RSL10 Hardware Reference
M-20829-008
October 2017
©
SCILLC, 2017
Previous Edition © 2016
"All Rights Reserved"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RSL10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ON Semiconductor RSL10

  • Page 1 RSL10 Hardware Reference M-20829-008 October 2017 © SCILLC, 2017 Previous Edition © 2016 “All Rights Reserved”...
  • Page 2 PUBLICATION ORDERING INFORMATION LITERATURE FULFILLMENT: N. American Technical Support: 800-282-9855 Toll ON Semiconductor Website: www.onsemi.com Literature Distribution Center for ON Semiconductor Free USA/Canada P.O. Box 5163, Denver, Colorado 80217 USA Europe, Middle East and Africa Technical Support: Order Literature: http://www.onsemi.com/orderlit...
  • Page 3: Table Of Contents

    ON Semiconductor Table of Contents Page 1. Introduction ....... .18 1.1 Purpose .
  • Page 4 RSL10 Hardware Reference 4.6.2 SYSCTRL_DSS_CMD ......36 4.6.3 SYSCTRL_DSS_LOOP_CACHE_CFG ....37 4.6.4 SYSCTRL_LPDSP32_DEBUG_CFG .
  • Page 5 ON Semiconductor 5.4.10 ACS_WAKEUP_GP_DATA ..... . 63 5.5 Resets ......63 5.5.1 Reset Status Register...
  • Page 6 RSL10 Hardware Reference 7. Memory ....... . . 94 7.1 Memory Architecture .
  • Page 7 ON Semiconductor 7.6 Flash Memory Registers ......121 7.6.1 FLASH_IF_CTRL ......121 7.6.2 FLASH_MAIN_WRITE_UNLOCK.
  • Page 8 RSL10 Hardware Reference 8.4.1.3 Channels ......144 8.4.2 Tx Specific Configuration ..... . . 144 8.4.2.1 Pulse Shape .
  • Page 9 ON Semiconductor 8.5.20 RF_TX_PULSE2 ......174 8.5.21 RF_TX_PULSE3 ......174 8.5.22 RF_RX_PULSE.
  • Page 10 RSL10 Hardware Reference 9.1.1 Bluetooth Baseband Error Handling ....204 9.1.2 Support Interfaces ......206 9.2 Baseband Registers and Memory Usage .
  • Page 11 ON Semiconductor 9.4.27 BB_DIAGSTAT......234 9.4.28 BB_DEBUGADDMAX ..... . . 234 9.4.29 BB_DEBUGADDMIN...
  • Page 12 RSL10 Hardware Reference 9.4.69 BB_RAL_LOCAL_RND ..... . . 252 9.4.70 BB_RAL_PEER_RND ..... . . 252 9.4.71 BB_ISOCHANCNTL0...
  • Page 13 ON Semiconductor 10.4.14 DIO_BB_SPI_SRC ......288 10.4.15 DIO_RF_SPI_SRC ......289 10.4.16 DIO_RF_GPIO03_SRC .
  • Page 14 RSL10 Hardware Reference 11.4.1.1 Frame Signal Configuration and Timing ....326 11.4.1.2 Data Serial Input and Output Configuration ....329 11.4.2 PCM Interrupt Configuration.
  • Page 15 ON Semiconductor 12.1.1.7 CRC_ADD_32 ......354 12.1.1.8 CRC_FINAL ......354 12.2 Direct Memory Access (DMA) Controller...
  • Page 16 RSL10 Hardware Reference 13.1.1.6 AUDIO_DMIC_DATA ..... 387 13.1.1.7 AUDIO_DMIC0_DATA ..... 387 13.1.1.8 AUDIO_DMIC1_DATA .
  • Page 17 ON Semiconductor 14.3.4 Debug Fault Status Register ..... . 413 14.3.5 ARM Cortex-M3 Processor Debug Port Specific Control and Configuration Registers .
  • Page 18: Introduction

    Bluetooth and other RF-based communication applications that make use of an RSL10 SoC. People who are developing local interfaces between an external device and RSL10, as well as those interested in the details of the audio, power supply and clocking components, will find this manual particularly helpful as it focuses on the configuration and use of system components.
  • Page 19: Further Reading

    Chapter 3: ARM Cortex-M3 Processor, provides an overview of the general-purpose ARM Cortex-M3 processor, its use in the RSL10 system, and its control and configuration registers. • Chapter 4: LPDSP32 Processor, provides an overview of the LPDSP32 DSP, its use in the RSL10 system, and its control and configuration registers. •...
  • Page 20: Overview

    YSTEM RCHITECTURE RSL10 is an ultra-low-power, highly flexible multi-protocol 2.4 GHz SoC specifically designed for use in high−performance wearable and medical applications, or any other applications that can benefit from low-power wireless connectivity. With its ARM Cortex-M3 Processor and LPDSP32 DSP core, RSL10 supports Bluetooth low energy technology and any 2.4 GHz proprietary protocol stacks, without sacrificing power consumption.
  • Page 21: Radio System Architecture

    LE 2 Mb PHY feature first defined in the Bluetooth core 5.0 technology release, and all optional features of Bluetooth low energy technology that were also defined in earlier core releases. The RSL10 baseband stack is supplemented by support structures that enable implementation of ON Semiconductor and customer designed custom protocols.
  • Page 22: Power

    OWER The RSL10 SoC is supplied from the VBAT pin, with a supply voltage in the range from 1.1 to 3.6 V in typical operating conditions. This supply is regulated by a DC-DC converter consisting of a low dropout voltage regulator (LDO) and a buck converter (can be used for VBAT >...
  • Page 23: Clocking

    ARM Cortex-M3 processor through one or more of the processor’s standard buses. This structure supports the control and configuration of all of the components of an RSL10 SoC in any system, and simplifies control of the LPDSP32, the RF front-end and Bluetooth protocol baseband hardware.
  • Page 24: Interfaces

    SoCs, support components such as external non-volatile storage, and sensors. The RSL10 system uses a DIO (Digital Input/Output) concept, where any DIO pad can be configured in software at any time to connect with any interface input or output. The only exception is the debug SWD-JTAG interface, which has dedicated pads for the serial-wire inputs.
  • Page 25: Peripherals

    For more information about the peripherals, see Chapter 12, “Peripherals” on page 351 and Chapter 14, “Private Peripherals” on page 401. 2.8 A UDIO OMPONENTS The RSL10 SoC provides a set of interfaces and peripherals to assist in applications that have an audio component. This includes: • An Asynchronous Sample Rate Converter (ASRC) •...
  • Page 26: Device Identification Register

    RSL10 Hardware Reference Table 1. Microcontroller Identification Register Field Name Description Byte The chip technology family to which the microcontroller AHBREGS_CHIP_ID_NUM_CHIP_FAMILY belongs. Version number for the microcontroller. Used to indicate AHBREGS_CHIP_ID_NUM_CHIP_VERSION major updates that might not be backwards compatible. An update of the major revision number indicates updates...
  • Page 27 ON Semiconductor www.onsemi.com...
  • Page 28: Arm Cortex-M3 Processor

    3.1 I NTRODUCTION The ARM Cortex-M3 processor plays a role as the central controller for the RSL10 microcontroller system.The ARM Cortex-M3 processor provides users with an interface for configuring and controlling all of the other system components. Following a power-on reset (POR), the system starts executing the Boot ROM on the ARM Cortex-M3 processor, and uses this ROM application to validate and initialize a system application.
  • Page 29: Sysctrl_Css_Loop_Cache_Cfg

    ON Semiconductor 3.1.1.1 SYSCTRL_CSS_LOOP_CACHE_CFG Bit Field Field Name Description CSS loop cache enable CSS_LOOP_CACHE_ENABLE Field Name Value Symbol Value Description Hex Value CSS loop cache disabled 0x0* CSS_LOOP_CACHE_ENABLE CSS_LOOP_CACHE_DISABLE CSS loop cache enabled CSS_LOOP_CACHE_ENABLE 3.2 D EBUG All applications executing on the ARM Cortex-M3 processor can be debugged through the SWJ-DP which can be configured to either serial wire or JTAG debug port communications.
  • Page 30: Debug Port Register

    RSL10 Hardware Reference To switch the SWJ-DP into serial wire mode, follow this initialization sequence: Send at least 50 clock cycles on SWCLK with the SWDIO pad held high. This ensures that the current interface is in its reset state.
  • Page 31: Ip Protection

    SYSCTRL_DBG_LOCK lock key (0x4C6F634B). At startup and whenever the RSL10 system is reset, the debug port defaults to this locked status. After start-up and system initialization, the Program ROM then loads the value from the word stored to LOCK_INFO_SETTING in the flash NVR3 sector into the register.
  • Page 32: Sysctrl_Dbg_Lock_Key

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Unlock debug port access DBG_LOCK_WR DBG_ACCESS_UNLOCK Lock debug port access 0x4C6F634B DBG_ACCESS_LOCK Debug port access is unlocked DBG_LOCK_RD DBG_ACCESS_UNLOCKED Debug port access is locked 0x1* DBG_ACCESS_LOCKED 3.3.1.2 SYSCTRL_DBG_LOCK_KEY Bit Field...
  • Page 33: Sysctrl_Cnt_Ctrl

    ON Semiconductor 3.4.1.1 SYSCTRL_CNT_CTRL Bit Field Field Name Description Activity counters status bit CNT_STATUS Clear activity counters CNT_CLEAR Stop activity counters CNT_STOP Start activity counters CNT_START Field Name Value Symbol Value Description Hex Value Activity counters stopped 0x0* CNT_STATUS CNT_STOPPED...
  • Page 34: Lpdsp32 Processor

    In some device variants, the LPDSP32 core can be removed from the RSL10 SoC. In devices that do not contain an LPDSP32 core, the...
  • Page 35: Interrupt Handling

    ON Semiconductor 4.4 I NTERRUPT ANDLING To coordinate execution of data-processing functions on the LPDSP32 processor with data that is available to be processed, the LPDSP32 is supported by two sets of interrupts that can trigger execution on the LPDSP32: Each DMA channel can issue one application-defined command, triggered by the DMA channel’s enabled...
  • Page 36: Registers

    RSL10 Hardware Reference To enable the LPDSP32 debug port, set the bit from SYSCTRL_LPDSP32_DEBUG_CFG_LPDSP32_DEBUG_ENABLE register. To allow the LPDSP32 debug port to force the core into an enabled state SYSCTRL_LPDSP32_DEBUG_CFG when halted over the debug port, set the from the SYSCTRL_LPDSP32_DEBUG_CFG_LPDSP32_EXIT_POWERDOWN_WHEN_HALTED register.
  • Page 37: Sysctrl_Dss_Loop_Cache_Cfg

    ON Semiconductor Bit Field Field Name Description Write a 1 to issue DSS command 2 DSS_CMD_2 Write a 1 to issue DSS command 1 DSS_CMD_1 Write a 1 to issue DSS command 0 DSS_CMD_0 Field Name Value Symbol Value Description...
  • Page 38: Power

    UPPLY VERVIEW The power supply is a critical component of the RSL10 system. Supplied power has significant effects on both RF and other types of system performance. The components that make up the power supply can be divided into two types of supply voltages: Power supply input voltages, described further in Section 5.2, “Power Supply Inputs”...
  • Page 39: Power Management Unit

    Section 5.4, “Power Modes” on page 51 5.2 P OWER UPPLY NPUTS 5.2.1 Battery Supply Voltage (VBAT) The primary voltage supplied to an RSL10 SoC is the battery supply voltage. This supply is used as the source for: www.onsemi.com...
  • Page 40: Digital Output Supply Voltage (Vddo)

    The System Supply Voltage (VCC) is used as the source for all of the internally generated supply voltages in the RSL10 SoC, and is supplied from VBAT. This power supply is used to reduce the battery voltage from a high voltage range (from 1.1 to 3.6 V) down to a supply voltage in the range from 1.0 to 1.32 V.
  • Page 41 ACS_VCC_CTRL_BUCK_ENABLE ACS_VCC_CTRL register. In this mode, the RSL10 SoC only uses VBAT or the internal LDO to supply VCC. Use of this mode requires an external VCC filtering capacitor, but does not require an external DC-DC converter inductor. The DC-DC converter is a buck converter used to reduce the battery voltage from a high value (from 1.4 to 3.6 V) to a lower VCC voltage value (from 1.0 to 1.32 V) with high efficiency.
  • Page 42: Vcc And Dc-Dc Converter Registers

    In this mode, the output ripple increases as VBAT decreases towards VCC - which might cause additional noise within the RSL10 system. To limit charge current in the DC-DC converter, the default setting of 80 mA (maximum output of 40 mA) is recommended. If the power supervisory circuit is resetting the system when using the DC-DC converter in the user circuit and under the user application’s operating conditions,...
  • Page 43: Internal Band Gap Reference Voltage

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Charge pump max current to 16 mA ICH_TRIM VCC_ICHTRIM_16MA Charge pump max current to 32 mA VCC_ICHTRIM_32MA Charge pump max current to 64 mA VCC_ICHTRIM_64MA Charge pump max current to 80 mA...
  • Page 44: Acs_Bg_Ctrl

    RSL10 Hardware Reference 5.3.2.1.1 ACS_BG_CTRL Bit Field Field Name Description 12:8 Temperature coefficient trimming SLOPE_TRIM Reference voltage trimming (2.5 mV steps) VTRIM Field Name Value Symbol Value Description Hex Value Temperature dependency 0 ppm/C 0xB* SLOPE_TRIM BG_SLOPE_TRIM_VALUE 0.6750 V VTRIM BG_TRIM_0P675V 0.6775 V...
  • Page 45: Rf Block Configuration And Control Registers

    ON Semiconductor , in the register, is the bit that controls the power amplifier ACS_VDDPA_CTRL_VDDPA_SW_CTRL ACS_VDDRF_CTRL supply, setting the output to HIZ in disable mode, and connecting the switched output to the VDDRF regulator (the Enable bit must be reset in this case). The...
  • Page 46: Acs_Vddpa_Ctrl

    1.06 V VDDPA_TRIM_1P06V 1.59 V 0x36 VDDPA_TRIM_1P59V 1.60 V 0x37* VDDPA_TRIM_1P60V 1.61 V 0x38 VDDPA_TRIM_1P61V 1.68 V 0x3F VDDPA_TRIM_1P68V 5.3.4 Digital Supply Voltages The RSL10 SoC includes internally regulated digital supply voltages, for which the calibrated settings are strongly recommended: www.onsemi.com...
  • Page 47: Digital Supply Configuration / Control Registers

    ON Semiconductor • VDDC is the core digital voltage that is used for most of the RSL10 system’s digital components. • VDDCRET replaces VDDC in power modes that use state retention of the RSL10 system’s digital components. • VDDM is the memory digital voltage that is used for memories and memory-mapped elements of the RSL10 system.
  • Page 48: Acs_Vddc_Ctrl

    RSL10 Hardware Reference 5.3.4.1.1 ACS_VDDC_CTRL Bit Field Field Name Description 21:16 VDDC standby voltage trimming (10 mV steps) STANDBY_VTRIM Low power mode control ENABLE_LOW_BIAS Sleep mode clamp control SLEEP_CLAMP Output voltage trimming configuration in 10 mV steps VTRIM Field Name...
  • Page 49: Acs_Vddret_Ctrl

    ON Semiconductor Bit Field Field Name Description Sleep mode clamp control SLEEP_CLAMP Output voltage trimming configuration in 10 mV steps VTRIM Field Name Value Symbol Value Description Hex Value 0.75 V STANDBY_VTRIM VDDM_STANDBY_TRIM_0P75V 0.76 V VDDM_STANDBY_TRIM_0P76V 1.0 V 0x19 VDDM_STANDBY_TRIM_1P00V 1.08 V...
  • Page 50: Analog Supply Voltage (Vdda)

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value VDDMRET trimming value 0x3* VDDMRET_VTRIM VDDMRET_TRIM_VALUE The VDDMRET retention regulator is 0x0* VDDMRET_ENABLE VDDMRET_DISABLE disabled The VDDMRET retention regulator is VDDMRET_ENABLE enabled VDDTRET trimming value 0x3* VDDTRET_VTRIM VDDTRET_TRIM_VALUE The VDDTRET retention regulator is...
  • Page 51: Analog Voltage Configuration And Control Registers

    The available power modes in RSL10 consist of Standby Mode, Sleep Mode, and Run Mode. Before entering Sleep Mode, RSL10 can be configured by the user to wake up from retention memory. RSL10 effectively uses power modes between RF events, while maintaining a Bluetooth low energy connection, and minimizing power consumption while in Standby Mode for duty cycled applications.
  • Page 52: Run Mode

    ROM and Flash are powered off, and used RAMs are placed in Retention Mode. The VDDC and VDDM regulator output voltages are set to their standby voltages. IMPORTANT: For an RSL10 SoC in standby, the 48 MHz crystal oscillator, RF block and STANDBY_VTRIM settings contribute significantly to the current of the battery (IBAT).
  • Page 53: Acs_Pwr_Modes_Ctrl

    ON Semiconductor enables or disables the DC-DC overload flag’s wakeup functionality. ACS_WAKEUP_CFG_DCDC_OVERLOAD_EN bit controls whether wakeup occurs on the wakeup pad’s rising edge, ACS_WAKEUP_CFG_WAKEUP_PAD_POL enabling a pull-down, or on the falling edge, with a pull-up enabled. The bit (where * is ACS_WAKEUP_CFG_DIO*_POL 0 to 3) controls the wakeup polarity on DIO pads 0 to 3.
  • Page 54 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Wait for 1 clock cycle DELAY WAKEUP_DELAY_1 Wait for 2 clock cycles WAKEUP_DELAY_2 Wait for 4 clock cycles WAKEUP_DELAY_4 Wait for 8 clock cycles WAKEUP_DELAY_8 Wait for 16 clock cycles WAKEUP_DELAY_16 Wait for 32 clock cycles (typ.10 us)
  • Page 55: Acs_Wakeup_State

    WAKEUP_DUE_TO_DIO0 5.4.5 Sleep Mode When operating in Sleep Mode, RSL10 will exhibit the lowest current consumption. Only the wakeup logic (see Section 5.4.4.1, “Wakeup Sources” on page 52 for sources of wakeup) is kept powered. The bandgap, regulators, RF block, etc. are disabled. The digital core and the memories can optionally be powered at low voltage.
  • Page 56 RSL10 Hardware Reference determines whether the reboot mode flag is set. ACS_WAKEUP_CTRL_BOOT_FLASH_APP_REBOOT controls whether the startup RC oscillator is at 3 or 12 MHz. ACS_WAKEUP_CTRL_RC_CLOCK_MULT bit configures whether or not the oscillators are treated as calibrated. ACS_WAKEUP_CTRL_RC_FTRIM_FLAG indicates whether the XTAL will start at boot.
  • Page 57: Wakeup From Retention Memory In Sleep Mode

    ON Semiconductor The digital reset is released, enabling boot PROM execution unless the VDDC retention regulator is enabled. To use the RTC timer as wakeup source, refer to Section 6.3.5, “Real-Time Clock (RTC)” 5.4.5.1 Wakeup from Retention Memory in Sleep Mode...
  • Page 58 RSL10 Hardware Reference NOTE: To verify the wakeup pad value, read from the SYSCTRL_WAKEUP_PAD_WAKEUP_PAD_VALUE in the register (see Section 5.4.9, “SYSCTRL_WAKEUP_PAD” on SYSCTRL_WAKEUP_PAD page 63). IMPORTANT: To configure the memory retention, the following operations are required: • -> ACS_VDDRET_CTRL VDDMRET_VTRIM •...
  • Page 59: Acs_Wakeup_Ctrl

    ON Semiconductor Table 6. Possible Wakeup Restore Addresses Location Address DSP_DRAM0_END 0x20007FE8 DSP_DRAM1_END 0x20009FE8 DSP_DRAM2_END 0x2000BFE8 DSP_DRAM3_END 0x2000DFE8 DSP_DRAM4_END 0x2000FFE8 DSP_DRAM5_END 0x20011FE8 BB_DRAM0_END 0x20013FE8 BB_DRAM1_END 0x20015FE8 5.4.6 ACS_WAKEUP_CTRL Bit Field Field Name Description Enable / Disable the Retention Mode of the pads...
  • Page 60 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Disable the pad Retention Mode 0x0* PADS_RETENTION_EN PADS_RETENTION_DISABLE Enable the pad Retention Mode PADS_RETENTION_ENABLE The reboot mode flag is not set 0x0* BOOT_FLASH_APP_REBOOT BOOT_FLASH_APP_REBOOT_DISABLE The reboot mode flag is set (ROM will...
  • Page 61: Sysctrl_Mem_Access_Cfg

