RSL10-COIN-GEVB
RSL10-COIN-GEVB
Programming
RSL10−COIN−GEVB is a Bluetooth
RSL10, the industry's lowest power Bluetooth 5 SoC, and NCT375,
a temperature sensor. This board is battery powered and advertises
temperature, battery voltage and URL as advertising/beacon packets.
Brief Beacon Enablement Instructions
•
To allow third party app installation on Android phones please go to
Settings → Security and enable "Unknown Sources".
•
Access the beacons by going into the Nearby section of your phone.
Please select Settings → Google → Nearby
•
Note
AND9710/D
on
beacon applications with RSL10.
Eddystone Beacon software is preloaded onto the board and
advertises ambient temperature from sensor device NCT375, battery
voltage and URL link
www.onsemi.com/idk
to 2 s.
Source code of the beacon software, Eddystone_TLM_URL_sleep
can be downloaded from
evalBoard.do?id=RSL10−COIN−GEVB.
This workspace can be imported easily into RSL10 SDK, which can
be downloaded from
http://www.onsemi.com/PowerSolutions/
evalBoard.do?id=RSL10−002GEVB.
TLM and URL frames can be captured by generically available
beacon apps. Examples on Android OS include Beacon scanner,
Beacon Toy, Beacon manager, Beacon simulator (Figure 1).
Figure 1. Various Generic Beacon Apps Supporting Android OS
© Semiconductor Components Industries, LLC, 2018
August, 2018 − Rev. 0
®
beacon board featuring
www.onsemi.com
describes Eddystone
Advertising interval is set
http://www.onsemi.com/PowerSolutions/
EVAL BOARD USER'S MANUAL
1
www.onsemi.com
Publication Order Number:
EVBUM2578/D
Advertisement
Related Manuals for ON Semiconductor RSL10-COIN-GEVB
Summary of Contents for ON Semiconductor RSL10-COIN-GEVB
- Page 1 RSL10-COIN-GEVB RSL10-COIN-GEVB Programming ® RSL10−COIN−GEVB is a Bluetooth beacon board featuring RSL10, the industry’s lowest power Bluetooth 5 SoC, and NCT375, a temperature sensor. This board is battery powered and advertises www.onsemi.com temperature, battery voltage and URL as advertising/beacon packets.
- Page 2 RSL10−COIN−GEVB To modify the preloaded FW, please follow the below 3. Connect Jlink Ultra+ with needle adapter Tag instructions to flash new code: Connect, TC2050−IDC to CON1 of the board and 1. Insert coin battery into the socket per following hold it.
- Page 3 LIMITATIONS OF LIABILITY: ON Semiconductor shall not be liable for any special, consequential, incidental, indirect or punitive damages, including, but not limited to the costs of requalification, delay, loss of profits or goodwill, arising out of or in connection with the board, even if ON Semiconductor is advised of the possibility of such damages. In no event shall ON Semiconductor’s aggregate liability from any obligation arising out of or in connection with the board, under any theory of liability, exceed the purchase price paid for the board, if any.
- Page 4 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: ON Semiconductor RSL10-COIN-GEVB...
