Instruction Manual
MANUP-1 REV H 14/04/20
VICTORIA (HEAD OFFICE)
Telephone: +61 (03) 9215 2700
Fax: +61 (03) 9215 2701
www.silvan.com.au
SILVAN AUSTRALIA PTY. LTD.
ABN 48 099 851 144
TRUKPAK 200L
SQUATPAK 300L, 400L
TK200-S7, TK200-S9, TK200-S10
SQ400-S7, SQ400-S8
NEW ZEALAND
Hamilton, New Zealand
Telephone: +64 (07) 8496 033
Fax: +64 (07) 8496070
www.silvannz.co.nz
UTEPAK 100L
UP100-S7
SQ300-S7
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Silvan Selecta UP100-S7
Summary of Contents for Silvan Selecta UP100-S7
- Page 1 Instruction Manual MANUP-1 REV H 14/04/20 UTEPAK 100L TRUKPAK 200L SQUATPAK 300L, 400L UP100-S7 TK200-S7, TK200-S9, TK200-S10 SQ300-S7 SQ400-S7, SQ400-S8 SILVAN AUSTRALIA PTY. LTD. ABN 48 099 851 144 VICTORIA (HEAD OFFICE) NEW ZEALAND Telephone: +61 (03) 9215 2700 Hamilton, New Zealand...
-
Page 2: Warranty Exclusions
Warranty Silvan Warranty Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. -
Page 3: Safety Instructions
Safety Instructions Before attempting to operate or install the sprayer carefully read and take note of the following safety warnings. Failure to comply with these warnings may result in serious injury or death. You need to read carefully and take note of the following warnings before attempting to operate or install this sprayer. -
Page 4: Specifications
Specifications GENERAL The Silvan Utepak, Trukpak and Squatpak are portable sprayers. Whether you are a commercial grower, or a home gardener you will find many uses for this unit. The tank pump and wand fittings are corrosion resistant and are suitable for applying weedicides, herbicides, insecticides, fungicides, organic and green formulations. -
Page 5: Spray Gun
Specifications (cont.) TANK 100, 200, 300 and 400 litre moulded translucent tank with calibrated litre graduations. Material is U.V. stabilized and impact resistant polyethylene with screw on lid has anti-spill breather. 100L Utepak and 200L Trukpak feature in moulded inserts in the tank base allowing the tank to be bolted down to a tray or skid. -
Page 6: Installation
Installation SETTING UP YOUR SPRAYER Where using the PA Spray Gun Fit the extension lance to the handgun ensuring the nylon washer is fitted between them. Fit the hose to the gun, using the hose clip supplied. Fit the white elbow fitting to the other end of the hose and secure it with the hose clamp provided. -
Page 7: Maintenance
Installation (cont.) FILLING THE TANK AND ADDING CHEMICAL Warning: Before using the sprayer for the first time or adding chemical check the operation and function of the sprayer with clean water • Check that the battery power supply is charged, the filters are clean, and all fittings, hoses and gun connections are tight. - Page 8 Special Installation – Hose Reel Kit 30m Eco Reel: 1. Fit the 2 x long brackets to the tank with 4 x M8x16mm Bolts, Washer & Spring Washers 2. Fit the hose reel with the 4 x M10 nuts Bolts, Washer & Spring Washers 3.
- Page 9 Special Installation – Hose Reel Kit 15m Reel for 200L: 1. Fit the 2 x long brackets to the tank with 4x M8x16mm Bolts, Washer & Spring Washers 2. Fit the upright bracket as shown with 2x M8X25mm Bolts, Washer & nyloc nuts 3.