    ON Semiconductor Field Name Value Symbol Value Description Hex Value DIO0 has not triggered a wakeup 0x0* DIO0_WAKEUP WAKEUP_DIO0_EVENT_NOT_SET event DIO0 has triggered a wakeup event WAKEUP_DIO0_EVENT_SET at least once Reset the sticky DCDC_OVERLOAD_CLEAR WAKEUP_DCDC_OVERLOAD_CLEAR WAKEUP_DCDC_OVERLOAD flag Reset the sticky...
  • Page 62 RSL10 Hardware Reference Bit Field Field Name Description PRAM1 access configuration PRAM1_ACCESS PRAM0 access configuration PRAM0_ACCESS Flash access configuration FLASH_ACCESS PROM access configuration PROM_ACCESS Field Name Value Symbol Value Description Hex Value DSP DRAM5 access disabled 0x0* DSP_DRAM5_ACCESS DSP_DRAM5_ACCESS_DISABLE DSP DRAM5 access enabled...
  • Page 63: Sysctrl_Wakeup_Addr

    ESETS The RSL10 SoC contains a variety of reset sources that can be used to reset the entire RSL10 system, or a set of its system components. A system reset causes the system to restart, and status bits to be set for each of the relevant reset causes.
  • Page 64 RSL10 Hardware Reference their encoding can be seen in Figure 5, which also shows the ordering of reset flags. These flags remain set until cleared by writing to their associated clear flags. IMPORTANT: To clear the status bits that indicate the source of a reset, the...
  • Page 65: Reset Status Register

    • The dedicated NRESET pad: if a reset using this pad occurs, the bit will be set. PAD_RESET_FLAG Partial resets supported by the RSL10 system include: • The watchdog timer (see Section 12.4, “Watchdog Timer” on page 376): • If the ARM Cortex-M3 processor is still running when the watchdog reset occurs, the bit will be set.
  • Page 66: Dig_Reset_Status

    RSL10 Hardware Reference 5.5.1.1 DIG_RESET_STATUS Bit Field Field Name Description Reset the sticky LOCKUP flag LOCKUP_RESET_FLAG_CLEAR Reset the sticky Watchdog time-out reset flag WATCHDOG_RESET_FLAG_CLEAR Reset the sticky ARM Cortex-M3 processor software reset flag CM3_SW_RESET_FLAG_CLEAR Reset the sticky ACS reset flag...
  • Page 67: Acs_Reset_Status

    ON Semiconductor 5.5.2 ACS_RESET_STATUS Bit Field Field Name Description Sticky flag that detects that a timeout in the power up sequence occurred TIMEOUT_RESET_FLAG Sticky flag that detects that a clock detector reset occurred CLK_DET_RESET_FLAG Sticky flag that detects that a VDDA reset occurred (triggered by vdda_ready =...
  • Page 68: Analog Test Signals

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value The VDDC reset has not triggered at VDDC_RESET_FLAG VDDC_RESET_FLAG_NOT_SET least once The VDDC reset was triggered at least 0x1* VDDC_RESET_FLAG_SET once since this status bit was last cleared The NRESET pad reset has not...
  • Page 69: Analog Output Configuration Register

    ON Semiconductor DIO0 can be used to output the RTC clock to control an external device. This mode is configured using the register, which has the following configurable bit-fields: ACS_AOUT_CTRL configures the RTC clock to be output to DIO0 starting at the defined interval, RTC_CLOCK_DIO0_START between 125 ms and 8 s.
  • Page 70 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value No start event (DIO0 not driven) 0x0* RTC_CLOCK_DIO0_START DIO0_RTC_CLK_DISABLE Start to output RTC clock every 125 ms 0x1 DIO0_RTC_CLK_125MS Start to output RTC clock every 250 ms 0x2 DIO0_RTC_CLK_250MS...
  • Page 71 ON Semiconductor Field Name Value Symbol Value Description Hex Value Flash TM0 connected to AOUT 0x13 (continued) TEST_AOUT AOUT_TM0 Bandgap ready on AOUT (digital signal 0x14 AOUT_BG_READY using VSSA and VCC states) vcc_ready on AOUT (digital signal 0x15 AOUT_VCC_READY using VSSA and VCC states)
  • Page 72 RSL10 Hardware Reference www.onsemi.com...
  • Page 73: Clocking

    6.1 O VERVIEW All clocks and clock domains in the RSL10 system are derived from the system clock (SYSCLK) or the standby clock (STANDBYCLK). Because of its importance to the functioning of RSL10 and the execution of applications, SYSCLK can be generated from one of five different sources for maximum flexibility.
  • Page 74 RSL10 Hardware Reference Figure 6. Clock Distribution www.onsemi.com...
  • Page 75: Clock Generation

    6.2.3 Standby RC Oscillator The standby RC oscillator is a ring oscillator that produces a trimmable output clock that can be used by the RSL10 system as a source for STANDBYCLK, and hence as a source for the RTC. This oscillator produces a nominal output...
  • Page 76: 32 Khz Crystal Oscillator

    RSL10 Hardware Reference frequency of 32 kHz. Enable the standby RC oscillator by setting the bit from the ACS_RCOSC_CTRL_RC_OSC_EN register. ACS_RCOSC_CTRL The frequency of the standby RC oscillator is trimmed using the bit-field from the ACS_RCOSC_CTRL_FTRIM_32K register. The trimming range for this oscillator can be shifted down by approximately 25%...
  • Page 77: Debug Port Clock

    6.2.6 Debug Port Clock The JTCK signal from the SWJ-DP interface in the RSL10 system can be used as an external input clock source that supplies SYSCLK. Prior to use in clocking the system, this clock is prescaled using the bit-field from the register.
  • Page 78: Acs_Xtal32K_Ctrl

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value The startup RC Oscillator is at 3 MHz 0x0* CLOCK_MULT RC_START_OSC_3MHZ The startup RC Oscillator is at 12 MHz 0x1 RC_START_OSC_12MHZ The 32kHz RC Oscillator is disabled 0x0* RC_OSC_EN...
  • Page 79: Clock Distribution

    LOCK ISTRIBUTION 6.3.1 System Clock (SYSCLK) The system clock (SYSCLK) is the primary clock for the RSL10 system and all other clocks except STANDBYCLK. The internal clock structures for the RF front-end are derived from SYSCLK. bit field from the...
  • Page 80: Standby Clock (Standbyclk)

    6.3.2 Standby Clock (STANDBYCLK) The RSL10 system includes a standby clock (STANDBYCLK) that is used as the source for the RTC (see Section 6.3.5, “Real-Time Clock (RTC)”), and can be used as the source for SYSCLK in standby operating modes.
  • Page 81: Baseband Clock (Bbclk) And Other Clocks For The Bluetooth Low Energy Baseband

    ON Semiconductor • Further divided forms of SLOWCLK (SLOWCLK_DIV2, SLOWCLK_DIV32), which are used as the source for: • The general purpose timers, which select between SLOWCLK_DIV2 and SLOWCLK_DIV32 (see Section 12.3, “Timers” on page 373) • The watchdog timer, which uses SLOWCLK_DIV32 (see Section 12.4, “Watchdog Timer” on page 376)
  • Page 82: User Clock (Usrclk)

    The user clock is an output clock that you can use as a clock source for the PCM interfaces or for any external components. This clock is not used internally by the RSL10 system, so its usage can depend entirely on the outside needs of the larger system containing RSL10.
  • Page 83 The PCM interface does not have its own divided clock, but is asynchronously clocked relative to the clock input provided at the PCM clock input pad. This clock source can be provided by the RSL10 system by routing a clock output to the same DIO that is acting as the PCM clock input (see Section 10.2, “Functional Configuration”...
  • Page 84: Clock Distribution Registers

    RSL10 Hardware Reference 6.3.9 Clock Distribution Registers Register Name Register Description Address System Clock Configuration Register 0x40000100 CLK_SYS_CFG Prescale register for SLOWCLK, BBCLK and 0x40000104 CLK_DIV_CFG0 USRCLK clocks Prescale register for PWM clock, UART and 0x40000108 CLK_DIV_CFG1 DMIC clocks Prescale register for DC-DC converter and...
  • Page 85: Clk_Div_Cfg0

    ON Semiconductor 6.3.9.2 CLK_DIV_CFG0 Bit Field Field Name Description 27:16 Prescale value for the USR clock (1 to 4096 in steps of 1) USRCLK_PRESCALE 10:8 Prescale value for the Baseband peripheral clock (1 to 8 in steps of 1) BBCLK_PRESCALE...
  • Page 86 RSL10 Hardware Reference Bit Field Field Name Description 13:8 Prescale value for the PWM1 peripheral clock (1 to 64 in steps of 1) PWM1CLK_PRESCALE Prescale value for the PWM0 peripheral clock (1 to 64 in steps of 1) PWM0CLK_PRESCALE Field Name...
  • Page 87: Clk_Div_Cfg2

    ON Semiconductor 6.3.9.4 CLK_DIV_CFG2 Bit Field Field Name Description Charge pump clock disable CPCLK_DISABLE 13:8 Prescale value for the charge pump clock from the SLOWCLK clock (1 to 64 in CPCLK_PRESCALE steps of 1) DC-DC converter clock disable DCCLK_DISABLE Prescale value for the DC-DC converter clock (1 to 64 in steps of 1)
  • Page 88: Acs_Rtc_Cfg

    RSL10 Hardware Reference 6.3.9.5 ACS_RTC_CFG Bit Field Field Name Description 31:0 Start value for the RTC timer counter (counts from start_value down to 0) START_VALUE Field Name Value Symbol Value Description Hex Value Divide by 1 START_VALUE RTC_CNT_START_0 Divide by 2...
  • Page 89: Clock Detection

    ON Semiconductor Field Name Value Symbol Value Description Hex Value RTC alarm is disabled 0x0* ALARM_CFG RTC_ALARM_DISABLE RTC alarm on counter bit 7 rising edge RTC_ALARM_7P8125MS (7.8125 ms) RTC alarm on counter bit 8 rising edge RTC_ALARM_15P625MS (15.625 ms) RTC alarm on counter bit 9 rising edge RTC_ALARM_31P25MS (31.25 ms)
  • Page 90: External Clock Detector

    4 kHz. This clock selection is automatically controlled by the underlying power-supply state machines of the RSL10 SoC, selecting the following clock sources for each mode: System startup RC oscillator (see Section 6.2.1, “RC Oscillator”...
  • Page 91: Clock Detector Registers

    ON Semiconductor When enabled, the clock detector can be used to trigger the interrupt. Configuration of this interrupt CLKDET_IRQ uses the bit field from the register, which can be configured to CLK_DET_CFG_CLK_DET_INT_SEL CLK_DET_CFG cause an interrupt if: • The monitored clock source becomes active •...
  • Page 92: Clk_Det_Status

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value No clock detected 0x0* CLK_DET_ENABLE CLK_DET_DISABLE Clock detected CLK_DET_ENABLE 6.4.3.2 CLK_DET_STATUS Bit Field Field Name Description Clock detector interrupt status (cleared when read) CLK_DET_INT_STATUS Clock detector status CLK_DET_STATUS Field Name...
  • Page 93 ON Semiconductor www.onsemi.com...
  • Page 94: Memory

    All memories are accessible through the ARM Cortex-M3 processor, although some interfaces and peripherals provide additional access paths to specific memory elements. The connections to the components that make up the memory for the RSL10 system are shown in Figure 7. Private Peripheral Registers...
  • Page 95: Memory Buses

    ON Semiconductor Table 7. RSL10 Memory Instances (Continued) Instance Name Size (bytes) Type Start Address Non-Volatile Record (NVR) 4 1024 Flash 0x00081800 (Manufacturing Test) Program RAM (x4) 4 x 8192 0x00200000 DSP (Program RAM) 4 x 10240 0x00220000 Data RAM...
  • Page 96: Memory Map And Usage

    SAGE 7.2.1 ARM Cortex-M3 Processor Memory Usage The memory provided on the RSL10 SoC is divided into five distinct areas with distinct uses. These areas are mapped into the RSL10 memory map, as shown in Figure 8 on page 97.
  • Page 97 2 KB 0x0008 07FF Flash NVR1 0x0008 0000 2 KB 0x0006 0FFF Flash RED2 0x0006 0800 2 KB 0x0006 07FF Flash RED1 0x0006 0000 2 KB 0x0000 0FFF PROM 0x0000 0000 4 KB 0x0000 0000 Figure 8. RSL10 Memory Map www.onsemi.com...
  • Page 98: Flash Memory

    Shared RAM Instances Other Memory Mapped Areas These sections are mapped into the RSL10 memory map, as shown in Figure 8 on page 97. The address ranges are in hexadecimal format. The following subsections provide a brief description and usage of each.
  • Page 99: Redundancy Sectors

    NOTE: The system library provides the function to support reading the NVR4 sector. Sys_ReadNVR4() See the RSL10 Firmware Reference manual for more information. IMPORTANT: NVR 1-2-3 sectors are only guaranteed for 1,000 program and erase cycles versus 100,000 programming cycles for all other memory sectors.
  • Page 100: Flash Delay Timings

    SystemCoreClock function from the CMSIS library is executed (for more information see the RSL10 SystemCoreClockUpdate() Firmware Reference). IMPORTANT: A minimum SYSCLK frequency of 1 MHz is required to safely complete a flash memory operation.
  • Page 101: Data Ram

    ON Semiconductor • When used as program memory or flash memory overlay by the ARM Cortex-M3 processor, the DSP PRAM is seen as 32-bit words and appears in reversed order on the ARM Cortex-M3 processor memory map. Since the memory is 40-bit native, the upper byte each word is not used. The main purpose of the DSP PRAM is to mirror the frequently used functions of the software stack and the application stored in the flash memory.
  • Page 102: Other Memory Mapped Areas

    RSL10 Hardware Reference 7.2.4 Other Memory Mapped Areas 7.2.4.1 Peripherals and Interfaces Memory-mapped registers on the peripheral bus are addressed between 0x4000 0000 and 0x400F FFFF (1 MB). This region contains the registers that are used to control various peripherals, interfaces, and other system components.
  • Page 103: Data Memory

    ON Semiconductor 0xFF FFFF Reserved 0x00 4000 0x00 3FFE 0x00 3FFF DSP_PRAM3 10 KB 0x00 3000 0x00 3001 0x00 2FFE 0x00 2FFF DSP_PRAM2 10 KB 0x00 2000 0x00 2001 0x00 1FFE 0x00 1FFF DSP_PRAM1 0x00 1001 0x00 1000 10 KB...
  • Page 104 RSL10 Hardware Reference 0xFF FFFF Reserved 0xC0 0008 0xC0 0007 0xC0 0004 Mapped Registers 0xC0 0000 0xC0 0003 0xBF FFFF Reserved 0x80 8000 0x80 7FFF 0x80 7FFC DRAM2 8 KB 0x80 6000 0x80 6003 0x80 5FFC 0x80 5FFF DRAM1 8 KB...
  • Page 105: Bluetooth Low Energy Baseband (Bb) Memory Usage

    IMPORTANT: The flash memory library contains functions that the user application can use to perform writes. Refer to the RSL10 Firmware Reference for more information. NOTE: While writing to or erasing any flash memory, no flash memory instance can be accessed from the I-Code or D-Code buses.
  • Page 106 RSL10 Hardware Reference Table 8. Flash Low-Level Commands (Continued) Command Description Execute a non-sequential programming access: CMD_PROGRAM_NOSEQ • If ECC is enabled, a pair of 32-bit words is written to flash memory. • If ECC is disabled, a single 36-bit word is written to flash memory.
  • Page 107: Low Power Read Mode

    ON Semiconductor 7.3.2 Low Power Read Mode • By setting the bit of the configuration register, it is only possible to read the flash LP_MODE FLASH_IF_CTRL memory when its power supply voltage VDDA is between 2.25 V and 2.75 V with reduced power consumption.
  • Page 108: Locking / Unlocking Mechanism

    RSL10 Hardware Reference 10. The command cannot be executed while the ARM Cortex-M3 processor runs a program CMD_PROGRAM_SEQ from the flash memory. 7.3.4 Locking / Unlocking Mechanism 7.3.4.1 Locking Mechanism A locking mechanism is included with the flash memory write hardware to prevent inadvertent writes to the flash memories.
  • Page 109 ON Semiconductor : indicates how many words are to be written to the destination (copier mode), or the FLASH_COPY_WORD_CNT number of words to be read and verified (comparator mode). : configures (copier or comparator), flash memory access (40-bit FLASH_COPY_CFG_MODE MODE...
  • Page 110: Memory Registers

    RSL10 Hardware Reference flash memory copier acts as a DMA access regarding the priority handling between the flash memory copier, ARM Cortex-M3 processor, LPDSP32 and baseband controller. NOTE: While the flash memory copier is running, it constantly tries to read from the flash memory and write to its destination memory.
  • Page 111: Sysctrl_Flash_Read_Cnt

    ON Semiconductor Field Name Value Symbol Value Description Hex Value DSP_PRAM2 is not mapped on the 0x0* DSP_PRAM2_OVERLAY_CFG DSP_PRAM2_OVERLAY_DISABLE Flash addressing range DSP_PRAM2 is also mapped on the DSP_PRAM2_OVERLAY_ENABLE Flash addressing range DSP_PRAM3 is not mapped on the 0x0* DSP_PRAM3_OVERLAY_CFG...
  • Page 112: Sysctrl_Mem_Power_Cfg

    RSL10 Hardware Reference Field Name Value Symbol Value Description Value No baseband memory error detected 0x0* BB_MEM_ERROR BB_MEM_NO_ERROR_DETECTED Baseband has accessed an isolated BB_MEM_ERROR_DETECTED memory No Flash copier memory error 0x0* FLASH_COPIER_MEM_ERROR FLASH_COPIER_MEM_NO_ERROR_DETECTED detected Flash copier has accessed an isolated...
  • Page 113 ON Semiconductor Bit Field Field Name Description Flash power configuration FLASH_POWER PROM power configuration PROM_POWER Field Name Value Symbol Value Description Hex Value DSP DRAM5 power disabled DSP_DRAM5_POWER DSP_DRAM5_POWER_DISABLE DSP DRAM5 power enabled 0x1* DSP_DRAM5_POWER_ENABLE DSP DRAM4 power disabled DSP_DRAM4_POWER...
  • Page 114: Sysctrl_Mem_Access_Cfg

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value PRAM1 power disabled PRAM1_POWER PRAM1_POWER_DISABLE PRAM1 power enabled 0x1* PRAM1_POWER_ENABLE PRAM0 power disabled PRAM0_POWER PRAM0_POWER_DISABLE PRAM0 power enabled 0x1* PRAM0_POWER_ENABLE Flash power disabled 0x0* FLASH_POWER FLASH_POWER_DISABLE Flash power enabled...
  • Page 115 ON Semiconductor Field Name Value Symbol Value Description Hex Value DSP DRAM5 access disabled 0x0* DSP_DRAM5_ACCESS DSP_DRAM5_ACCESS_DISABLE DSP DRAM5 access enabled DSP_DRAM5_ACCESS_ENABLE DSP DRAM4 access disabled 0x0* DSP_DRAM4_ACCESS DSP_DRAM4_ACCESS_DISABLE DSP DRAM4 access enabled DSP_DRAM4_ACCESS_ENABLE DSP DRAM3 access disabled 0x0* DSP_DRAM3_ACCESS...
  • Page 116: Sysctrl_Mem_Retention_Cfg

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Flash access disabled 0x0* FLASH_ACCESS FLASH_ACCESS_DISABLE Flash access enabled FLASH_ACCESS_ENABLE PROM access disabled PROM_ACCESS PROM_ACCESS_DISABLE PROM access enabled 0x1* PROM_ACCESS_ENABLE 7.5.6 SYSCTRL_MEM_RETENTION_CFG Bit Field Field Name Description DSP PRAM5 retention configuration...
  • Page 117: Sysctrl_Mem_Arbiter_Cfg

    ON Semiconductor Field Name Value Symbol Value Description Hex Value DSP DRAM1 Normal Mode DSP_DRAM1_RETENTION DSP_DRAM1_NORMAL_MODE DSP DRAM1 Retention Mode 0x1* DSP_DRAM1_RETENTION_MODE DSP DRAM0 Normal Mode DSP_DRAM0_RETENTION DSP_DRAM0_NORMAL_MODE DSP DRAM0 Retention Mode 0x1* DSP_DRAM0_RETENTION_MODE DSP PRAM3 Normal Mode 0x0* DSP_PRAM3_RETENTION...
  • Page 118 RSL10 Hardware Reference Bit Field Field Name Description 19:18 DSP PRAM1 arbiter configuration DSP_PRAM1_ARBITER 17:16 DSP PRAM0 arbiter configuration DSP_PRAM0_ARBITER 11:10 Baseband DRAM1 arbiter configuration BB_DRAM1_ARBITER Baseband DRAM0 arbiter configuration BB_DRAM0_ARBITER DRAM1 and DRAM2 arbiter configuration DRAM12_ARBITER DRAM0 arbiter configuration...
  • Page 119 ON Semiconductor Field Name Value Symbol Value Description Hex Value DSP has priority access to the DSP 0x0* DSP_PRAM2_ARBITER DSP_PRAM2_DSP_PRIORITY PRAM2 (above ARM Cortex-M3 core and DMA) ARM Cortex-M3 core has priority DSP_PRAM2_CM3_PRIORITY access to the DSP PRAM2 (above DSP and DMA)
  • Page 120: Sysctrl_Mem_Timing_Cfg

