Foley TV Bed
OTTOMAN UPGRADE
WHEN THE OTTOMAN UPGRADE IS SELECTED - PLEASE USE THIS AI -- IGNORE THE STANDARD BED AI IN PACK 3
IMPORTANT – READ CAREFULLY – RETAIN FOR FUTURE REFERENCE You
must ensure that the mattress is on the bed frame before operating the lift
mechanism – Failure to do so could result in injury.
Keep hands clear of the mechanism when opening or closing the ottoman.
Beware of entrapment – Never reach in through the mechanism to access the
storage area.
Always ensure that the ottoman is FULLY opened before accessing the
storage area.
Do not exceed the maximum weight as specified in the table below:
1.5 hour approx
assembly time
MK1 230916
Double or King Size
Super King Size
IMPORTANT OTTOMAN SAFETY WARNINGS
Bed
Bed Size
Double
Foley TV Bed
King
Super King
Two person
assembly
Min Weight (kg) Max Weight (kg)
20
20
20
50
50
50
Advertisement
Related Manuals for DREAMS Foley
Summary of Contents for DREAMS Foley
- Page 1 Foley TV Bed OTTOMAN UPGRADE Double or King Size Super King Size WHEN THE OTTOMAN UPGRADE IS SELECTED - PLEASE USE THIS AI -- IGNORE THE STANDARD BED AI IN PACK 3 IMPORTANT OTTOMAN SAFETY WARNINGS IMPORTANT – READ CAREFULLY – RETAIN FOR FUTURE REFERENCE You must ensure that the mattress is on the bed frame before operating the lift mechanism –...
- Page 2 Maximum storage height is 310mm. WARNING! HAZARD - DO NOT REACH INTO THE SPACE BELOW! Foley TV Bed - Assembly guide - Page 2...
- Page 3 Do not sit on the mattress whilst the platform is in motion or is in the raised position. o Users should only get in and out of bed when platform is in the flat (horizontal) position. Foley TV Bed - Assembly guide - Page 3...
- Page 4 Thank you Hello, thanks for choosing to purchase your bed from Dreams - you're now on your way to your best ever night's sleep. Before you begin building your bed, please take a moment to read through the instructions and make sure that you've got all the relevant parts listed on the following pages.
- Page 5 Fixed retaining bracket - footboard Metal Slat Frame for Double or King Size Parking bracket - mattress base board Metal Slat Support Rails Mattress Stoppers Fabric Hand Strap s l i Foley TV Bed - Assembly guide - Page 5...
- Page 6 Bolts (M8x30mm) for fitting gas-lift mechanisms p(a) & p(b) to headboard and footboard (A&B) Spring washer for M8 bolts Flat washer for M8 bolts Gas-lift mechanisms Foley TV Bed - Assembly guide - Page 6...
- Page 7 Continue to press the button for another 5 seconds then press the up or down button to successfully match the code. Regularly check the batteries and if necessary re-place them - x3 pcs AAA size. Foley TV Bed - Assembly guide - Page 7...
- Page 8 Fit the wings to the headboard iii) Foley TV Bed - Assembly guide - Page 8...
- Page 9 Follow these instructions if you want to lift the frame up from the LEFT side. p(b) p(a) p(b) 10mm p(a) Bolts should be in the Align with Blue labels centre of the long holes Foley TV Bed - Assembly guide - Page 9...
- Page 10 Follow these instructions if you want to lift the frame up from the RIGHT side. p(b) p(a) p(a) 10mm p(b) Align with Red labels Bolts should be in the centre of the long holes Foley TV Bed - Assembly guide - Page 10...
- Page 11 Fit brackets (M,N & R) to the side rails a x2 b x2 c x2 100% Foley TV Bed - Assembly guide - Page 11...
- Page 12 Headend j x8 N.B. LABELS POINT TOWARDS EACH OTHER Inside the bed Left Right side rail side rail Footend Fit the four cushion pads (Z) and the two central supports (U). Foley TV Bed - Assembly guide - Page 12...
- Page 13 Note: For illustration purposes only, TV connections may vary. TV Power Lead TIP: If you would like to connect media equipment, your cables can be passed through the appropriate duct as shown. HDMI Foley TV Bed - Assembly guide - Page 13...
- Page 14 Choose a suitable set of hardware Counter-Sunk Counter-Sunk Screws Screw-Washer sets y x2 (M8x25mm) - Use Screws (M4x12mm) (M6x12mm) 5mm Allen Key (D) z x2 Allen Key (4mm) Allen Key (2.5mm) Loosen Tighten Foley TV Bed - Assembly guide - Page 14...
- Page 15 IF SCREWS ARE SUPPLIED WITH TV, PLEASE USE THOSE IN PREFERENCE Choose a suitable set of hardware Screw-Washer Counter-Sunk Counter-Sunk Screws sets (M8x25mm) y x2 Screws (M4x12mm) (M6x12mm) Use 5mm Allen Key (D) z x2 Allen Key (4mm) Allen Key (2.5mm) Foley TV Bed - Assembly guide - Page 15...
- Page 16 TV Installation Kit - 100 x 100 Vesa fixing Loosen Tighten Foley TV Bed - Assembly guide - Page 16...
- Page 17 HDMI PLUG IN - KEEP ALL CABLES TIGHT USE CLIPS & TIES PROVIDED. Keep wires tight - peel & adhere to back of TV. Foley TV Bed - Assembly guide - Page 17...
- Page 18 TV Power Lead Aerial Cable if required iii) Fit the fabric base cover evenly around the inside of the bed Foley TV Bed - Assembly guide - Page 18...
- Page 19 Double or King x4 Super King x6 Double or King x4 Super King x6 Double or King Size Super King Size Foley TV Bed - Assembly guide - Page 19...
- Page 20 SMALL GAP 10mm Bolt into centre of long holes Foley TV Bed - Assembly guide - Page 20...
- Page 21 100% SMALL GAP Foley TV Bed - Assembly guide - Page 21...
- Page 22 Unpack the contents of the Ottoman Support Bar (O.S.B.) from it's carton - this is packed inside Pack 4. 100% 100% iii) Foley TV Bed - Assembly guide - Page 22...
- Page 23 Set the inner stem to the correct length so the end just touches the retaining bracket - it needs to touch to hold it in position. 100% Adjust the retaining bracket (P) so the stem end scrapes the surface. Foley TV Bed - Assembly guide - Page 23...
- Page 24 Metal tends to be more resilient to everyday wear and tear. We recommend to gently dust your metal furniture and keep it dry to maintain its look. Thank you for shopping with us - we hope you have a great night's sleep. - Care and maintenance guide - Page 24 Foley TV Bed...
- Page 25 Little dreamers Keep the little ones entertained while you assemble your new purchase.
