPERATING INSTRUCTIONS Pressure Adjusting On/Off Tap – Spare Inlet Pressure Bypass return to tank Spare Outlet Tap Connection to Hose Reel  Turn the Pressure adjustment tap to clockwise (this allows flow from the pump to travel through the bypass hose to the tank) ...

  • Page 8: Maintenance

    Operation FILLING THE TANK AND ADDING CHEMICAL Warning: Before using the sprayer for the first time or adding chemical check the operation and function of the sprayer with clean water  Check that the battery power supply is charged and all fittings, hoses and gun connections are tight. ...

This manual is also suitable for:

Sq400-s10r-1

Table of Contents