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value ARM Cortex-M3 core has priority 0x0* DRAM12_ARBITER DRAM12_CM3_PRIORITY access to the DRAM1 and DRAM2 (above DSP and DMA) DSP has priority access to the DRAM1 DRAM12_DSP_PRIORITY and DRAM2 (above ARM Cortex-M3...
  • Page 121: Flash Memory Registers

    ON Semiconductor 7.6 F LASH EMORY EGISTERS Register Name Register Description Address Flash Interface Control Register 0x40000500 FLASH_IF_CTRL Flash Main Write Unlock Register 0x40000504 FLASH_MAIN_WRITE_UNLOCK Flash Main Write Control Register 0x40000508 FLASH_MAIN_CTRL Flash, Memory and RF Power-Up Delay Configuration 0x40000510...
  • Page 122: Flash_Main_Write_Unlock

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Not pre-fetch the n+1 address on 0x0* PREFETCH_D_BUS FLASH_PREFETCH_D_BUS_DISABLE D-Bus Pre-fetch the n+1 address on D-Bus FLASH_PREFETCH_D_BUS_ENABLE Not pre-fetch the n+1 address on I-Bus 0x0* PREFETCH_I_BUS FLASH_PREFETCH_I_BUS_DISABLE Pre-fetch the n+1 address on I-Bus...
  • Page 123: Flash_Main_Ctrl

    ON Semiconductor 7.6.3 FLASH_MAIN_CTRL Bit Field Field Name Description Authorize write access to the high part of the Flash Main block through the MAIN_HIGH_W_EN FLASH_IF registers. Authorize write access to the middle part of the Flash Main block through the MAIN_MIDDLE_W_EN FLASH_IF registers.
  • Page 124: Flash_Cmd_Ctrl

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value FLASH_DELAY_CTRLx set for a SYSCLK_FREQ FLASH_DELAY_FOR_SYSCLK_3MHZ SYSCLK = 3 MHz FLASH_DELAY_CTRLx set for a FLASH_DELAY_FOR_SYSCLK_4MHZ SYSCLK = 4 MHz FLASH_DELAY_CTRLx set for a 0x2* FLASH_DELAY_FOR_SYSCLK_5MHZ SYSCLK = 5 MHz...
  • Page 125: Flash_If_Status

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Idle command 0x0* COMMAND CMD_IDLE Wakeup the Flash CMD_WAKE_UP Load patch and trimming values from CMD_LOAD_TRIM NVR4 Execute a read cycle CMD_READ Execute a non-sequential CMD_PROGRAM_NOSEQ programming cycle Starts a sequential programming...
  • Page 126 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value All NVR4 CBD0-CDB7 contents are 0x0* TRIMMED_STATUS FLASH_UNTRIMMED equal to 0xFFFF. eFlash untrimmed. Some registers CBD0-CBD7 contents FLASH_TRIMMED are not equal to 0xFFFF. eFlash trimmed. Flash can be accessed (isolation...
  • Page 127: Flash_Addr

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Indicates that the high part of the Flash 0x0* MAIN_HIGH_W_UNLOCK FLASH_MAIN_HIGH_W_LOCKED main section is protected against write accesses by the Flash interface Indicates that the high part of the Flash...
  • Page 128: Flash_Patch_Addr

    RSL10 Hardware Reference Bit Field Field Name Description Authorize Write access to the Flash NVR2 sector through the FLASH_IF NVR2_W_EN registers. Authorize Write access to the Flash NVR1 sector through the FLASH_IF NVR1_W_EN registers. Field Name Value Symbol Value Description...
  • Page 129: Flash_Copy_Ctrl

    ON Semiconductor Field Name Value Symbol Value Description Hex Value FLASH_DATA[1:0] compare with 0x0* COMP_MODE COMP_MODE_CONSTANT eFlash DOUT Odd address compare with COMP_MODE_CHBK FLASH_DATA[1:0], even address compare with inverse FLASH_DATA[1:0] Copy Flash to memory 0x0* COPY_DEST COPY_TO_MEM Copy Flash to CRC...
  • Page 130: Flash_Copy_Word_Cnt

    RSL10 Hardware Reference 7.6.16 FLASH_COPY_WORD_CNT Bit Field Field Name Description 16:0 Number of words to copy / compare COPY_WORD_CNT 7.6.17 FLASH_ECC_CTRL Bit Field Field Name Description 15:8 Select the number of corrected errors before sending a ARM Cortex-M3 core ECC_COR_CNT_INT_THRESHOLD...
  • Page 131: Flash_Ecc_Error_Addr

    ON Semiconductor Bit Field Field Name Description Reset the Flash address of the last detected error ECC_ERROR_ADDR_CLEAR FLASH_ECC_ERROR_COR_CNT status ECC_COR_ERROR_CNT_STATUS FLASH_ECC_ERROR_UNCOR_CNT status ECC_UNCOR_ERROR_CNT_STATUS Field Name Value Symbol Value Description Value Reset the Flash corrected errors ECC_COR_ERROR_CNT_CLEAR FLASH_ECC_COR_ERROR_CNT_CLEAR counter Reset the Flash uncorrected errors...
  • Page 132 RSL10 Hardware Reference www.onsemi.com...
  • Page 133: Rf Front-End

    CHAPTER 8 RF Front-End 8.1 O VERVIEW The RF front-end (RFFE) transceiver is an ultra low-power 2.4 GHz radio, handling data rates up to 2 Mbps. It supports several wireless protocols such as Bluetooth low energy technology, custom, or proprietary protocols. The RF front-end communicates with: •...
  • Page 134 RSL10 Hardware Reference Figure 11. RFFE Block Diagram The RF front-end implements a full transceiver, with the following digital features: • FSK modem with programmable pulse shape and modulation index • Data-rate programmable from 3 Mbps to 62.5 kbps (4 Mbps with 4-FSK) •...
  • Page 135: Sysctrl_Rf_Power_Cfg

    The RFFE implements the physical layer requirements of Bluetooth low energy technology, as accessed through the Bluetooth baseband hardware (see Chapter 9, “Bluetooth Low Energy Baseband” on page 203). It can also be used for a variety of standard (e.g., 802.15.4-based) protocols, proprietary protocols, and user- or ON Semiconductor-defined custom protocols.
  • Page 136: 48 Mhz Crystal Oscillator

    RSL10 Hardware Reference • 00: the digital baseband is off (no clock). • 01: the clock is generated but the blocks are reset (Tx, Rx, FIFOs and finite state machine (FSM)). • 10: the digital baseband is frozen. • 11: working •...
  • Page 137 ON Semiconductor The RFFE has an internal SPI and 10 GPIOs; for more information see Section 11.8, “Support Interfaces” on page 348. The RFFE has a number of GPIOs that can be configured to assist in monitoring IRQs and other signals while debugging protocol implementations that use the RFFE.
  • Page 138: Packet Format

    RSL10 Hardware Reference RF_TXFIFO_IRQ Interrupt is raised when the is high. TXFIFO_NEAR_UNDERFLOW Since the IRQ is tied to the “near underflow” flag of the FIFO, it can be cleared by filling the FIFO with enough data. RF_RXFIFO_IRQ Interrupt is raised when the is high.
  • Page 139: Packet Length

    ON Semiconductor bit of the register. Pattern detection can accept some errors: this is useful with EN_PATTERN PACKET_HANDLING very short preambles, since the clock recovery is not yet complete. The maximum number of errors accepted in pattern recognition is located in the field of the register.
  • Page 140: Multi-Frame

    RSL10 Hardware Reference of the register to 1; in such a case, the RS accepts the normal address and the ADDRESS_RX_BR ADDRESS_CONF_EN broadcast address during reception. Confirmation of broadcast address reception is found in the field IS_ADDRESS_BR of the register.
  • Page 141: Accessing The Fifos

    ON Semiconductor Table 12. Bluetooth CRC24 Algorithm Parameters CRC Parameter Parameter Value Polynomial (hex) 0x00065B Initial Value (hex) 0x555555 or protocol defined Final XOR Value (hex) 0x000000 This hardware CRC implementation works on the serialized stream, so the bit order depends on the value.
  • Page 142: Modulator And Radio Configuration

    RSL10 Hardware Reference During the reception of a message, many events can occur: for instance, a CRC error, or a packet length error. In all cases, the data must be stored in the FIFO, at least temporarily. If an event occurs, there are two choices: keep the data in the FIFO and let the external controller examine the content, or simply flush the received data.
  • Page 143: Radio Configuration

    ON Semiconductor Table 14. Supported Encoding and Decoding Options (Continued) Option Description Bit Order in Quadrature Modulations The bit order in quadrature modulation (especially O-QPSK) can be determined by the , and bits of the modulation. EVEN_BEFORE_ODD OFFSET I_NQ_DELAYED CODING...
  • Page 144: Channels

    RSL10 Hardware Reference   19 21  ----------------------------- - center_frequency refTx The RFFE chip has the option of having two different clock references, depending on the operational mode: Tx or Rx. The Tx reference clock is five times larger than the Rx clock. So to have the same frequency in Rx and Tx, the digital central frequency needs to be changed.
  • Page 145: Modulation Index

    ON Semiconductor If the bit of the register is set to 1, the second half of the pulse shape is inverted. PULSE_NSYM MOD_TX NOTE: The modulation is obtained by converting both the convolution of the pulse shape and the data-stream into a series of pulses (not rectangles). In the case of a GFSK modulation, the specified pulse shape is not the impulse response of an exponential filter, but the convolution of this response with a rectangle that is 1 symbol long.
  • Page 146: Interpolator

    RSL10 Hardware Reference This value must be split into mantissa and exponent. The exponent is the floor of the log of M, which is 2. The resulting mantissa is 13.   2 ----- - 7.25    In the case of a 4-FSK modulation, the definition of index modulation must be considered to be the same, but this results in the additional deviations being at +3 and -3 times the nominal deviation.
  • Page 147: Rx Specific Configuration

    ON Semiconductor 8.4.3 Rx Specific Configuration 8.4.3.1 Channel Filter Configuration The channel filter is not a digital block, but is digitally configurable, and its configurations might affect the digital baseband fine tuning. It is a polyphase filter, so its transfer function is not symmetrical; therefore, it rejects the image. Its central frequency and its bandwidth can be configured with three parameters.
  • Page 148 RSL10 Hardware Reference Interpolator Decimator ↑ ↓ phase in phase out deriv deriv Figure 14. Simplified Block Diagram of the Resampler Block for the Phase Note that in Figure 14, acc stands for “accumulator”, and deriv stands for “derivator”. While the RSSI can be resampled without any major problems, there might be an issue with the phase with this configuration if the signals are not handled correctly.
  • Page 149: Carrier Recovery

    ON Semiconductor ---------- These gain are compensated for, through the : this variable is an unsigned word. The gain is RESAMPLE_PH_GAIN given by: resample_ph_gain 7 – -resample_rssi_g1 On the RSSI side, an additional gain is added after the interpolator. This gain is given by 2 .
  • Page 150: Carrier Recovery Boundaries

    RSL10 Hardware Reference The time constant of the fine carrier recovery block is found in the register. The block is TAU_PHASE_RECOV enabled by setting the bit of the register. EN_FINE_RECOV CARRIER_RECOVERY 8.4.3.3.3 Carrier Recovery Boundaries The carrier recovery block can recover the carrier in a specified range. Theoretically the range is expected to be as wide as possible, but there are some limitations.
  • Page 151: Rssi Detection

    ON Semiconductor   2 --- - 0 8 ,   It is easy to calculate that the closest values are e = -1 and m = 5: these values give K = 0.8125, and a carrier recovery range of ±152 kHz. So freq_lim_man(2:0) = 0b101 and freq_lim_exp(2:0) = 0b111 (the prefix 0b means a binary representation).
  • Page 152 RSL10 Hardware Reference Carrier Offset Estimation This is always performed; the only way to block it is to disable RSSI detection. Carrier offset estimation is carried out by accumulating the actual frequency for a variable number of samples. The number of samples is chosen using the...
  • Page 153: Delay Line Synchronization

    ON Semiconductor give a false value, since the early estimation is made on data not yet corrected. The functionality is activated by the bit of the register being set to 1. EN_MIN_MAX_MF DEMOD_CTRL Fast Clock Recovery On the 4-FSK modulation, clock recovery is critical because the horizontal eye is quite close. In order to have a clock recovery that performs well, the time constant needs to be increased to filter the excessive noise on the zero crossings.
  • Page 154: Clock And Data-Rate Recovery

    RSL10 Hardware Reference In the case of an FSK modulation, the phase signal at the input of the filter is converted to frequency, and goes through the FIR. In the case of a PSK modulation, the phase is converted to the linear domain by a simple look-up table (LUT), and the I and Q signals go through the filter.
  • Page 155 ON Semiconductor Table 15. Data-Rate Recovery Search Range dr_limit Search Range ±3.125% ±6.25% ±12.5% NOTE: For small data-rate mismatches – for example, if only ppm of crystal oscillators are responsible for a DR mismatch – a simple clock recovery is enough. Also, there is a potential issue in data-rate recovery if carrier recovery is not performed correctly.
  • Page 156: Decision

    RSL10 Hardware Reference This means that the time constant for the 4-FSK modulation needs to be increased in order to achieve better filtering and be more precise regarding the sampling time. The latter is especially important because, as can be seen in Figure 16, if the sampling time is not exact, there may be a wrong decision regarding the level.
  • Page 157: Peak Detector

    ON Semiconductor • agc_level(8:7) — load of the intermediate frequency amplifier • 00: 16 k, max gain • 01: 8 k, 6dB of attenuation • 10: 4 k, 12dB of attenuation • 11: 2 k, 18dB of attenuation • agc_level(10:9) — select the LNA bias current.
  • Page 158: Rssi And Peak-Detector Combined Agc Strategy

    The following steps describe how to use register settings to configure a CW signal output, for Tx or Rx, at a rate of either 1 Mbps or 2Mbps: Load the hci_app hex file into flash memory, and then reset the RSL10 Evaluation and Development Board. This ensures that the RF registers are set correctly.
  • Page 159: Rf Front-End Registers

    ON Semiconductor When working in CW configuration, use your own preferred settings for VDDRF, VDDPA enabling, VCC, VDDPA, DCCLK, the charge pump clock, and buck enabling. 8.5 RF F RONT EGISTERS Register Name Register Description Address RF Power Configuration 0x40000050...
  • Page 160 RSL10 Hardware Reference Register Name Register Description Address AGC_ATT1 0x40010084 RF_AGC_ATT1 REG22 0x40010088 RF_REG22 REG23 0x4001008C RF_REG23 REG24 0x40010090 RF_REG24 REG25 0x40010094 RF_REG25 REG26 0x40010098 RF_REG26 REG27 0x4001009C RF_REG27 REG28 0x400100A0 RF_REG28 PLL_CTRL 0x400100A4 RF_PLL_CTRL REG2A 0x400100A8 RF_REG2A XTAL_CTRL 0x400100AC...
  • Page 161 ON Semiconductor Bit Field Field Name Description If set to 1 enables the differential coding/decoding MODE2_DIFF_CODING If set to 1, the PSK mode is selected, FSK otherwise. MODE2_PSK_NFSK 12:8 set the output testmode MODE2_TESTMODE In FSM mode, if set to 1 indicates to the FSM to go in suspend mode...
  • Page 162 RSL10 Hardware Reference Bit Field Field Name Description If set to 1 correct the AFC negatively CARRIER_RECOVERY_AFC_NEG If set to 1 enables the starter mode, i.e. a 32x faster carrier CARRIER_RECOVERY_STARTER_MODE recovery. if set to 1 enables the Automatic Frequency Control...
  • Page 163 ON Semiconductor Bit Field Field Name Description If set to 1, stops the Rx and flushes the FIFO in case of packet length FIFO_FIFO_FLUSH_ON_PL_ERR error If set to 1, stops the Rx and flushes the FIFO in case of CRC error...
  • Page 164 RSL10 Hardware Reference Bit Field Field Name Description If set to 1, flushes the Rx FIFO when the Rx is enabled, in order to receive a FIFO_2_RXFF_FLUSH_ON_START packet with an empty FIFO. If set to 1, flushes the Tx FIFO after the end of a packet transmission in order FIFO_2_TXFF_FLUSH_ON_STOP to have an empty FIFO.
  • Page 165 ON Semiconductor Bit Field Field Name Description Configuration of GPIO pad 5 PAD_CONF_3_PAD_5_CONF Configuration of GPIO pad 4 PAD_CONF_3_PAD_4_CONF Field Name Value Symbol Value Description Hex Value 0x0* MAC_CONF_MAC_TIMER_GR MAC_CONF_MAC_TIMER_GR_DEFAULT 0x0* MAC_CONF_RX_MAC_ACT MAC_CONF_RX_MAC_ACT_DEFAULT 0x0* MAC_CONF_RX_MAC_TX_NRX MAC_CONF_RX_MAC_TX_NRX_DEFAULT 0x0* MAC_CONF_RX_MAC_START_ MAC_CONF_RX_MAC_START_NSTOP_ NSTOP...
  • Page 166: Rf_Center_Freq

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0x0* TX_MAC_TIMER_TX_MAC_TIMER TX_MAC_TIMER_TX_MAC_TIMER_ DEFAULT 0x0* RX_MAC_TIMER_RX_MAC_TIMER RX_MAC_TIMER_RX_MAC_TIMER_ DEFAULT 8.5.7 RF_CENTER_FREQ Bit Field Field Name Description If set to 1, automatically adapt frequency between Tx and Rx. CENTER_FREQ_ADAPT_CFREQ If set to 1, the ratio of the pll reference between Tx and Rx is 5 instead of 6.
  • Page 167: Rf_Reg08

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* MOD_INFO_RX_SYMBOL_2BIT_RX MOD_INFO_RX_SYMBOL_2BIT_RX_ DEFAULT 0x0* MOD_INFO_RX_DR_M_RX MOD_INFO_RX_DR_M_RX_DEFAULT 0x0* MOD_INFO_TX_EN_DIV_2_N3_TX MOD_INFO_TX_EN_DIV_2_N3_TX_ DEFAULT 0x0* MOD_INFO_TX_SYMBOL_2BIT_TX MOD_INFO_TX_SYMBOL_2BIT_TX_ DEFAULT 0x0* MOD_INFO_TX_DR_M_TX MOD_INFO_TX_DR_M_TX_DEFAULT 8.5.9 RF_REG08 Bit Field Field Name Description 31:24 The packet length in the fixed packet length mode. In the variable packet PACKET_LENGTH_PACKET_LEN length mode, it specifies the maximal packet length defined by the standard.
  • Page 168: Rf_Reg09

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0xFF* PACKET_LENGTH_PACKET_LEN PACKET_LENGTH_PACKET_LEN_ DEFAULT 0x0* PACKET_HANDLING_LSB_FIRST PACKET_HANDLING_LSB_FIRST_ DEFAULT 0x0* PACKET_HANDLING_EN_CRC PACKET_HANDLING_EN_CRC_ DEFAULT 0x0* PACKET_HANDLING_EN_CRC_ON_ PACKET_HANDLING_EN_CRC_ON_ PKTLEN PKTLEN_DEFAULT 0x0* PACKET_HANDLING_EN_PREAMBLE PACKET_HANDLING_EN_PREAMBLE_ DEFAULT 0x0* PACKET_HANDLING_EN_MULTI_ PACKET_HANDLING_EN_MULTI_ FRAME FRAME_DEFAULT 0x0* PACKET_HANDLING_ENB_DW_ON_ PACKET_HANDLING_ENB_DW_ON_...
  • Page 169: Rf_Reg0A

    ON Semiconductor Bit Field Field Name Description If set to 1, the packet length is fixed and specified in the PACKET_LEN PACKET_LENGTH_OPTS_EN_PACKET register _LEN_FIX Signed value that specifies the correction to apply to the specified packet PACKET_LENGTH_OPTS_PACKET_ length (due to differences between standards). The packet length here is...
  • Page 170: Rf_Sync_Pattern

    RSL10 Hardware Reference 8.5.12 RF_SYNC_PATTERN Bit Field Field Name Description 31:0 Pattern (sync word) to be inserted or recognized. PATTERN Field Name Value Symbol Value Description Hex Value 0x0* PATTERN PATTERN_DEFAULT 8.5.13 RF_REG0C Bit Field Field Name Description 30:26 polynom of the third convolutional code...
  • Page 171: Rf_Crc_Polynomial

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* PACKET_EXTRA_EN_STOP_WORD PACKET_EXTRA_EN_STOP_WORD_ DEFAULT 0x0* PACKET_EXTRA_PKT_INFO_PRE_ PACKET_EXTRA_PKT_INFO_PRE_ NPOST NPOST_DEFAULT 0x0* PACKET_EXTRA_PATTERN_MAX_ PACKET_EXTRA_PATTERN_MAX_ ERR_DEFAULT 0x0* PACKET_EXTRA_PATTERN_WORD_ PACKET_EXTRA_PATTERN_WORD_ LEN_DEFAULT 8.5.14 RF_CRC_POLYNOMIAL Bit Field Field Name Description 31:0 CRC polynomial. It is coded using the Koopman notation, i.e. the nth bit codes CRC_POLYNOMIAL_CRC_POLY the (n+1) coefficient.
  • Page 172: Rf_Reg10

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0x0* RX_FRAC_CONF_RX_FRAC_DEN RX_FRAC_CONF_RX_FRAC_DEN_ DEFAULT 0x0* RX_FRAC_CONF_RX_FRAC_NUM RX_FRAC_CONF_RX_FRAC_NUM_ DEFAULT 0x0* FRAC_CONF_TX_FRAC_GAIN FRAC_CONF_TX_FRAC_GAIN_ DEFAULT 0x0* FRAC_CONF_RX_FRAC_GAIN FRAC_CONF_RX_FRAC_GAIN_ DEFAULT 0x0* FRAC_CONF_TX_EN_FRAC FRAC_CONF_TX_EN_FRAC_DEFAULT 0x0* FRAC_CONF_RX_EN_FRAC FRAC_CONF_RX_EN_FRAC_DEFAULT 0x0* CONV_CODES_PUNCT_CC_PUNCT_2 CONV_CODES_PUNCT_CC_PUNCT_2_ DEFAULT 0x0* CONV_CODES_PUNCT_CC_PUNCT_1 CONV_CODES_PUNCT_CC_PUNCT_1_...
  • Page 173: Rf_Tx_Pulse0

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* FRONTEND_EN_RESAMPLE_RSSI FRONTEND_EN_RESAMPLE_RSSI_ DEFAULT 0x0* FRONTEND_EN_RESAMPLE_PHADC FRONTEND_EN_RESAMPLE_PHADC_ DEFAULT 0x0* FRONTEND_DIV_PHADC FRONTEND_DIV_PHADC_DEFAULT 0x0* TX_MULT_TX_MULT_EXP TX_MULT_TX_MULT_EXP_DEFAULT 0x0* TX_MULT_TX_MULT_MAN TX_MULT_TX_MULT_MAN_DEFAULT 0x0* TX_FRAC_CONF_TX_FRAC_DEN TX_FRAC_CONF_TX_FRAC_DEN_ DEFAULT 0x0* TX_FRAC_CONF_TX_FRAC_NUM TX_FRAC_CONF_TX_FRAC_NUM_ DEFAULT 8.5.18 RF_TX_PULSE0 Bit Field Field Name...
  • Page 174: Rf_Tx_Pulse2

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0x0* TX_PULSE_SHAPE_2_TX_COEF8 TX_PULSE_SHAPE_2_TX_COEF8_ DEFAULT 0x0* TX_PULSE_SHAPE_2_TX_COEF7 TX_PULSE_SHAPE_2_TX_COEF7_ DEFAULT 0x0* TX_PULSE_SHAPE_2_TX_COEF6 TX_PULSE_SHAPE_2_TX_COEF6_ DEFAULT 0x0* TX_PULSE_SHAPE_2_TX_COEF5 TX_PULSE_SHAPE_2_TX_COEF5_ DEFAULT 8.5.20 RF_TX_PULSE2 Bit Field Field Name Description 31:24 TX_PULSE_SHAPE_3_TX_COEF12 23:16 TX_PULSE_SHAPE_3_TX_COEF11 15:8 TX_PULSE_SHAPE_3_TX_COEF10...
  • Page 175: Rf_Rx_Pulse

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* TX_PULSE_SHAPE_4_TX_COEF14 TX_PULSE_SHAPE_4_TX_COEF14_ DEFAULT 0x0* TX_PULSE_SHAPE_4_TX_COEF13 TX_PULSE_SHAPE_4_TX_COEF13_ DEFAULT 8.5.22 RF_RX_PULSE Bit Field Field Name Description 31:28 RX_PULSE_SHAPE_RX_COEF8 27:24 RX_PULSE_SHAPE_RX_COEF7 23:20 RX_PULSE_SHAPE_RX_COEF6 19:16 RX_PULSE_SHAPE_RX_COEF5 15:12 RX_PULSE_SHAPE_RX_COEF4 11:8 RX_PULSE_SHAPE_RX_COEF3 RX_PULSE_SHAPE_RX_COEF2 These registers specify the Rx pulse shape. The pulse shape is formed by: RX_PULSE_SHAPE_RX_COEF1 coef1-coef8-coef8-coef1.
  • Page 176: Rf_Reg17

    RSL10 Hardware Reference Bit Field Field Name Description Mantissa of the final stage gain of the matched filter FILTER_GAIN_FILTER_GAIN_M Exponent of the final stage gain of the matched filter FILTER_GAIN_FILTER_GAIN_E Field Name Value Symbol Value Description Hex Value 0x0* RX_IF_RESAMPLE_PH_IF...
  • Page 177: Rf_Reg18

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* CARRIER_RECOVERY_EXTRA_MAX_ CARRIER_RECOVERY_EXTRA_ ERR_IN_DL_SYNC MAX_ERR_IN_DL_SYNC_ DEFAULT 0x0* CARRIER_RECOVERY_EXTRA_EN_ CARRIER_RECOVERY_EXTRA_ SYNC_OK_DELAY_LINE EN_SYNC_OK_DELAY_LINE_ DEFAULT 0x0* CARRIER_RECOVERY_EXTRA_NC_ CARRIER_RECOVERY_EXTRA_ SEL_OUT NC_SEL_OUT_DEFAULT 0x0* CARRIER_RECOVERY_EXTRA_EN_ CARRIER_RECOVERY_EXTRA_ NOT_CAUSAL EN_NOT_CAUSAL_DEFAULT 0x0* CARRIER_RECOVERY_EXTRA_FREQ_ CARRIER_RECOVERY_EXTRA_ LIMIT_MAN FREQ_LIMIT_MAN_DEFAULT 0x0* CARRIER_RECOVERY_EXTRA_FREQ_ CARRIER_RECOVERY_EXTRA_...
  • Page 178: Rf_Reg19

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0x0* RSSI_BANK_TAU_RSSI_FILTERING RSSI_BANK_TAU_RSSI_ FILTERING_DEFAULT 0x0* DECISION_USE_VIT_SOFT DECISION_USE_VIT_SOFT_ DEFAULT 0x0* DECISION_VITERBI_LEN DECISION_VITERBI_LEN_ DEFAULT 0x0* DECISION_VITERBI_POW_NLIN DECISION_VITERBI_POW_NLIN_ DEFAULT 0x0* DECISION_EN_VITERBI_GFSK DECISION_EN_VITERBI_GFSK_ DEFAULT 8.5.26 RF_REG19 Bit Field Field Name Description 29:28 Same as pll_filter_res_trim but for Tx case. Real value in Tx is pll_filter_res_trim PLL_BANK_PLL_FILTER_RES_ xor pll_filter_res_trim_tx.
  • Page 179: Rf_Reg1A

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* CLK_CH_FILTER_DIV_RSSI CLK_CH_FILTER_DIV_RSSI_ DEFAULT 0x0* CLK_CH_FILTER_DIV_FILT CLK_CH_FILTER_DIV_FILT_ DEFAULT 8.5.27 RF_REG1A Bit Field Field Name Description 31:28 Maximum attenuation level in AGC algorithm ATT_CTRL_ATT_CTRL_MAX 27:24 Attuenuation level if the AGC is bypassed...
  • Page 180: Rf_Reg1B

    RSL10 Hardware Reference 8.5.28 RF_REG1B Bit Field Field Name Description If set to 1 enables the Tx data-whitening before the convolutional code IEEE802154_OPTS_EN_DW_TEST block 30:29 sets the clock output mode for BER mode or RW mode: 00 => data change IEEE802154_OPTS_BER_CLK_MODE on falling edge, 01 =>...
  • Page 181: Rf_Agc_Lut1

    ON Semiconductor 8.5.29 RF_AGC_LUT1 Bit Field Field Name Description 31:22 Look up table with the AGC values: agc_level_0 is supposed the lowest AGC_LUT_1_AGC_LEVEL_2_LO attenuation, while agc_level_11 is the one with a maximum of attenuation. 21:11 Look up table with the AGC values: agc_level_0 is supposed the lowest AGC_LUT_1_AGC_LEVEL_1 attenuation, while agc_level_11 is the one with a maximum of attenuation.
  • Page 182: Rf_Agc_Lut4

    RSL10 Hardware Reference Bit Field Field Name Description 12:2 Look up table with the AGC values: agc_level_0 is supposed the lowest AGC_LUT_3_AGC_LEVEL_6 attenuation, while agc_level_11 is the one with a maximum of attenuation. Look up table with the AGC values: agc_level_0 is supposed the lowest AGC_LUT_3_AGC_LEVEL_5_HI attenuation, while agc_level_11 is the one with a maximum of attenuation.
  • Page 183: Rf_Agc_Att1

    ON Semiconductor Bit Field Field Name Description 10:8 Fixes the granularity of the timer in Rx mode. The granularity is given by TIMINGS_1_T_GRANULARITY_RX (2^(t_granularity))x1us Look up table with the AGC values: agc_level_0 is supposed the lowest AGC_LUT_5_AGC_LEVEL_11_HI attenuation, while agc_level_11 is the one with a maximum of attenuation.
  • Page 184: Rf_Reg22

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0x3* AGC_ATT_1_AGC_ATT_34 AGC_ATT_1_AGC_ATT_34_DEFAULT 0x3* AGC_ATT_1_AGC_ATT_23 AGC_ATT_1_AGC_ATT_23_DEFAULT 0x3* AGC_ATT_1_AGC_ATT_12 AGC_ATT_1_AGC_ATT_12_DEFAULT 0x3* AGC_ATT_1_AGC_ATT_01 AGC_ATT_1_AGC_ATT_01_DEFAULT 8.5.35 RF_REG22 Bit Field Field Name Description If set to 1 enables filter Tx configuration for the fast Rx PLL...
  • Page 185: Rf_Reg24

    ON Semiconductor Bit Field Field Name Description 23:20 PA backoff bias BIAS_0_IQ_RXTX_1 19:16 PA bias BIAS_0_IQ_RXTX_0 14:12 Select the number of wait states during the APB transaction INTERFACE_CONF_APB_WAIT_ STATE Select the spi mode: 00 legacy spi, 01 advanced spi, 10 BLIM4SME spi...
  • Page 186: Rf_Reg25

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0x0* BIAS_4_IQ_PLL_1 BIAS_4_IQ_PLL_1_DEFAULT 0x0* BIAS_3_IQ_RXTX_8 BIAS_3_IQ_RXTX_8_DEFAULT 0x0* BIAS_3_IQ_RXTX_7 BIAS_3_IQ_RXTX_7_DEFAULT 0x0* BIAS_2_IQ_RXTX_6 BIAS_2_IQ_RXTX_6_DEFAULT 0x0* BIAS_2_IQ_RXTX_5 BIAS_2_IQ_RXTX_5_DEFAULT 8.5.38 RF_REG25 Bit Field Field Name Description 31:28 Peak detector threshold bias 0 BIAS_9_IQ_BB_6...
  • Page 187: Rf_Reg27

    ON Semiconductor Bit Field Field Name Description Peak detector threshold bias 1 BIAS_10_IQ_BB_8 Peak detector threshold bias 2 BIAS_10_IQ_BB_7 Field Name Value Symbol Value Description Hex Value 0x0* SD_MASH_MASH_ENABLE SD_MASH_MASH_ENABLE_DEFAULT 0x0* SD_MASH_MASH_DITHER SD_MASH_MASH_DITHER_DEFAULT 0x0* SD_MASH_MASH_ORDER SD_MASH_MASH_ORDER_DEFAULT 0x0* SD_MASH_MASH_RSTB SD_MASH_MASH_RSTB_DEFAULT 0x0*...
  • Page 188: Rf_Reg28

    RSL10 Hardware Reference 8.5.41 RF_REG28 Bit Field Field Name Description If set to 1 switch the low-pass filter in the Rx chain CTRL_RX_SWITCH_LP If set to 1, the peak detector is powered on during the Rx by the FSM CTRL_RX_USE_PEAK_DETECTOR...
  • Page 189: Rf_Pll_Ctrl

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* CTRL_RX_CTRL_RX CTRL_RX_CTRL_RX_DEFAULT 0x0* SWCAP_FSM_SB_CAP_RX SWCAP_FSM_SB_CAP_RX_DEFAULT 0x0* SWCAP_FSM_SB_CAP_TX SWCAP_FSM_SB_CAP_TX_DEFAULT 0x0* DLL_CTRL_CK_LAST_SEL_DELAY DLL_CTRL_CK_LAST_SEL_DELAY_ DEFAULT 0x0* DLL_CTRL_CK_FIRST_SEL_DELAY DLL_CTRL_CK_FIRST_SEL_DELAY_ DEFAULT 0x0* DLL_CTRL_CK_EXT_SEL DLL_CTRL_CK_EXT_SEL_DEFAULT 0x0* DLL_CTRL_CK_DIG_EN DLL_CTRL_CK_DIG_EN_DEFAULT 0x0* DLL_CTRL_CK_TEST_EN DLL_CTRL_CK_TEST_EN_DEFAULT 0x0* DLL_CTRL_TOO_FAST_ENB DLL_CTRL_TOO_FAST_ENB_DEFAULT 0x0*...
  • Page 190 RSL10 Hardware Reference Bit Field Field Name Description Debug: charge-pump offset current values selection bits (see bit 6 to enable this PLL_CTRL_1_CHP_CURR_ mode): 00 => d_phi = 15, 01 => d_phi=22.5, 10 => d_phi = 30, 11 => d_phi = 60.
  • Page 191: Rf_Reg2A

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* PLL_CTRL_1_FAST_CHP_EN PLL_CTRL_1_FAST_CHP_EN_DEFAULT 0x0* PLL_CTRL_1_CHP_MODE_TRIM PLL_CTRL_1_CHP_MODE_TRIM_ DEFAULT 0x0* PLL_CTRL_1_CHP_CMC_EN PLL_CTRL_1_CHP_CMC_EN_DEFAULT 0x0* PLL_CTRL_1_CHP_CURR_OFFSET_EN PLL_CTRL_1_CHP_CURR_OFFSET_EN_ DEFAULT 8.5.43 RF_REG2A Bit Field Field Name Description If set to 1, the en PPA cascode bit is independent from the en PA...
  • Page 192 RSL10 Hardware Reference Bit Field Field Name Description Xtal oscillator enable (active low) XTAL_CTRL_XO_EN_B_REG 15:14 Xtal trimming speed: 00 => 43us, 01 => 85us, 10 => 171us, 11 => 341us XTAL_CTRL_XTAL_CKDIV When high, disable the output clock to go to main IP (clk_out output stay XTAL_CTRL_CLK_OUT_EN_B low).
  • Page 193: Rf_Reg2C

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* XTAL_CTRL_XTAL_CKDIV XTAL_CTRL_XTAL_CKDIV_DEFAULT 0x0* XTAL_CTRL_CLK_OUT_EN_B XTAL_CTRL_CLK_OUT_EN_B_DEFAULT 0x0* XTAL_CTRL_REG_VALUE_SEL XTAL_CTRL_REG_VALUE_SEL_ EXTERNAL XTAL_CTRL_REG_VALUE_SEL_ INTERNAL 0x1* XTAL_CTRL_AFTERSTARTUP_ XTAL_CTRL_AFTERSTARTUP_CURR_ CURR_SEL SEL_DEFAULT 0x1* XTAL_CTRL_STARTUP_CURR_SEL XTAL_CTRL_STARTUP_CURR_SEL_DEFAULT 0x0* XTAL_CTRL_INV_CLK_DIG XTAL_CTRL_INV_CLK_DIG_DEFAULT 0x0* XTAL_CTRL_INV_CLK_PLL XTAL_CTRL_INV_CLK_PLL_DEFAULT 0x0* XTAL_CTRL_FORCE_CLK_READY XTAL_CTRL_FORCE_CLK_READY_DEFAULT 0x0*...
  • Page 194: Rf_Reg2D

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0x0* SUBBAND_OFFSET_SB_OFFSET SUBBAND_OFFSET_SB_OFFSET_DEFAULT 0x0* SWCAP_LIM_SB_MAX_VAL SWCAP_LIM_SB_MAX_VAL_DEFAULT 0x0* SWCAP_LIM_SB_MIN_VAL SWCAP_LIM_SB_MIN_VAL_DEFAULT 0x0* SUBBAND_CONF_SB_FLL_MODE SUBBAND_CONF_SB_FLL_MODE_DEFAULT 0x0* SUBBAND_CONF_SB_INV_BAND SUBBAND_CONF_SB_INV_BAND_DEFAULT 0x0* SUBBAND_CONF_SB_FREQ_CNT SUBBAND_CONF_SB_FREQ_CNT_DEFAULT 0x0* SUBBAND_CONF_SB_WAIT_T SUBBAND_CONF_SB_WAIT_T_DEFAULT 0x0* SUBBAND_CONF_SB_MODE SUBBAND_CONF_SB_MODE_DEFAULT 0x0* PA_CONF_SW_CN PA_CONF_SW_CN_DEFAULT 0x0* PA_CONF_TX_SWITCHPA...
  • Page 195: Rf_Reg2E

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* SUBBAND_CORR_SUBBAND_CORR_EN SUBBAND_CORR_SUBBAND_CORR_EN_ DEFAULT 0x0* SUBBAND_CORR_SUBBAND_CORR_RX SUBBAND_CORR_SUBBAND_CORR_RX_ DEFAULT 0x0* SUBBAND_CORR_SUBBAND_CORR_TX SUBBAND_CORR_SUBBAND_CORR_TX_ DEFAULT 0x0* PLL_CONF_TX_NRX_INV_CLK_PLL_ PLL_CONF_TX_NRX_INV_CLK_PLL_ TX_DEFAULT 0x0* PLL_CONF_TX_NRX_INV_CLK_DIG_ PLL_CONF_TX_NRX_INV_CLK_DIG_ TX_DEFAULT 0x3* PLL_CONF_TX_NRX_CK_SEL_TX PLL_CONF_TX_NRX_CK_SEL_TX_ DEFAULT 0x0* PLL_CONF_TX_NRX_CHP_CURR_OFF_ PLL_CONF_TX_NRX_CHP_CURR_OFF_ TRIM_TX TRIM_TX_DEFAULT 0x0*...
  • Page 196: Rf_Reg2F

    RSL10 Hardware Reference Bit Field Field Name Description If set to 1 enables the early fine recovery after the packet detection or DEMOD_CTRL_EARLY_FINE_RECOV pre-sync Number of samples to estimate the carrier offset: 0 -> 32, 1 -> 64, 2 -> 128, RSSI_DETECT_RSSI_DET_CR_LEN 3->256...
  • Page 197 ON Semiconductor Bit Field Field Name Description If set to 1 enables the pull-up of the GPIO pads PADS_PE_DS_GPIO_PE If set to 1 enables the pull-up of the nreset pad PADS_PE_DS_NRESET_PE If set to 1 enables the pull-up of the MISO SPI pad...
  • Page 198: Rf_Reg30

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0x0* SYNC_WORD_CORR_EN_SYNC_WORD_CORR SYNC_WORD_CORR_EN_SYNC_WORD_ CORR_DEFAULT 0x0* SYNC_WORD_CORR_SYNC_WORD_BIAS SYNC_WORD_CORR_SYNC_WORD_BIAS_ DEFAULT 8.5.49 RF_REG30 Bit Field Field Name Description 31:25 Start the bist test on the Rx FIFO (code 0x5d) RXFIFO_STATUS_BIST 31:30 Indicate the BIST error: 00 => no error, 01 => error in checkboard test, 10 RXFIFO_STATUS_BIST_ERRORS =>...
  • Page 199: Rf_Reg31

    ON Semiconductor 8.5.50 RF_REG31 Bit Field Field Name Description 31:24 Maximum RSSI value over a filtering period RSSI_MAX_RSSI_MAX 23:16 Minimum RSSI value over a filtering period RSSI_MIN_RSSI_MIN 15:8 Number of bytes in the Rx FIFO RXFIFO_COUNT_RX_COUNT Number of bytes in the Tx FIFO TXFIFO_COUNT_TX_COUNT 8.5.51 RF_REG32...
  • Page 200: Rf_Irq_Status

    RSL10 Hardware Reference 8.5.55 RF_IRQ_STATUS Bit Field Field Name Description Is set to 1 when the IRQ RXFIFO is active IRQ_STATUS_FLAG_RXFIFO Is set to 1 when the IRQ TXFIFO is active IRQ_STATUS_FLAG_TXFIFO Is set to 1 when the IRQ SYNC is active...
  • Page 201: Rf_Revision

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* ANALOG_INFO_CLK_DIG_READY ANALOG_INFO_CLK_DIG_NOT_READY ANALOG_INFO_CLK_DIG_READY 8.5.59 RF_REVISION Bit Field Field Name Description 29:24 Version of the chip: 0x00: v1, 0x10: v2A, 0x11: v2B, 0x12: v2C, 0x13: v2D, 0x14: CHIP_ID v2E, 0x20: v3...
  • Page 202 RSL10 Hardware Reference www.onsemi.com...
  • Page 203: Bluetooth Low Energy Baseband

    Figure 18. This supplements the physical layers implemented by the RF front-end (refer to Chapter 8, “RF Front-End” on page 133) and the L2CAP and host layers that are supported by the Bluetooth stack firmware (refer to the “Bluetooth Stack and Profiles” chapter from the RSL10 Firmware Reference). www.onsemi.com...
  • Page 204: Bluetooth Baseband Error Handling

    • The hardware aspects of the security manager as accessible through the GAP layer See the RSL10 Firmware Reference for more information about host and profile layer support. 9.1.1 Bluetooth Baseband Error Handling This interrupt indicates that a hardware error has been detected. The error type can be recovered by reading the...
  • Page 205 Indicates whether two consecutive and concurrent CONCEVTIRQ_ERROR have been generated, and not acknowledged in 1: Error occurred ble_event_irq time by the RSL10 software. 0: No error Indicates whether Rx data buffer pointer value programmed is null: RXDATA_PTR_ERROR this is a major programming failure.
  • Page 206: Support Interfaces

    RSL10 Hardware Reference Table 17. ERRORTYPESTAT Description (Continued) Command Value Description 0: No error Indicates Anticipated Pre-Fetch Mechanism error: happens when 2 EVT_CNTL_APFM_ERROR consecutive events are programmed, and the first event is not 1: Error occurred completely finished while second pre-fetch instant is reached.
  • Page 207: Baseband Abstraction Layer Primitives

    ON Semiconductor The abstraction layer contains a few primitives, allowing atomic read/writes and copies of data from system RAM to exchange memory. 9.2.1 Baseband Abstraction Layer Primitives The following functions and macros are used by the link layer software to access the baseband registers, exchange...
  • Page 208: Baseband Timing

    Area Figure 20. Control Structure Allocation IMPORTANT: The exchange memory provided by the RSL10 SoC supports a maximum of 31 links; however, the default Bluetooth stack firmware may be built to support fewer links, for power and memory efficiency. If your user application requires more links than the Bluetooth library builds described in the RSL10 Firmware Reference can support, contact your ON Semiconductor Customer Service Representative for assistance.
  • Page 209: Acs_Bb_Timer_Ctrl

    ON Semiconductor BBCLK ------------------------------------------------------------------------- - 1MHz BBCLK_DIV   BBIF_CTRL_CLK_SEL The reset and the low power timing generator clock (32 kHz), or a divided clock for lower power consumption, are divided from the standby clock (Section 6.3.2, “Standby Clock (STANDBYCLK)” on page 80) with the baseband timer...
  • Page 210: Timing And Event-Related Interrupts

    RSL10 Hardware Reference 9.3.3 Timing and Event-Related Interrupts The real time scheduling and the system wakeup are synchronized over several interrupts. These interrupts are generated by the hardware (BaseBand / Core). Refer to Figure 22 on page 210. Rx ISR...
  • Page 211 ON Semiconductor SW programs ET entry HW fetches entry 2 slots in advance some time before slot Figure 23. Programming Process Overview Start Start Start Prog Latency Prog Latency Prog Latency Master Interval Slave Prog Latency Prog Latency Prog Latency...
  • Page 212: End Of Event Interrupt

    RSL10 Hardware Reference 9.3.3.2 End of Event Interrupt The end of event interrupt allows the firmware to check what has been received and sent. This interrupt happens at the end of the event, even if nothing has been received. See Figure 24 on page 211.
  • Page 213: Wakeup Interrupt

    ON Semiconductor Prog Latency Channel = 38 Scanner Advertiser Prog Latency Start Figure 26. Rx interrupts, Advertising Packet Received 9.3.3.4 Wakeup Interrupt The wakeup interrupt allows the firmware to turn on the system and start a Bluetooth low energy technology activity.
  • Page 214: Software Interrupt

    RSL10 Hardware Reference The event arbiter checks whether the event should be programmed, or if it is in the past and should be pushed into the canceled queue. 9.3.3.5 Software Interrupt This interrupt indicates an event arbiter cancellation.The firmware increments the priority and the programming time before trying to reinsert the event in the event arbiter wait queue.
  • Page 215 ON Semiconductor Register Name Register Description Address Deep sleep wakeup register 0x40001534 BB_DEEPSLWKUP Deep sleep status register 0x40001538 BB_DEEPSLSTAT Stabilization times 0x4000153C BB_ENBPRESET Fine timer correction register 0x40001540 BB_FINECNTCORR Base timer correction register 0x40001544 BB_BASETIMECNTCORR Diagnostic ports control register 0x40001550...
  • Page 216 Register controlling the decision instant for priority scheduling 0x400016B0 BB_BBPRIOSCHARB arbitration In typical use cases, the Bluetooth device address should be set to the value stored to the Device Configuration Record (NVR3) at the location. For more information see the RSL10 Firmware Reference. DEVICE_INFO_BLUETOOTH_ADDR www.onsemi.com...
  • Page 217: Bbif_Ctrl

    ON Semiconductor 9.4.1 BBIF_CTRL Bit Field Field Name Description External wakeup request used to sort out sleep modes WAKEUP_REQ Configure the internal baseband controller clock divider in order to provide a CLK_SEL 1MHz reference clock Enable the baseband controller clocks generation...
  • Page 218 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Reset value 0x0* LINK_FORMAT LINK_FORMAT_RESET Master connect MASTER_CONNECT Slave connect SLAVE_CONNECT Low Duty Cycle Advertiser LOW_DUTY_ADVERTISER High Duty Cycle Advertiser HIGH_DUTY_ADVERTISER Passive Scanner PASSIVE_SCANNER Active Scanner ACTIVE_SCANNER Initiator INITIATOR...
  • Page 219: Bbif_Coex_Status

    ON Semiconductor 9.4.4 BBIF_COEX_STATUS Bit Field Field Name Description 15:12 Indicates the priority level of the current Bluetooth baseband core activity BLE_PTI Indicates if the Bluetooth baseband core has an event in process, active high. BLE_IN_PROCESS Indicates if the Bluetooth baseband core is busy and performs Tx activity, active BLE_TX high.
  • Page 220: Bbif_Coex_Int_Status

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Interrupt not triggered 0x0* BLE_TX_EVENT BLE_TX_EVENT_NONE Interrupt triggered on rising edge BLE_TX_EVENT_RISING_EDGE Interrupt triggered on falling edge BLE_TX_EVENT_FALLING_EDGE Interrupt triggered on any edge BLE_TX_EVENT_TRANSITION Interrupt not triggered 0x0* BLE_RX_EVENT...
  • Page 221 ON Semiconductor Field Name Value Symbol Value Description Hex Value No audio link is currently processed by 0x0* RF_ACTIVE IDLE the RF front-end The audio link is currently processed ACTIVE by the RF front-end Use the Bluetooth low energy 0x0*...
  • Page 222 RSL10 Hardware Reference Bit Field Field Name Description Default Rx Window size in us (used when device is master connected or RXWINSZDEF performs its second receipt) Indicates the maximum number of errors allowed to recognize the SYNCERR synchronization word Field Name...
  • Page 223: Bb_Version

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Bluetooth baseband core reports all 0x0* ADVERTFILT_EN ADVERTFILT_EN_0 errors to Bluetooth baseband software Bluetooth baseband core reports only ADVERTFILT_EN_1 correctly received packet, without error to Bluetooth baseband software Disable Bluetooth baseband core...
  • Page 224: Bb_Intcntl

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Bluetooth baseband core is used as a 0x0* DMMODE DMMODE_0 standalone BLE device Bluetooth baseband core is used in a DMMODE_1 dual mode device No ISO/Audio Channel available ISOPORTNB...
  • Page 225 ON Semiconductor Bit Field Field Name Description SW triggered interrupt mask SWINTMSK End of event / anticipated pre-fetch abort interrupt mask EVENTAPFAINTMSK Fine target timer mask FINETGTIMINTMSK Gross target timer mask GROSSTGTIMINTMSK Error interrupt mask ERRORINTMSK Encryption engine interrupt mask...
  • Page 226: Bb_Intstat

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Interrupt not generated RXINTMSK RXINTMSK_0 Interrupt generated 0x1* RXINTMSK_1 Interrupt not generated CSCNTINTMSK CSCNTINTMSK_0 Interrupt generated 0x1* CSCNTINTMSK_1 9.4.12 BB_INTSTAT Bit Field Field Name Description Audio channel 2 interrupt status...
  • Page 227: Bb_Intrawstat

    ON Semiconductor Field Name Value Symbol Value Description Hex Value No error interrupt 0x0* ERRORINTSTAT ERRORINTSTAT_0 An error interrupt is pending ERRORINTSTAT_1 No encryption / decryption interrupt 0x0* CRYPTINTSTAT CRYPTINTSTAT_0 An encryption / decryption interrupt is CRYPTINTSTAT_1 pending No end of advertising / scanning /...
  • Page 228: Bb_Intack

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value No Audio interrupt 0x0* AUDIOINT0RAWSTAT AUDIOINT0RAWSTAT_0 An Audio interrupt is pending. AUDIOINT0RAWSTAT_1 No SW triggered interrupt 0x0* SWINTRAWSTAT SWINTRAWSTAT_0 A SW triggered interrupt is pending SWINTRAWSTAT_1 No end of event interrupt...
  • Page 229 ON Semiconductor Bit Field Field Name Description End of deep sleep interrupt acknowledgment bit SLPINTACK Packet reception interrupt acknowledgment bit RXINTACK 625us base time reference interrupt acknowledgment bit CSCNTINTACK Field Name Value Symbol Value Description Hex Value 0x0* AUDIOINT2ACK AUDIOINT2ACK_0...
  • Page 230: Bb_Basetimecnt

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0x0* EVENTINTACK EVENTINTACK_0 Acknowledges the end of advertising / EVENTINTACK_1 scanning / connection interrupt. This bit resets SLPINTSTAT and SLPINTRAWSTAT flags 0x0* SLPINTACK SLPINTACK_0 Acknowledges the end of Sleep Mode SLPINTACK_1 interrupt.
  • Page 231: Bb_Bdaddru

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* BDADDRL BDADDRL_0 9.4.18 BB_BDADDRU Bit Field Field Name Description Bluetooth low energy device address privacy indicator PRIV_NPUB 15:0 Bluetooth low energy device address (MSB part) BDADDRU Field Name Value Symbol...
  • Page 232: Bb_Deepslwkup

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Bluetooth baseband core can be 0x0* EXTWKUPDSB EXTWKUPDSB_0 woken by external wakeup Bluetooth baseband core cannot be EXTWKUPDSB_1 woken up by external wakeup Bluetooth baseband core is not yet in...
  • Page 233: Bb_Enbpreset

    ON Semiconductor 9.4.23 BB_ENBPRESET Bit Field Field Name Description 20:10 Time in low power oscillator cycles allowed for stabilization of the high frequency TWOSC oscillator when the deep-Sleep Mode has been left due to sleep-timer expiry (DEEPSLWKUP-DEEPSLTIME]) Field Name Value Symbol...
  • Page 234: Bb_Diagstat

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Disable diagnostic port 3 output. All 0x0* DIAG3_EN DIAG3_EN_0 outputs are set to 0x0. Enable diagnostic port 3 output DIAG3_EN_1 Selection of the outputs that must be 0x0* DIAG3...
  • Page 235: Bb_Debugaddmin

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* REG_ADDMAX REG_ADDMAX_0 0x0* EM_ADDMAX EM_ADDMAX_0 9.4.29 BB_DEBUGADDMIN Bit Field Field Name Description 31:16 Lower limit for the register zone indicated by the reg_inzone flag REG_ADDMIN 15:0 Lower limit for the exchange memory zone indicated by the em_inzone flag...
  • Page 236 RSL10 Hardware Reference Bit Field Field Name Description Indicates anticipated pre-fetch mechanism error: happens when 2 consecutive EVT_SCHDL_APFM_ERROR events are programmed, and when the first event is not completely finished while second pre-fetch instant is reached Indicates event scheduler faced invalid timing programing on two consecutive EVT_SCHDL_ENTRY_ERROR ET entries (e.g first one with 624us offset and second one with no offset)
  • Page 237: Bb_Swprofiling

    ON Semiconductor Field Name Value Symbol Value Description Hex Value No error 0x0* WHITELIST_ERROR WHITELIST_ERROR_0 Error occurred WHITELIST_ERROR_1 No error 0x0* EVT_CNTL_APFM_ERROR EVT_CNTL_APFM_ERROR_0 Error occurred EVT_CNTL_APFM_ERROR_1 No error 0x0* EVT_SCHDL_APFM_ERROR EVT_SCHDL_APFM_ERROR_0 Error occurred EVT_SCHDL_APFM_ERROR_1 No error 0x0* EVT_SCHDL_ENTRY_ERROR EVT_SCHDL_ENTRY_ERROR_0 Error occurred...
  • Page 238: Bb_Radiocntl1

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value SPI pointer 0x0* SPIPTR SPIPTR_0 SPI clock is master1_gclk / 3 0x0* SPIFREQ SPIFREQ_0 SPIFREQ_1 SPIFREQ_2 SPIFREQ_3 Indicates SPI transfer in progress SPICOMP SPICOMP_0 Indicates SPI transfer is completed.
  • Page 239: Bb_Radiocntl2

    ON Semiconductor Field Name Value Symbol Value Description Hex Value No radio selected 0x0* XRFSEL XRFSEL_0 Integrated radio (Bluetooth low energy XRFSEL_3 technology) SUBVERSION Current RFFE revision SUBVERSION_3 9.4.34 BB_RADIOCNTL2 Bit Field Field Name Description 15:0 Frequency table pointer FREQTABLE_PTR...
  • Page 240: Bb_Radiotxrxtim0

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value 0x0* RXPWRUP1 RXPWRUP1_0 0x0* TXPWRDN1 TXPWRDN1_0 0x0* TXPWRUP1 TXPWRUP1_0 9.4.37 BB_RADIOTXRXTIM0 Bit Field Field Name Description 31:24 TXPATHDLY0 20:16 RXPATHDLY0 14:8 RFRXTMDA0 SYNC_POSITION0 Field Name Value Symbol Value Description...
  • Page 241: Bb_Spiptrcntl1

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* TXOFFPTR TXOFFPTR_0 0x0* TXONPTR TXONPTR_0 9.4.40 BB_SPIPTRCNTL1 Bit Field Field Name Description 31:16 Pointer to the RxOFF sequence address section RXOFFPTR 15:0 Pointer to the RxON sequence address section...
  • Page 242: Bb_Actscanstat

    RSL10 Hardware Reference 9.4.44 BB_ACTSCANSTAT Bit Field Field Name Description 24:16 Active scan mode back-off counter initialization value BACKOFF Active scan mode upper limit counter value UPPERLIMIT Field Name Value Symbol Value Description Hex Value 0x1* BACKOFF BACKOFF_1 0x1* UPPERLIMIT UPPERLIMIT_1 9.4.45 BB_WLPUBADDPTR...
  • Page 243: Bb_Aescntl

    ON Semiconductor 9.4.48 BB_AESCNTL Bit Field Field Name Description Cipher mode control AES_MODE Starts AES-128 ciphering/deciphering process AES_START Field Name Value Symbol Value Description Hex Value Cipher mode 0x0* AES_MODE AES_MODE_0 Decipher mode AES_MODE_1 0x0* AES_START AES_START_0 Starts AES-128 ciphering/deciphering...
  • Page 244: Bb_Aeskey127_96

    RSL10 Hardware Reference 9.4.52 BB_AESKEY127_96 Bit Field Field Name Description 31:0 AES encryption 128-bit key (bits 127 down to 96) AESKEY127_96 Field Name Value Symbol Value Description Hex Value 0x0* AESKEY127_96 AESKEY127_96_0 9.4.53 BB_AESPTR Bit Field Field Name Description 15:0...
  • Page 245: Bb_Rftesttxstat

    ON Semiconductor Bit Field Field Name Description Applicable only in Tx/Rx RF Test Mode TXLENGTHSRC Applicable only in Tx/Rx RF Test Mode PRBSTYPE Applicable only in Tx/Rx RF Test Mode TXPLDSRC Applicable in RF Test Mode only TXPKTCNTEN Tx packet length in number of bytes...
  • Page 246: Bb_Rftestrxstat

    RSL10 Hardware Reference 9.4.58 BB_RFTESTRXSTAT Bit Field Field Name Description 31:0 Reports number of correctly received packets during test modes RXPKTCNT Field Name Value Symbol Value Description Hex Value 0x0* RXPKTCNT RXPKTCNTX_0 9.4.59 BB_TIMGENCNTL Bit Field Field Name Description Controls the anticipated pre-fetch abort mechanism...
  • Page 247: Bb_Coexifcntl0

    ON Semiconductor 9.4.62 BB_COEXIFCNTL0 Bit Field Field Name Description 25:24 Determines how mws_scan_frequency impacts Bluetooth low energy MWSSCANFREQMSK technology Tx and Rx 21:20 Defines Bluetooth low energy technology packet ble_rx mode behavior WLCRXPRIOMODE 17:16 Defines Bluetooth low energy technology packet ble_tx mode behavior...
  • Page 248 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Tx indication excluding Tx power up 0x0* WLCTXPRIOMODE WLCTXPRIOMODE_0 delay Tx indication including Tx power up WLCTXPRIOMODE_1 delay Tx High priority indicator WLCTXPRIOMODE_2 WLCTXPRIOMODE_3 mws Tx Frequency has no impact...
  • Page 249: Bb_Coexifcntl1

    ON Semiconductor Field Name Value Symbol Value Description Hex Value tx has no impact 0x0* TXMSK TXMSK_0 tx can stop Bluetooth low energy TXMSK_1 technology Tx, no impact on Bluetooth low energy technology Rx tx can stop Bluetooth low energy...
  • Page 250: Bb_Coexifcntl2

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value If ble_pti[3:0] output value is greater 0x0* WLCPRXTHR WLCPRXTHR_0 than WLCPRXTHR, then Rx Bluetooth low energy technology priority is considered as high, and must be provided to the RF coexistence...
  • Page 251: Bb_Bbmprio1

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x3* BLEM7 BLEM7_3 0x4* BLEM6 BLEM6_4 0x8* BLEM5 BLEM5_8 0x9* BLEM4 BLEM4_9 0xA* BLEM3 BLEM3_10 0xD* BLEM2 BLEM2_13 0xE* BLEM1 BLEM1_14 0xF* BLEM0 BLEM0_15 9.4.66 BB_BBMPRIO1 Bit Field Field Name...
  • Page 252: Bb_Ral_Local_Rnd

    RSL10 Hardware Reference 9.4.69 BB_RAL_LOCAL_RND Bit Field Field Name Description Writing a 1 initializes of local RPA random number generation LFSR LRND_INIT 21:0 Initialization value for local RPA random generation when LRDN_INIT is set to 1, LRND_VAL else reports the current Local RPA random number LFSR value...
  • Page 253: Bb_Isomutecntl0

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Audio Mode 0 0x0* ISOTYPE0 ISOTYPE0_0 Reserved ISOTYPE0_1 Reserved ISOTYPE0_2 Reserved ISOTYPE0_3 9.4.72 BB_ISOMUTECNTL0 Bit Field Field Name Description Indicates which buffer is in use (direct copy of ET-ISOBUFSEL) TOGO0...
  • Page 254: Bb_Isocurrentrxptr0

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Tx ISO Buffer pointer 0 of ISO Channel 0x0* ISO0TXPTR0 ISO0TXPTR0_0 Tx ISO Buffer pointer 1 of ISO Channel 0x0* ISO0TXPTR1 ISO0TXPTR1_0 9.4.74 BB_ISOCURRENTRXPTR0 Bit Field Field Name Description...
  • Page 255: Bb_Isochancntl1

    ON Semiconductor Field Name Value Symbol Value Description Hex Value 0x0* EVT_CNT_OFFSETU0 EVT_CNT_OFFSETU0_0 9.4.78 BB_ISOCHANCNTL1 Bit Field Field Name Description Generate Tx ACK RETXACKEN1 Enable audio syn_p generation SYNCGEN1 Enable ISO channel ISOCHANEN1 ISO Channel Type ISOTYPE1 Field Name Value Symbol...
  • Page 256: Bb_Isocurrenttxptr1

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Do not mute on bad reception of an 0x0* MUTE_SINK1 MUTE_SINK1_0 ISO packet Mute after data or bad reception, with MUTE_SINK1_1 the pattern stored in MUTE_PATTERN0 Provides Source buffer to the Packet...
  • Page 257: Bb_Isotrcnl1

    ON Semiconductor 9.4.82 BB_ISOTRCNL1 Bit Field Field Name Description 23:16 Negotiated, maximum expected number of bytes for ISO Channel 0 Rx payloads ISO1RXLEN Negotiated, number of bytes for ISO Channel 0 Tx payloads ISO1TXLEN Field Name Value Symbol Value Description...
  • Page 258: Bb_Isomutecntl2

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Disable ISO Channel (LLID=0 invalid) 0x0* ISOCHANEN2 ISOCHANEN2_0 Enable ISO Channel (LLID=0 valid) ISOCHANEN2_1 Audio Mode 0 0x0* ISOTYPE2 ISOTYPE2_0 Reserved ISOTYPE2_1 Reserved ISOTYPE2_2 Reserved ISOTYPE2_3 9.4.86 BB_ISOMUTECNTL2 Bit Field...
  • Page 259: Bb_Isocurrenttxptr2

    ON Semiconductor 9.4.87 BB_ISOCURRENTTXPTR2 Bit Field Field Name Description 31:16 Tx ISO Buffer pointer 0 of ISO Channel 2 ISO2TXPTR0 15:0 Tx ISO Buffer pointer 1 of ISO Channel 2 ISO2TXPTR1 Field Name Value Symbol Value Description Hex Value Tx ISO Buffer pointer 0 of ISO Channel...
  • Page 260: Bb_Isoevtcntloffsetu2

    RSL10 Hardware Reference 9.4.91 BB_ISOEVTCNTLOFFSETU2 Bit Field Field Name Description MSB part of EVT_CNT_OFFSET2[39:0] field EVT_CNT_OFFSETU2 Field Name Value Symbol Value Description Hex Value 0x0* EVT_CNT_OFFSETU2 EVT_CNT_OFFSETU2_0 9.4.92 BB_BBPRIOSCHARB Bit Field Field Name Description Determine Bluetooth low energy technology priority scheduling arbitration mode...
  • Page 261: Digital Input/Output

    CHAPTER 10 Digital Input/Output 10.1 O VERVIEW The RSL10 system contains 16 digital input/output (DIO) pads that can be configured: • To support the external interfaces, output clocks, and other I/Os • As general-purpose I/Os controllable from the core DIOs support all digital inputs and output functions that are not supported directly by a dedicated I/O. For more information about the functional configuration of DIO pads, see Section 10.2, “Functional Configuration”...
  • Page 262 RSL10 Hardware Reference In addition to standard digital functional configuration, certain DIOs can be configured for special modes. These special modes are described in Section 10.2.1, “Special Functional Configurations” on page 264. CAUTION: While a DIO can be configured to be both an output and an input, it is the user application's responsibility to ensure that the DIO is not driving an output to a pad that is also being driven externally.
  • Page 263 ON Semiconductor Table 18. DIO Multiplexed Functionality (Continued) Mode Setting Description 0x1F Baseband SPI chip select output DIO_MODE_BB_SPI_CSN 0x20 Baseband SPI clock output DIO_MODE_BB_SPI_CLK 0x21 Baseband SPI serial output signal (MOSI) DIO_MODE_BB_SPI_MOSI 0x22 Baseband debug signal 0 DIO_MODE_BB_DBG0_0 0x23 Baseband debug signal 1...
  • Page 264: Special Functional Configurations

    LPDSP32 JTAG Test Mode select input selection LPDSP32_JTAG_TMS LPDSP32 JTAG test clock selection LPDSP32_JTAG_TCK 10.2.1 Special Functional Configurations RSL10 contains two special functional configurations that affect a subset of the DIOs. These special functional configurations are described in Table 20. www.onsemi.com...
  • Page 265: Physical Configuration

    DIO_JTAG_SW_PAD_CFG 10.3 P HYSICAL ONFIGURATION The RSL10 system includes physical configuration parameters for each DIO. These parameters are set using configuration bits from the appropriate register. DIO_CFG_* If the DIO is configured as an input pad, it has the following configuration options: •...
  • Page 266: Dio Registers

    RSL10 Hardware Reference • bit allows you to select the drive strength for the DIO output. DIO_CFG_DRIVE NOTE: The bit-field from the register can be used to increase the DIO_PAD_CFG_DRIVE DIO_PAD_CFG drive strength of all outputs by 50% or more if needed for a user application.
  • Page 267 ON Semiconductor Field Name Value Symbol Value Description Hex Value 2x drive strength DRIVE DIO_2X_DRIVE 3x drive strength DIO_3X_DRIVE 5x drive strength DIO_5X_DRIVE 6x drive strength 0x3* DIO_6X_DRIVE Disable low pass filter 0x0* DIO_LPF_DISABLE Enable low pass filter DIO_LPF_ENABLE No pull selected...
  • Page 268 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Output STANDBYCLK signal 0x1B (continued) IO_MODE DIO_MODE_STANDBYCLK Output baseband controller Tx data 0x1C DIO_MODE_BB_TX_DATA signal Output baseband controller Tx data 0x1D DIO_MODE_BB_TX_DATA_VALID valid signal Output baseband controller 0x1E DIO_MODE_BB_SYNC_P...
  • Page 269: Dio_Data

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Output RF front-end GPIO8 output 0x33 (continued) IO_MODE DIO_MODE_RF_GPIO8 signal Output RF front-end GPIO9 output 0x34 DIO_MODE_RF_GPIO9 signal Output the DMIC clock signal 0x35 DIO_MODE_DMIC_CLK Output audio synchronization pulse 0x36...
  • Page 270 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value DIO pad is low 0x0* DIO0_LOW DIO pad is low 0x0* DIO1_LOW DIO pad is low 0x0* DIO2_LOW DIO pad is low 0x0* DIO3_LOW DIO pad is low 0x0*...
  • Page 271 ON Semiconductor Field Name Value Symbol Value Description Hex Value Set the DIO pad to low if IO_MODE is (continued) GPIO GPIO4_LOW 0b0000XX Set the DIO pad to low if IO_MODE is GPIO5_LOW 0b0000XX Set the DIO pad to low if IO_MODE is...
  • Page 272: Dio_Dir

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Set the DIO pad to high if IO_MODE is 0x1000 (continued) GPIO GPIO12_HIGH 0b0000XX Set the DIO pad to high if IO_MODE is 0x2000 GPIO13_HIGH 0b0000XX Set the DIO pad to high if IO_MODE is...
  • Page 273 ON Semiconductor Field Name Value Symbol Value Description Hex Value DIO is an input 0x0* DIO0_INPUT DIO is an input 0x0* DIO1_INPUT DIO is an input 0x0* DIO2_INPUT DIO is an input 0x0* DIO3_INPUT DIO is an input 0x0* DIO4_INPUT...
  • Page 274 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Set DIO to input if IO_MODE is (continued) GPIO GPIO4_INPUT 0b0000XX Set DIO to input if IO_MODE is GPIO5_INPUT 0b0000XX Set DIO to input if IO_MODE is GPIO6_INPUT 0b0000XX...
  • Page 275: Dio_Mode

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Set DIO to output if IO_MODE is 0x1000 (continued) GPIO GPIO12_OUTPUT 0b0000XX Set DIO to output if IO_MODE is 0x2000 GPIO13_OUTPUT 0b0000XX Set DIO to output if IO_MODE is 0x4000...
  • Page 276: Dio_Int_Cfg

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value This DIO is not configured as a ARM 0x0* (continued) GPIO DIO15_IS_NOT_GPIO Cortex-M3 core controlled GPIO This DIO is configured as a ARM DIO0_IS_GPIO Cortex-M3 core controlled GPIO This DIO is configured as a ARM...
  • Page 277: Dio_Int_Debounce

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Interrupt not triggered 0x0* EVENT DIO_EVENT_NONE Interrupt triggered on high state DIO_EVENT_HIGH_LEVEL Interrupt triggered on low state DIO_EVENT_LOW_LEVEL Interrupt triggered on rising edge DIO_EVENT_RISING_EDGE Interrupt triggered on falling edge DIO_EVENT_FALLING_EDGE...
  • Page 278: Dio_Pcm_Src

    RSL10 Hardware Reference 10.4.7 DIO_PCM_SRC Bit Field Field Name Description 20:16 PCM_SERI input selection SERI 12:8 PCM_FRAME input selection FRAME PCM_CLK input selection Field Name Value Symbol Value Description Hex Value Select DIO[0] as source SERI PCM_SERI_SRC_DIO_0 Select DIO[1] as source...
  • Page 279 ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source FRAME PCM_FRAME_SRC_DIO_0 Select DIO[1] as source PCM_FRAME_SRC_DIO_1 Select DIO[2] as source PCM_FRAME_SRC_DIO_2 Select DIO[3] as source PCM_FRAME_SRC_DIO_3 Select DIO[4] as source PCM_FRAME_SRC_DIO_4 Select DIO[5] as source...
  • Page 280: Dio_Spi_Src

    RSL10 Hardware Reference 10.4.8 DIO_SPI_SRC Bit Field Field Name Description 20:16 SPI_SERI input selection SERI 12:8 SPI_CS input selection SPI_CLK input selection Field Name Value Symbol Value Description Hex Value Select DIO[0] as source SERI SPI_SERI_SRC_DIO_0 Select DIO[1] as source...
  • Page 281 ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source SPI_CS_SRC_DIO_0 Select DIO[1] as source SPI_CS_SRC_DIO_1 Select DIO[2] as source SPI_CS_SRC_DIO_2 Select DIO[3] as source SPI_CS_SRC_DIO_3 Select DIO[4] as source SPI_CS_SRC_DIO_4 Select DIO[5] as source SPI_CS_SRC_DIO_5...
  • Page 282: Dio_Uart_Src

    RSL10 Hardware Reference 10.4.9 DIO_UART_SRC Bit Field Field Name Description UART_RX input selection Field Name Value Symbol Value Description Hex Value Select DIO[0] as source UART_RX_SRC_DIO_0 Select DIO[1] as source UART_RX_SRC_DIO_1 Select DIO[2] as source UART_RX_SRC_DIO_2 Select DIO[3] as source...
  • Page 283 ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source SDA_SRC_DIO_0 Select DIO[1] as source SDA_SRC_DIO_1 Select DIO[2] as source SDA_SRC_DIO_2 Select DIO[3] as source SDA_SRC_DIO_3 Select DIO[4] as source SDA_SRC_DIO_4 Select DIO[5] as source SDA_SRC_DIO_5...
  • Page 284: Dio_Audiosink_Src

    RSL10 Hardware Reference 10.4.11 DIO_AUDIOSINK_SRC Bit Field Field Name Description Audio sink clock input selection Field Name Value Symbol Value Description Hex Value Select DIO[0] as source AUDIOSINK_CLK_SRC_DIO_0 Select DIO[1] as source AUDIOSINK_CLK_SRC_DIO_1 Select DIO[2] as source AUDIOSINK_CLK_SRC_DIO_2 Select DIO[3] as source...
  • Page 285: Dio_Bb_Rx_Src

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source NMI_SRC_DIO_0 Select DIO[1] as source NMI_SRC_DIO_1 Select DIO[2] as source NMI_SRC_DIO_2 Select DIO[3] as source NMI_SRC_DIO_3 Select DIO[4] as source NMI_SRC_DIO_4 Select DIO[5] as source NMI_SRC_DIO_5...
  • Page 286 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Select DIO[0] as source RF_SYNC_P BB_RF_SYNC_P_SRC_DIO_0 Select DIO[1] as source BB_RF_SYNC_P_SRC_DIO_1 Select DIO[5] as source BB_RF_SYNC_P_SRC_DIO_2 Select DIO[3] as source BB_RF_SYNC_P_SRC_DIO_3 Select DIO[4] as source BB_RF_SYNC_P_SRC_DIO_4 Select DIO[5] as source...
  • Page 287 ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source BB_RX_CLK_SRC_DIO_0 Select DIO[1] as source BB_RX_CLK_SRC_DIO_1 Select DIO[2] as source BB_RX_CLK_SRC_DIO_2 Select DIO[3] as source BB_RX_CLK_SRC_DIO_3 Select DIO[4] as source BB_RX_CLK_SRC_DIO_4 Select DIO[5] as source BB_RX_CLK_SRC_DIO_5...
  • Page 288: Dio_Bb_Spi_Src

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Select DIO[0] as source DATA BB_RX_DATA_SRC_DIO_0 Select DIO[1] as source BB_RX_DATA_SRC_DIO_1 Select DIO[2] as source BB_RX_DATA_SRC_DIO_2 Select DIO[3] as source BB_RX_DATA_SRC_DIO_3 Select DIO[4] as source BB_RX_DATA_SRC_DIO_4 Select DIO[5] as source...
  • Page 289: Dio_Rf_Spi_Src

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source MISO BB_SPI_MISO_SRC_DIO_0 Select DIO[1] as source BB_SPI_MISO_SRC_DIO_1 Select DIO[2] as source BB_SPI_MISO_SRC_DIO_2 Select DIO[3] as source BB_SPI_MISO_SRC_DIO_3 Select DIO[4] as source BB_SPI_MISO_SRC_DIO_4 Select DIO[5] as source...
  • Page 290 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Select DIO[0] as source MOSI RF_SPI_MOSI_SRC_DIO_0 Select DIO[1] as source RF_SPI_MOSI_SRC_DIO_1 Select DIO[2] as source RF_SPI_MOSI_SRC_DIO_2 Select DIO[3] as source RF_SPI_MOSI_SRC_DIO_3 Select DIO[4] as source RF_SPI_MOSI_SRC_DIO_4 Select DIO[5] as source...
  • Page 291 ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source RF_SPI_CSN_SRC_DIO_0 Select DIO[1] as source RF_SPI_CSN_SRC_DIO_1 Select DIO[2] as source RF_SPI_CSN_SRC_DIO_2 Select DIO[3] as source RF_SPI_CSN_SRC_DIO_3 Select DIO[4] as source RF_SPI_CSN_SRC_DIO_4 Select DIO[5] as source RF_SPI_CSN_SRC_DIO_5...
  • Page 292: Dio_Rf_Gpio03_Src

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Select DIO[0] as source RF_SPI_CLK_SRC_DIO_0 Select DIO[1] as source RF_SPI_CLK_SRC_DIO_1 Select DIO[2] as source RF_SPI_CLK_SRC_DIO_2 Select DIO[3] as source RF_SPI_CLK_SRC_DIO_3 Select DIO[4] as source RF_SPI_CLK_SRC_DIO_4 Select DIO[5] as source...
  • Page 293 ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source GPIO3 RF_GPIO3_SRC_DIO_0 Select DIO[1] as source RF_GPIO3_SRC_DIO_1 Select DIO[3] as source RF_GPIO3_SRC_DIO_2 Select DIO[3] as source RF_GPIO3_SRC_DIO_3 Select DIO[4] as source RF_GPIO3_SRC_DIO_4 Select DIO[5] as source...
  • Page 294 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Select DIO[0] as source GPIO2 RF_GPIO2_SRC_DIO_0 Select DIO[1] as source RF_GPIO2_SRC_DIO_1 Select DIO[2] as source RF_GPIO2_SRC_DIO_2 Select DIO[3] as source RF_GPIO2_SRC_DIO_3 Select DIO[4] as source RF_GPIO2_SRC_DIO_4 Select DIO[5] as source...
  • Page 295: Dio_Rf_Gpio47_Src

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source GPIO0 RF_GPIO0_SRC_DIO_0 Select DIO[1] as source RF_GPIO0_SRC_DIO_1 Select DIO[0] as source RF_GPIO0_SRC_DIO_2 Select DIO[3] as source RF_GPIO0_SRC_DIO_3 Select DIO[4] as source RF_GPIO0_SRC_DIO_4 Select DIO[5] as source...
  • Page 296 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Select DIO[0] as source GPIO7 RF_GPIO7_SRC_DIO_0 Select DIO[1] as source RF_GPIO7_SRC_DIO_1 Select DIO[5] as source RF_GPIO7_SRC_DIO_2 Select DIO[3] as source RF_GPIO7_SRC_DIO_3 Select DIO[4] as source RF_GPIO7_SRC_DIO_4 Select DIO[5] as source...
  • Page 297 ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source GPIO5 RF_GPIO5_SRC_DIO_0 Select DIO[1] as source RF_GPIO5_SRC_DIO_1 Select DIO[5] as source RF_GPIO5_SRC_DIO_2 Select DIO[3] as source RF_GPIO5_SRC_DIO_3 Select DIO[4] as source RF_GPIO5_SRC_DIO_4 Select DIO[5] as source...
  • Page 298: Dio_Rf_Gpio89_Src

    RSL10 Hardware Reference 10.4.18 DIO_RF_GPIO89_SRC Bit Field Field Name Description 12:8 RF front-end GPIO9 input selection GPIO9 RF front-end GPIO8 input selection GPIO8 Field Name Value Symbol Value Description Hex Value Select DIO[0] as source GPIO9 RF_GPIO9_SRC_DIO_0 Select DIO[1] as source...
  • Page 299: Dio_Dmic_Src

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Select DIO[0] as source GPIO8 RF_GPIO8_SRC_DIO_0 Select DIO[1] as source RF_GPIO8_SRC_DIO_1 Select DIO[5] as source RF_GPIO8_SRC_DIO_2 Select DIO[3] as source RF_GPIO8_SRC_DIO_3 Select DIO[4] as source RF_GPIO8_SRC_DIO_4 Select DIO[5] as source...
  • Page 300 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Select DIO[0] as source DMIC_CLK_SRC_DIO_0 Select DIO[1] as source DMIC_CLK_SRC_DIO_1 Select DIO[2] as source DMIC_CLK_SRC_DIO_2 Select DIO[3] as source DMIC_CLK_SRC_DIO_3 Select DIO[4] as source DMIC_CLK_SRC_DIO_4 Select DIO[5] as source...
  • Page 301: Dio_Lpdsp32_Jtag_Src

    ON Semiconductor 10.4.20 DIO_LPDSP32_JTAG_SRC Bit Field Field Name Description 20:16 LPDSP32_TDI input selection 12:8 LPDSP32_TMS input selection LPDSP32_TCK input selection Field Name Value Symbol Value Description Hex Value Select DIO[0] as source LPDSP32_TDI_SRC_DIO_0 Select DIO[1] as source LPDSP32_TDI_SRC_DIO_1 Select DIO[2] as source...
  • Page 302 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Select DIO[0] as source LPDSP32_TMS_SRC_DIO_0 Select DIO[1] as source LPDSP32_TMS_SRC_DIO_1 Select DIO[2] as source LPDSP32_TMS_SRC_DIO_2 Select DIO[3] as source LPDSP32_TMS_SRC_DIO_3 Select DIO[4] as source LPDSP32_TMS_SRC_DIO_4 Select DIO[5] as source...
  • Page 303: Dio_Jtag_Sw_Pad_Cfg

    ON Semiconductor 10.4.21 DIO_JTAG_SW_PAD_CFG Bit Field Field Name Description JTCK Low-Pass-Filter enable / disable JTCK_LPF JTMS Low-Pass-Filter enable / disable JTMS_LPF CM3 JTAG on DIO[14:15] CM3_JTAG_DATA_EN CM3 JTAG TRST on DIO13 CM3_JTAG_TRST_EN JTCK pull-up enable / disable JTCK_PULL JTMS drive strength...
  • Page 304: Dio_Pad_Cfg

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Disable low pass filter 0x0* EXTCLK_LPF_DISABLE Enable low pass filter EXTCLK_LPF_ENABLE No pull selected PULL_CTRL EXTCLK_NO_PULL Weak pull-up selected 0x1* EXTCLK_WEAK_PULL_UP Weak pull-down selected EXTCLK_WEAK_PULL_DOWN Strong pull-down selected EXTCLK_STRONG_PULL_UP 10.4.23 DIO_PAD_CFG...
  • Page 305: Interfaces

    IMPORTANT: For accurate ADC measurements across operating conditions, the VDDC supply voltage level must be a minimum of 1.00 V. For more information about VDDC configuration, see Section 5.3.4, “Digital Supply Voltages” on page 46, and the “Manufacturing Calibrated Settings” from the RSL10 Firmware Reference. 11.1.1 ADC Input Configuration The purpose of the ADCs is to sample analog signals that are relevant to the user’s application use cases—for...
  • Page 306 RSL10 Hardware Reference Low-Frequency Mode SLOWCLK is first prescaled by a fixed factor of 10, with a maximum sampling rate of 5 kHz. ADC measurement results have a resolution of 14 bits. High-Frequency Mode SLOWCLK is prescaled by a factor of 2, with sampling rates of up to 25 kHz where ADC measurement results have a resolution of 14 bits, or up to 50 kHz where ADC measurement results have a resolution of 8 bits.
  • Page 307: Adc Output Data

    2.0 V. Measurements outside of the range from 0 to 2.0 V can extend this range if the ADC sampling configuration extends the range of measured values. For improved accuracy in the ADC data, the RSL10 SoC provides an offset correction factor in the ADC_OFFSET register that automatically applies a compensation value to the measured ADC data.
  • Page 308: Adc And Power Supply Monitoring Interrupt

    RSL10 Hardware Reference 11.1.5 ADC and Power Supply Monitoring Interrupt A single interrupt line is shared between the ADC and the power supply monitoring circuitry. This interrupt can be independently configured to trigger when one or both of the following conditions are met: •...
  • Page 309: Adc_Input_Sel

    ON Semiconductor 11.1.6.3 ADC_INPUT_SEL Bit Field Field Name Description Positive input selection POS_INPUT_SEL Negative input selection NEG_INPUT_SEL Field Name Value Symbol Value Description Hex Value Select DIO0 as positive input POS_INPUT_SEL ADC_POS_INPUT_DIO0 Select DIO1 as positive input ADC_POS_INPUT_DIO1 Select DIO2 as positive input...
  • Page 310: Adc_Offset

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value ADC disabled 0x0* FREQ ADC_DISABLE Sample rate is SLOWCLK/200 (low ADC_PRESCALE_200 frequency mode) Sample rate is SLOWCLK/400 (low ADC_PRESCALE_400 frequency mode) Sample rate is SLOWCLK/640 (low ADC_PRESCALE_640 frequency mode)
  • Page 311: Adc_Batmon_Int_Enable

    ON Semiconductor Field Name Value Symbol Value Description Hex Value No Alarm is triggered 0x0* ALARM_COUNT_VALUE BATMON_ALARM_NONE Alarm count value is 1 BATMON_ALARM_COUNT1 Alarm count value is 255 0xFF BATMON_ALARM_COUNT255 Lowest voltage threshold: 7.8 mV SUPPLY_THRESHOLD SUPPLY_THRESHOLD_LOW Mid voltage threshold: 1 V...
  • Page 312: Adc_Batmon_Count_Val

    URPOSE NTERFACE RSL10 can configure any of the DIO pads as software-controlled general-purpose DIO (GPIO) pads. The function of these GPIO pads is defined by a user application, which can use them for any general-purpose input or output. register indicates which DIO pads have been configured for GPIO functionality; bits in this register...
  • Page 313: Gpio Interrupts

    ON Semiconductor The value observed at the digital input pads can be read from the register. This value is read as 0 for all DIO_DATA pads configured as ADC inputs (see Section 11.1, “Analog-to-Digital Converters (ADCs)”), because the digital input is not enabled in this mode.
  • Page 314 RSL10 Hardware Reference The example timing diagram shown in Figure 28 provides some information about the important elements in an I transaction, which are described in further detail in the previously mentioned bus specification. These elements are: Start Condition The SDA transitions from the idle high state to the low state while the SCL remains high. This can also happen during a transmission as a repeated start condition, which indicates that the transaction is starting again without an intermediate stop condition.
  • Page 315 ON Semiconductor Start Address Read/Write Acknowledge Data Acknowledge Data Not Acknowledge Stop Condition (Bits 0-6) (Bit 7) by Slave (Bits 0-7) by Master or (Bits 0-7) by Master Receiver; Condition Slave Acknowledge or Not Acknowledge by Slave Receiver Figure 28. I...
  • Page 316 RSL10 Hardware Reference Table 24. I C Event and State Status Bits Bit Field Field Name Bit Type Field Description Event Indicate if an error (I C bus or I C watchdog) has occurred. I2C_STATUS_ERROR_S is 0 when I2C_STATUS_ERROR_S I2C_ERROR_CNT contains 0 and is not 1.
  • Page 317: Slave Mode Specific Configuration

    ON Semiconductor Table 24. I C Event and State Status Bits (Continued) Bit Field Field Name Bit Type Field Description State Indicate the state of the Read/Write direction bit last sent or I2C_STATUS_READ_WRITE received. Transition out of this state occurs after a new Read/ Write direction bit is sent or received.
  • Page 318: Master Mode Specific Configuration

    RSL10 Hardware Reference transaction, the bit in the register can be queried to identify the addresses that I2C_STATUS_GEN_CALL I2C_STATUS were used to address the device. A device receiving data in a slave mode configuration can use the bit from the...
  • Page 319: I2C Interrupts

    ON Semiconductor 11.3.3 I C Interrupts The I C interface uses an associated interrupt which, when enabled, signals the receipt of a correct address byte and the completion of each data byte in the transaction. When enabled, the I C interrupt signals the stop condition following a transaction for a master transfer. The system...
  • Page 320: Operation Using Auto Acknowledgement

    RSL10 Hardware Reference NOTE: Use of the bits from the I2C_CTRL1_NACK I2C_CTRL1_ACK I2C_CTRL1_STOP_CMD register is only defined when an acknowledgement is needed during a data transfer. I2C_CTRL1 Interface behavior in response to these control bits being set at other times is undefined.
  • Page 321 ON Semiconductor Bit Field Field Name Description Select whether data transfer will be controlled by the ARM Cortex-M3 core or CONTROLLER the DMA for I2C Configure whether stop interrupts will be generated by the I2C interface STOP_INT_ENABLE Select whether acknowledgement is automatically generated or not...
  • Page 322: I2C_Ctrl1

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Require manual acknowledgement of 0x0* AUTO_ACK_ENABLE I2C_AUTO_ACK_DISABLE all I2C interface transfers Use automatic acknowledgement for I2C_AUTO_ACK_ENABLE I2C interface transfers Disable the I2C sample clock (I2C is 0x0* I2C_SAMPLE_CLK_ENABLE I2C_SAMPLE_CLK_DISABLE...
  • Page 323: I2C_Addr_Start

    ON Semiconductor 11.3.4.5 I2C_ADDR_START Bit Field Field Name Description I2C address to use for the transaction ADDRESS Select whether a read or a write transaction is started READ_WRITE Field Name Value Symbol Value Description Hex Value Start an I2C write transaction...
  • Page 324 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value No pending master start frame 0x0* START_PENDING I2C_START_NOT_PENDING A master frame is pending to start (bit I2C_START_PENDING is set when I2C_ADDR_START is written) I2C interface is not operating in master...
  • Page 325: Pulse Code Modulation (Pcm) Interface

    ODULATION NTERFACE RSL10 has access to a highly configurable pulse code modulation (PCM) interface that can be used to stream control, configuration or signal data into and out of the microcontroller. The PCM interface is multiplexed onto the DIO pads, which can be configured as the input and output signals that form the PCM interface with the necessary physical pad configuration.
  • Page 326: Pcm Signal Configuration

    RSL10 Hardware Reference Either the ARM Cortex-M3 processor or the DMA can control the data transferred by the PCM interface. Select the controller by configuring the bit in the register. PCM_CTRL_CONTROLLER PCM_CTRL IMPORTANT: The PCM interface configuration and internal status registers are tightly synchronized to the input PCM clock.
  • Page 327 ON Semiconductor be left in the default configuration (configured for two words per frame), regardless of the actual frame length used, to get the expected behavior. Alternately, if the bit is FRAME_SUBFRAMES configured to enable subframes, a frame signal is generated with every word of each data frame.
  • Page 328 RSL10 Hardware Reference Figure 30. Frame Signal Timing Examples www.onsemi.com...
  • Page 329: Data Serial Input And Output Configuration

    ON Semiconductor 11.4.1.2 Data Serial Input and Output Configuration The PCM interface allows data bits to be configured for transmission and reception in either an MSB to LSB ordering, or an LSB to MSB ordering. To select between these two configurations, set the...
  • Page 330 RSL10 Hardware Reference Table 25. Required Configuration Settings for I S Configuration Configuration Bit or Bit Field Setting PCM_CTRL_WORD_SIZE PCM_WORD_SIZE_16 PCM_CTRL_FRAME_LENGTH PCM_MULTIWORD_2 PCM_CTRL_FRAME_WIDTH PCM_FRAME_WIDTH_LONG PCM_CTRL_FRAME_ALIGN PCM_FRAME_ALIGN_LAST PCM_CTRL_BIT_ORDER PCM_BIT_ORDER_MSB_FIRST PCM_CTRL_FRAME_SUBFRAMES PCM_SUBFRAME_DISABLE PCM_CTRL_SLAVE PCM_SLAVE PCM_CTRL_PCM_CLK_POL PCM_SAMPLE_RISING_EDGE The PCM interface produces a data stream that complies with the I S standard with either sampling edge.
  • Page 331 ON Semiconductor Figure 31. Signal Timing Diagram: I S Configuration www.onsemi.com...
  • Page 332: Pcm Registers

    RSL10 Hardware Reference 11.4.4 PCM Registers Register Name Register Description Address PCM Control 0x40000A00 PCM_CTRL PCM Transmit Data 0x40000A04 PCM_TX_DATA PCM Receive Data 0x40000A08 PCM_RX_DATA PCM Status 0x40000A0C PCM_STATUS 11.4.4.1 PCM_CTRL Bit Field Field Name Description PCM clock polarity PCM_CLK_POL...
  • Page 333: Pcm_Tx_Data

    ON Semiconductor Field Name Value Symbol Value Description Hex Value The PCM frame is high for one PCM 0x0* FRAME_WIDTH PCM_FRAME_WIDTH_SHORT clock period The PCM frame is high for half of the PCM_FRAME_WIDTH_LONG frame length PCM frames contain 2 words...
  • Page 334: Pulse Width Modulation (Pwm)

    IDTH ODULATION The RSL10 system contains two pulse-width modulator (PWM) drivers that can be configured to generate a single output signal with a specified period and duty cycle. Each PWM driver can be used as independently as a simple D/A converter, or as a driver for an external audio sink.
  • Page 335: Pwm Registers

    ON Semiconductor PWM*CLK cycles of each period, to a maximum equal to the period of that PWM signal. After (PWM_CFG_PWM_HIGH + 1) PWM*CLK cycles, the PWM signal is low for the remainder of the period. NOTE: If the specified high time is greater than or equal to the specified period for a PWM, the PWM signal does not go low.
  • Page 336: Serial Peripheral Interfaces (Spi)

    ERIPHERAL NTERFACES The RSL10 system includes two Serial Peripheral Interfaces (SPI) that allow the system to communicate with external components including external analog front ends, external controllers, and non-volatile memories (NVM). The SPI interfaces are multiplexed onto the DIO pads, which can be configured as the input and output signals that form each SPI interface with the necessary physical pad configuration.
  • Page 337 ON Semiconductor   SYSCLK SPI*_CLK   NOTE: If , the output on the SPI*_SERO pad might be SYSCLK SPI*_CLK delayed by up to one SYSCLK period. For both master and slave mode, the bit in the SPI*_CTRL0_CLK_POLARITY SPI*_CTRL0 register is used to control both when data changes and when data is sampled.
  • Page 338: Spi Interrupts

    RSL10 Hardware Reference If the bit in the register is set, the SPI interface operates in auto mode SPI*_CTRL0_MODE_SELECT SPI*_CTRL0 to limit the overhead between SPI transfers. This mode works in conjunction with the SPI interface data registers. These registers are: Shift register containing the data to transmit using the SPI interface.
  • Page 339: Spi Dma Control

    ON Semiconductor 11.6.3 SPI DMA Control If using the DMA to control data transfers over an SPI interface, transmit events are triggered on the completion of a data transmission and receive events are triggered on the completion of a received data word. There are two methods to ensure that the first DMA word is transferred: •...
  • Page 340 RSL10 Hardware Reference Bit Field Field Name Description Select the polarity of the SPI clock SPI0_CLK_POLARITY Select between manual and auto transaction handling modes for SPI master SPI0_MODE_SELECT transactions Enable/disable the SPI interface SPI0_ENABLE Prescale the SPI interface clock for master transfers...
  • Page 341: Spi0_Ctrl1

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Prescale the SPI interface clock by 2 0x0* SPI0_PRESCALE SPI0_PRESCALE_2 Prescale the SPI interface clock by 4 SPI0_PRESCALE_4 Prescale the SPI interface clock by 8 SPI0_PRESCALE_8 Prescale the SPI interface clock by 16...
  • Page 342: Spi0_Tx_Data

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value SPI transfers use 1-bit words 0x0* SPI0_WORD_SIZE SPI0_WORD_SIZE_1 SPI transfers use 8-bit words SPI0_WORD_SIZE_8 SPI transfers use 16-bit words SPI0_WORD_SIZE_16 SPI transfers use 24-bit words 0x17 SPI0_WORD_SIZE_24 SPI transfers use 32-bit words...
  • Page 343: Spi1_Ctrl0

    ON Semiconductor 11.6.4.6 SPI1_CTRL0 Bit Field Field Name Description Enable/disable SPI overrun interrupts SPI1_OVERRUN_INT_ENABLE Enable/disable SPI underrun interrupts SPI1_UNDERRUN_INT_ENABLE Select whether data transfer will be controlled by the ARM Cortex-M3 core or SPI1_CONTROLLER the DMA for SPI Use the SPI interface as master or slave...
  • Page 344: Spi1_Ctrl1

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Prescale the SPI interface clock by 2 0x0* SPI1_PRESCALE SPI1_PRESCALE_2 Prescale the SPI interface clock by 4 SPI1_PRESCALE_4 Prescale the SPI interface clock by 8 SPI1_PRESCALE_8 Prescale the SPI interface clock by 16...
  • Page 345: Spi1_Tx_Data

    ON Semiconductor 11.6.4.8 SPI1_TX_DATA Bit Field Field Name Description 31:0 Single word buffer for data to be transmitted over the SPI interface SPI1_TX_DATA 11.6.4.9 SPI1_RX_DATA Bit Field Field Name Description 31:0 Single word buffer for data that has been received over the SPI interface SPI1_RX_DATA 11.6.4.10 SPI1_STATUS...
  • Page 346 RSL10 Hardware Reference The UART interface can be enabled or disabled using the bit in the appropriate UART_CFG_ENABLE UART_CTRL register. When disabled the UART interface will immediately terminate any ongoing transfer, and setting the UART transmit line high and ignoring any partially received receive data.
  • Page 347: Uart Interrupts

    ON Semiconductor 11.7.1 UART Interrupts The UART interface uses three associated interrupts that separately control transmission and reception of UART data and handling of UART transmission errors. Section 14.1, “Nested Vectored Interrupt Controller (NVIC)” on page 401 for information regarding interrupt configuration and handling.
  • Page 348: Uart_Tx_Data

    For more information on DIO configuration, see Chapter 10, “Digital Input/Output” on page 261. Figure 34 on page 349 shows how these interfaces (and their DIO connections) are connected internally on the RSL10 SoC, and Table 26 provides a description of these connections.
  • Page 349 ON Semiconductor Figure 34. Interface between the Baseband Controller and the RF Front-End www.onsemi.com...
  • Page 350 RSL10 Hardware Reference Table 26. Interface signals between the baseband controller and the RF front-end Baseband Signal RF Front-end Signal Source Description BB_SPI_MISO RF_SPI_MISO RF Front-end SPI data slave to master BB_SPI_MOSI RF_SPI_MOSI Baseband SPI data master to slave BB_SPI_CLK...
  • Page 351: Peripherals

    CHAPTER 12 Peripherals 12.1 C (CRC) G YCLIC EDUNDANCY HECK ENERATOR The peripherals to the ARM Cortex-M3 processor include a CRC generator that provides support for two standard cyclic redundancy check (CRC) algorithms (CRC-CCITT and CRC-32, defined by the IEEE 802.3 Ethernet standard).
  • Page 352: Crc Registers

    RSL10 Hardware Reference The ARM Cortex-M3 processor’s CRC generator supports non-standard variants of the CRC-CCITT and CRC-32 standard implementation. • To use non-standard CRC ordering of data within each data byte, set the bit from the CRC_CTRL_BIT_ORDER register. CRC_CTRL •...
  • Page 353: Crc_Value

    ON Semiconductor Field Name Value Symbol Value Description Hex Value Final CRC XOR is done according to 0x0* FINAL_CRC_XOR CRC_FINAL_XOR_STANDARD the standard (CRC-CCITT: no XOR; CRC-32: XOR with 0xFFFFFFFF) Final CRC XOR is done in opposite of CRC_FINAL_XOR_NON_STANDARD the standard...
  • Page 354: Crc_Add_16

    RSL10 Hardware Reference 12.1.1.5 CRC_ADD_16 Bit Field Field Name Description 15:0 Add 1 half-word (16 bits) to the CRC calculation CRC_ADD_16 12.1.1.6 CRC_ADD_24 Bit Field Field Name Description 23:0 Add 3 bytes (24 bits) to the CRC calculation CRC_ADD_24_BITS 12.1.1.7 CRC_ADD_32...
  • Page 355: Dma Channel Configuration

    ON Semiconductor 12.2.2 DMA Channel Configuration The DMA has eight independently configurable channels. To enable or disable a DMA channel, configure the bit from the appropriate register. If the DMA channel is in the midst of an operation DMA_CTRL0_ENABLE DMA_CTRL0 when it is disabled, the operation is aborted.
  • Page 356 RSL10 Hardware Reference a peripheral as the destination typically have destination incrementing disabled. Conversely, transfers that use memory as the destination typically have destination incrementing enabled. If the address is incremented, the increment can be configured to be positive or negative, and to...
  • Page 357: Word Size, Data Packing And Transfer Length

    ON Semiconductor Interrupt Configuration The interrupts used to coordinate with, and control, a DMA transfer can be defined using the bits from the DMA channel’s register. For more DMA_CTRL0_*_INT_ENABLE DMA_CTRL0 information, see Section 12.2.5, “DMA Interrupt Configuration” on page 364.
  • Page 358 RSL10 Hardware Reference For example, when reading 8-bit bytes from the I C interface and storing them to data memory, four 8-bit data words from the I C interface are packed before they are written to memory. In this example, it is most efficient to make the destination word size 32 bits to minimize bus utilization and maximize memory use efficiency.
  • Page 359 ON Semiconductor Word size Source Data Destination Data SRC DEST Big Endian Little Endian H G F E D C B A s H G F E D C B A d H G F E D C B A d...
  • Page 360: Transfer Length

    RSL10 Hardware Reference For memory-to-peripheral transfers, the counter in the DMA channel always operates on the peripheral’s word size. For peripheral-to-memory, peripheral-to-peripheral and memory-to-memory transfers, the counter in the DMA channel always operates on the source’s word size. The next address for reading or writing can be determined from: •...
  • Page 361 ON Semiconductor Table 30. Valid Sources of DMA Data Source Encoded Bits SPI 0 SPI 1 UART ASRC PBUS DMIC Each source interface or peripheral, when configured for DMA operation, asserts its DMA request signal when data can be read from the interface. This signal is cleared automatically when a data value is read from the interface using the peripheral bus.
  • Page 362: Memory-To-Memory (Mm)

    RSL10 Hardware Reference IMPORTANT: Due to the structure of the SPI interfaces, when a user application initializes a transmit transfer using an SPI interface controlled by a DMA channel, the user application must preload the SPI interface’s transmit data register ( ) with the first data word of the transfer.
  • Page 363: Peripheral-To-Memory (Pm)

    ON Semiconductor 10. The DMA releases the peripheral bus. 11. The DMA channel’s counter is incremented. 12. If the transfer length is not reached, the DMA channel waits for the next peripheral DMA request. If the transfer length is reached and the DMA is in linear mode, the DMA channel switches to the complete state. If the DMA is in circular mode, the DMA resets the counter to 0 and remains enabled.
  • Page 364: Dma Interrupt Configuration

    RSL10 Hardware Reference The DMA writes the word at the next destination address. 10. The DMA channel acknowledges the destination peripheral DMA request (implied by the previous write operation). 11. The DMA releases the peripheral bus. 12. The DMA channel’s counter is incremented.
  • Page 365: Channel Priority

    ON Semiconductor When using a circular DMA transfer, the counter interrupt and complete interrupt can be used in tandem to create a two-page buffer for continuous data transfers. When the first page has transferred, the counter interrupt triggers. When the second page has transferred, the complete interrupt triggers. In this configuration:...
  • Page 366: Dma Registers

    RSL10 Hardware Reference When the DMA is granted access to memory, it performs a single operation (read or write) and releases the processor data memory. This ensures that the DMA never blocks access to data memory from the processor for more than a single memory operation.
  • Page 367 ON Semiconductor Register Name Register Description Address DMA Channel Source Base Address 4 0x40000630 DMA_SRC_BASE_ADDR[4] DMA Channel Source Base Address 5 0x40000634 DMA_SRC_BASE_ADDR[5] DMA Channel Source Base Address 6 0x40000638 DMA_SRC_BASE_ADDR[6] DMA Channel Source Base Address 7 0x4000063C DMA_SRC_BASE_ADDR[7] DMA Channel Destination Base Address 0...
  • Page 368: Dma_Ctrl0

    RSL10 Hardware Reference Register Name Register Description Address DMA Channel Word Count 3 0x400006CC DMA_WORD_CNT[3] DMA Channel Word Count 4 0x400006D0 DMA_WORD_CNT[4] DMA Channel Word Count 5 0x400006D4 DMA_WORD_CNT[5] DMA Channel Word Count 6 0x400006D8 DMA_WORD_CNT[6] DMA Channel Word Count 7...
  • Page 369 ON Semiconductor Field Name Value Symbol Value Description Hex Value Set the step size of DMA channel to 1 0x0* DEST_ADDR_STEP_SIZE DMA_DEST_ADDR_STEP_SIZE_1 Set the step size of DMA channel to 2 DMA_DEST_ADDR_STEP_SIZE_2 Set the step size of DMA channel to 3...
  • Page 370 RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Source data uses 8-bit words 0x0* SRC_WORD_SIZE DMA_SRC_WORD_SIZE_8 Source data uses 16-bit words DMA_SRC_WORD_SIZE_16 Source data uses 32-bit words DMA_SRC_WORD_SIZE_32 Source data uses 4-bit words DMA_SRC_WORD_SIZE_4 Data writes are triggered by the I2C...
  • Page 371: Dma_Src_Base_Addr

    ON Semiconductor Field Name Value Symbol Value Description Hex Value DMA channel will provide a 0x0* TRANSFER_TYPE DMA_TRANSFER_M_TO_M memory-to-memory data transfer DMA channel will provide a DMA_TRANSFER_M_TO_P memory-to-peripheral data transfer DMA channel will provide a DMA_TRANSFER_P_TO_M peripheral-to-memory data transfer DMA channel will provide a...
  • Page 372: Dma_Next_Src_Addr

    RSL10 Hardware Reference 12.2.8.5 DMA_NEXT_SRC_ADDR The following bit fields and field names apply equally to all registers. DMA_NEXT_SRC_ADDR[*] Bit Field Field Name Description 31:0 Address of the next data to be transferred using DMA channel DMA_NEXT_SRC_ADDR 12.2.8.6 DMA_NEXT_DEST_ADDR The following bit fields and field names apply equally to all registers.
  • Page 373: Timers

    Indicate that a channel disable DISABLE_INT_STATUS DMA_DISABLE_INT_STATUS interrupt has occurred 12.3 T IMERS The RSL10 system provides five timers including: • The SysTick timer from the ARM Cortex-M3 processor, which is described in Section 14.2, “SysTick” on page 409 • Four general-purpose timers Each general-purpose timer provides: •...
  • Page 374: Starting Or Stopping Timers

    RSL10 Hardware Reference • bit is used to select between fixed initial division of slow clock by 2 or by 32 TIMER_CFG_CLK_SRC • bit field is used to increase the scaling factor by a power of two, allowing the TIMER_CFG_PRESCALE selection of a clock that is additionally divided by as much as 128 for each timer.
  • Page 375: Timer_Cfg

    ON Semiconductor Register Name Register Description Address Timer current value register 1 0x40000424 TIMER_VAL[1] Timer current value register 2 0x40000428 TIMER_VAL[2] Timer current value register 3 0x4000042C TIMER_VAL[3] 12.3.3.1 TIMER_CFG The following bit fields and field names apply equally to all ] registers.
  • Page 376: Timer_Ctrl

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Divide the input clock frequency by 1 0x0* PRESCALE TIMER_PRESCALE_1 Divide the input clock frequency by 2 TIMER_PRESCALE_2 Divide the input clock frequency by 4 TIMER_PRESCALE_4 Divide the input clock frequency by 8...
  • Page 377: Watchdog Registers

    ON Semiconductor The watchdog timer runs on a prescaled clock that has been derived from the slow clock using a fixed division of 1024. This clock is used to decrement the value in the watchdog’s 13-bit counter. When the watchdog timer is refreshed, a configurable number of bits in the 13-bit counter are set and the prescaling counter is reset.
  • Page 378: Watchdog_Ctrl

    RSL10 Hardware Reference 12.4.1.2 WATCHDOG_CTRL Bit Field Field Name Description 31:0 Write a key to reset the watchdog WATCHDOG_REFRESH Field Name Value Symbol Value Description Hex Value Write 32-bit key to reset the watchdog 0x2B1E211 WATCHDOG_REFRESH WATCHDOG_REFRESH (other values have no effect)
  • Page 379: Audio

    CHAPTER 13 Audio 13.1 D (DMIC) I IGITAL ICROPHONE NPUTS The DMIC block provides a serial audio interface for up to two channels, using a pulse density modulated (PDM) digital output stream. The DMIC input data is decimated in a two-step process: A filter supporting a decimation range between 8 and 36 is used.
  • Page 380 RSL10 Hardware Reference • bit-field defines the decimation rate applied to data input from the DMIC. The AUDIO_CFG_DEC_RATE decimation factor as a function of the register is as follows: AUDIO_CFG_DEC_RATE   Decimation Factor AUDIO_CFG_DEC_RATE + 8 • bit is used to select either clocking the DMIC input signal with the audio...
  • Page 381: Digital Microphone And Shared Digital Microphone/Output Driver Registers

    ON Semiconductor before it is overwritten with a subsequent sample. If an overrun has occurred, this flag remains set until the corresponding bit is used to clear it. AUDIO_STATUS_DMIC*_OVERRUN_FLAG_CLEAR Data received from the DMIC input samples is decimated into 18-bit samples, using a two-phase decimation filter.
  • Page 382 RSL10 Hardware Reference Bit Field Field Name Description Data alignment in AUDIO_OD_DATA OD_DATA_ALIGN Enable output driver output OD_ENABLE Enable the DMA request when a new DMIC1 sample is ready DMIC1_DMA_REQ_EN Enable the interrupt generation when a new DMIC1 sample is ready...
  • Page 383: Audio_Status

    ON Semiconductor Field Name Value Symbol Value Description Hex Value OD_DATA is 16-bit LSB aligned 0x0* OD_DATA_ALIGN OD_DATA_LSB_ALIGNED OD_DATA is 18-bit MSB aligned OD_DATA_MSB_ALIGNED Disable the OD output 0x0* OD_ENABLE OD_DISABLE Enable the OD output OD_ENABLE Disable the DMA request when a...
  • Page 384: Audio_Dmic_Cfg

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Reset the OD underrun detection OD_UNDERRUN_FLAG_CLEAR OD_UNDERRUN_FLAG_CLEAR sticky bit Indicates that no OD underrun has 0x0* OD_UNDERRUN_FLAG OD_UNDERRUN_NOT_DETECTED been detected Indicates that an OD underrun has OD_UNDERRUN_DETECTED been detected...
  • Page 385 ON Semiconductor Field Name Value Symbol Value Description Hex Value Delay disabled 0x0* DMIC1_DELAY DMIC1_DELAY_DISABLE Delay of 0.125 samples DMIC1_DELAY_0P125 Delay of 0.25 samples DMIC1_DELAY_0P25 Delay of 0.375 samples DMIC1_DELAY_0P375 Delay of 0.5 samples DMIC1_DELAY_0P5 Delay of 0.625 samples DMIC1_DELAY_0P625 Delay of 0.75 samples...
  • Page 386: Audio_Dmic0_Gain

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value Cut-off frequency is Fs/3200 (5 Hz at 0x0* DMIC0_DCRM DMIC0_DCRM_CUTOFF_5HZ Fs=16 kHz) Cut-off frequency is Fs/1600 (10 Hz at DMIC0_DCRM_CUTOFF_10HZ Fs=16 kHz) Cut-off frequency is Fs/800 (20 Hz at...
  • Page 387: Audio_Dmic_Data

    UTPUT RIVER The output driver provides a mono digital audio output from the RSL10 system. This output driver can be connected to drive one or more DIO pairs, which are used as the driver for a speaker or receiver. The output driver consists of four stages:...
  • Page 388 This includes: AUDIO_STATUS • bit, which indicates if the output driver is included in this version of RSL10 AUDIO_STATUS_OD_STATUS • bit, which indicates when a new audio sample is required for the AUDIO_STATUS_OD_DATA_REQ_FLAG output driver.
  • Page 389: Output Driver Registers

    ON Semiconductor Table 32. Recommended Output Driver Configuration Register Bit Field Setting Notes Set supplied clock frequency to between 1 and 2 MHz (1 MHz for lowest power CLK_DIV1 AUDIOCLK_PRESCALE consumption, 2 MHz for lowest high frequency noise). AUDIOSLOWCLK_PRESCALE Prevent the output driver from driving...
  • Page 390: Audio_Od_Gain

    RSL10 Hardware Reference Field Name Value Symbol Value Description Hex Value DC removal filter disabled 0x0* DCRM DCRM_DISABLE Cut-off frequency is OD_CLK/800000 DCRM_CUTOFF_1P25HZ (1.25 Hz at OD_CLK=1 MHz) Cut-off frequency is OD_CLK/400000 DCRM_CUTOFF_2P5HZ (2.5 Hz at OD_CLK=1 MHz) Cut-off frequency is OD_CLK/266667 DCRM_CUTOFF_3P75HZ (3.75 Hz at OD_CLK=1 MHz)
  • Page 391: Audio_Od_Data

    +/-22 ppm can be achieved. An example employing the audio sink block for this use case can be seen in the calibration library, as described in the RSL10 Firmware Reference. The audio sink clock being measured is sourced from a DIO or from STANDBYCLK, as specified by the DIO configuration.
  • Page 392 RSL10 Hardware Reference AUDIOSINK_CNT[i-1] Audio si nk clock AUDIOSINK_PERIOD_CNT[i-1] BLE/RF frame pulse AUDIOSINK_PHASE_CNT[i-1] AUDIOSINK_PHASE_CNT[i] SY SCLK Figure 38. Audio Sink Timing The measurement registers are defined as follows: • register holds the integer number of cycles of the audio sink clock being measured AUDIOSINK_CNT between consecutive BLE/RF frame pulses.
  • Page 393: Audio Sink Registers

    ON Semiconductor • bit, which clears and starts the phase counter AUDIOSINK_CTRL_PHASE_CNT_START_NO_WAIT immediately. • bit, which stops the phase counter mechanism manually. AUDIOSINK_CTRL_PHASE_CNT_STOP • bit, which indicates whether the phase counter mechanism is AUDIOSINK_CTRL_PHASE_STATUS currently active or idle. • register, which contains the number of SYSCLK cycles between when the...
  • Page 394 RSL10 Hardware Reference Bit Field Field Name Description Stop the audio sink clock period counter mechanism PERIOD_CNT_STOP Start the audio sink clock period counter mechanism PERIOD_CNT_START Audio sink clock phase counter missed status PHASE_CNT_MISSED_STATUS Audio sink clock phase counter status...
  • Page 395: Audiosink_Cfg

    ON Semiconductor 13.3.1.2 AUDIOSINK_CFG Bit Field Field Name Description Defines over how many audio sink clock periods the period counter measures PERIODS_CFG Field Name Value Symbol Value Description Hex Value Measure 1 audio sink clock period 0x0* PERIODS_CFG AUDIO_SINK_PERIODS_1 Measure 2 audio sink clock periods...
  • Page 396 RSL10 Hardware Reference The ASRC is configured with the register. This register configures: ASRC_CFG • The ASRC operates in one of four modes, controlled by the setting. Use of these ASRC_CFG_ASRC_MODE modes is dependent on the relationship between the source (F...
  • Page 397: Asrc Registers

    ON Semiconductor • This 30-value register array holds the internal filter states of the polyphase filter. The ASRC_STATE_MEM: number of states that need to be stored depends on the setting, as outlined in Table 33 ASRC_CFG_ASRC_MODE on page 396. Data is provided to the ASRC through the register.
  • Page 398: Asrc_Int_Enable

    RSL10 Hardware Reference Bit Field Field Name Description Write a 1 to reset ASRC ASRC_RESET Enable status of the re-sampler block ASRC_EN_STATUS Disable the re-sampler block ASRC_DISABLE Enable the re-sampler block ASRC_ENABLE Field Name Value Symbol Value Description Hex Value...
  • Page 399: Asrc_Out

    ON Semiconductor Field Name Value Symbol Value Description Hex Value This source can not set an interrupt ASRC_UPDATE_ERR INT_DIS_ASRC_UPDATE_ERR This source can set the interrupt line 0x1* INT_EBL_ASRC_UPDATE_ERR This source can not set an interrupt 0x0* ASRC_IN_ERR INT_DIS_ASRC_IN_ERR This source can set the interrupt line...
  • Page 400: Asrc_Phase_Inc

    RSL10 Hardware Reference 13.4.1.7 ASRC_PHASE_INC Bit Field Field Name Description 31:0 ASRC phase counter increment step size ASRC_STEP 13.4.1.8 ASRC_PHASE_CNT Bit Field Field Name Description 31:0 ASRC phase counter ASRC_PHASE_CNT 13.4.1.9 ASRC_STATE_MEM Bit Field Field Name Description 31:0 ASRC State Memory 0 to 29 ASRC_STATE_MEM www.onsemi.com...
  • Page 401: Private Peripherals

    ARM Cortex-M3 processor and is described in the ARM Cortex-M3 Technical Reference Manual. The ARM Cortex-M3 processor as implemented for RSL10 uses pulse interrupts. These interrupts are sampled on the rising edge of SYSCLK. A pulse interrupt can be reasserted during the ISR so that the interrupt can be in the pending state and active at the same time.
  • Page 402 RSL10 Hardware Reference Table 34. Interrupts in the ARM Cortex-M3 Processor (Continued) Interrupt Enumeration Define Enumeration Value Vector Number Description DIO0_IRQn DIO0 interrupt DIO1_IRQn DIO1 interrupt DIO2_IRQn DIO2 interrupt DIO3_IRQn DIO3 interrupt WATCHDOG_IRQn Watchdog interrupt SPI0_RX_IRQn SPI0 receive interrupt SPI0_TX_IRQn...
  • Page 403 1 interrupt BLE_AUDIO2 Audio over Bluetooth low energy technology channel 2 interrupt Table 35 lists the NVIC registers. The following subsections describe their bit fields and use by the RSL10 microcontroller. Table 35. NVIC Control Registers Register Name Register Description...
  • Page 404 RSL10 Hardware Reference Table 35. NVIC Control Registers (Continued) Register Name Register Description Address NVIC External Interrupt Set Pending Register 1 0xE000E204 NVIC_ISPR1 NVIC External Interrupt Set Pending Register 2 0xE000E208 NVIC_ISPR2 NVIC External Interrupt Clear Pending Register 0 0xE000E280...
  • Page 405: Interrupt Controller Type Register

    Table 36. Interrupt Controller Type Register Bit Assignments Bit Field Field Name Description INTLINESNUM Total number of interrupt line groups: RSL10 uses 69 external interrupts (NVIC_INTLINESNUM_65_96, hex value 0x2) 14.1.2 Interrupt Set Enable and Clear Enable Registers Use the Interrupt Set Enable registers ( ) to:...
  • Page 406: Interrupt Set-Pending Registers And Interrupt Clear-Pending Registers

    RSL10 Hardware Reference These registers are part of the ARM Cortex-M3 processor’s register block. Table 37 describes the field of the NVIC Interrupt Set-Enable registers. Table 38 describes the field of the Interrupt Clear-Enable registers. Table 37. Interrupt Set-Enable Register Bit Assignments...
  • Page 407: Active Bit Register

    ARMv7M Architecture Reference Manual. The NVIC for the ARM Cortex-M3 processor in the RSL10 system has been implemented with four interrupt priority bits per interrupt. These four priority bits are MSB aligned to an eight-bit priority bit field as required by ARM.
  • Page 408 RSL10 Hardware Reference bit field from the Application Interrupt and Reset Control register (see the ARMv7M SCB_AIRCR_PRIGROUP Architecture Reference Manual) is used to divide the interrupt priority settings into interrupt groups, and to prioritize interrupts within those groups. The possible configurations for the division of the priority bit field into pre-emption priority and subgroup priority is shown in Table 42.
  • Page 409: Registers Described By Arm Documentation

    ON Semiconductor 14.1.6 Registers Described by ARM Documentation The following registers are documented in the ARMv7M Architecture Reference Manual: • Interrupt Control State register • Vector Table Offset register • Application Interrupt and Reset Control register • System Control register •...
  • Page 410: Systick Control And Configuration Registers

    RSL10 Hardware Reference 14.2.1 SysTick Control and Configuration Registers Register Name Register Description Address SYSTICK Control and Status Register 0xE000E010 SysTick_CTRL SYSTICK Reload Value Register 0xE000E014 SysTick_LOAD SYSTICK Current Value Register 0xE000E018 SysTick_VAL SYSTICK Calibration Register 0xE000E01C SysTick_CALIB IMPORTANT: The SysTick timer is a standard component provided with the ARM Cortex-M3 processor. The registers for this peripheral are defined in core_cm3.h and augmented by defines for the bit fields, bit settings...
  • Page 411: Debug Controller

    • To break a stalled memory access, where the memory access might be stalled due to a memory conflict with another component of the RSL10 system, set the bit. CoreDebug_DHCSR_C_SNAPALL The Debug Exception and Monitor Control Register (...
  • Page 412: Debug Monitor Configuration

    RSL10 Hardware Reference also provides a variety of debug related status information, including: DHCSR • If the core has been reset or is resetting ( ); this bit is cleared when read CoreDebug_DHCSR_S_RESET_ST • If an instruction has completed execution since this register has been last read; this bit is cleared when read •...
  • Page 413 ON Semiconductor 14.3.4 Debug Fault Status Register The Debug Fault Status register ( ) is used to monitor debug events including: DFSR • External debug requests • Vector catches • Data watchpoint matches • instruction execution BKPT • Halt requests Each flag in the Debug Fault Status register is set independently when its debug condition occurs.
  • Page 414 RSL10 Hardware Reference 14.3.5.1 SCB_DFSR Settings Bit Field Field Name Description EXTERNAL Indicate if an external debug request has been asserted. The processor stops on the next instruction boundary. VCATCH Indicate if a vector catch occurred. When the VCATCH flag is set, a flag in one of the local fault status registers is also set to indicate the type of fault.
  • Page 415 ON Semiconductor 14.3.5.4 Debug Exception and Monitor Control Register Bit Field Field Name Description MON_REQ Indicate if a debug monitor exception has been triggered by a pending manual request or a hardware debug event MON_STEP Single-step the core; this bit can only be written if the debug monitor exception is...
  • Page 416 APPENDIX A Control and Configuration Registers This appendix lists all the registers that are available. Refer to the appropriate section for information about the control and configuration registers for a block. The sections are: • Section A.1, “Chip Identification” on page 417 •...
  • Page 417 ON Semiconductor www.onsemi.com...
  • Page 418 RSL10 Hardware Reference www.onsemi.com...
  • Page 419 ON Semiconductor www.onsemi.com...
  • Page 420 RSL10 Hardware Reference www.onsemi.com...
  • Page 421 ON Semiconductor www.onsemi.com...
  • Page 422 RSL10 Hardware Reference www.onsemi.com...
  • Page 423 ON Semiconductor www.onsemi.com...
  • Page 424 RSL10 Hardware Reference www.onsemi.com...
  • Page 425 ON Semiconductor www.onsemi.com...
  • Page 426 RSL10 Hardware Reference www.onsemi.com...
  • Page 427 ON Semiconductor www.onsemi.com...
  • Page 428 RSL10 Hardware Reference www.onsemi.com...
  • Page 429 ON Semiconductor www.onsemi.com...
  • Page 430 RSL10 Hardware Reference www.onsemi.com...
  • Page 431 ON Semiconductor www.onsemi.com...
  • Page 432 RSL10 Hardware Reference www.onsemi.com...
  • Page 433 ON Semiconductor www.onsemi.com...
  • Page 434 RSL10 Hardware Reference www.onsemi.com...
  • Page 435 ON Semiconductor www.onsemi.com...
  • Page 436 RSL10 Hardware Reference www.onsemi.com...
  • Page 437 ON Semiconductor www.onsemi.com...
  • Page 438 RSL10 Hardware Reference www.onsemi.com...
  • Page 439 ON Semiconductor www.onsemi.com...
  • Page 440 RSL10 Hardware Reference www.onsemi.com...
  • Page 441 ON Semiconductor www.onsemi.com...
  • Page 442 RSL10 Hardware Reference www.onsemi.com...
  • Page 443 ON Semiconductor www.onsemi.com...
  • Page 444 RSL10 Hardware Reference www.onsemi.com...
  • Page 445 ON Semiconductor www.onsemi.com...
  • Page 446 RSL10 Hardware Reference www.onsemi.com...
  • Page 447 ON Semiconductor www.onsemi.com...
  • Page 448 RSL10 Hardware Reference www.onsemi.com...
  • Page 449 ON Semiconductor www.onsemi.com...
  • Page 450 RSL10 Hardware Reference www.onsemi.com...
  • Page 451 ON Semiconductor www.onsemi.com...
  • Page 452 RSL10 Hardware Reference www.onsemi.com...
  • Page 453 ON Semiconductor www.onsemi.com...
  • Page 454 RSL10 Hardware Reference www.onsemi.com...
  • Page 455 ON Semiconductor www.onsemi.com...
  • Page 456 RSL10 Hardware Reference www.onsemi.com...
  • Page 457 ON Semiconductor www.onsemi.com...
  • Page 458 RSL10 Hardware Reference www.onsemi.com...
  • Page 459 ON Semiconductor www.onsemi.com...
  • Page 460 RSL10 Hardware Reference www.onsemi.com...
  • Page 461 ON Semiconductor www.onsemi.com...
  • Page 462 RSL10 Hardware Reference www.onsemi.com...
  • Page 463 ON Semiconductor www.onsemi.com...
  • Page 464 RSL10 Hardware Reference www.onsemi.com...
  • Page 465 ON Semiconductor www.onsemi.com...
  • Page 466 RSL10 Hardware Reference www.onsemi.com...
  • Page 467 ON Semiconductor www.onsemi.com...
  • Page 468 RSL10 Hardware Reference www.onsemi.com...
  • Page 469 ON Semiconductor www.onsemi.com...
  • Page 470 RSL10 Hardware Reference www.onsemi.com...
  • Page 471 ON Semiconductor www.onsemi.com...
  • Page 472 RSL10 Hardware Reference www.onsemi.com...
  • Page 473 ON Semiconductor www.onsemi.com...
  • Page 474 RSL10 Hardware Reference www.onsemi.com...
  • Page 475 ON Semiconductor www.onsemi.com...
  • Page 476 RSL10 Hardware Reference www.onsemi.com...
  • Page 477 ON Semiconductor www.onsemi.com...
  • Page 478 RSL10 Hardware Reference www.onsemi.com...
  • Page 479 ON Semiconductor www.onsemi.com...
  • Page 480 RSL10 Hardware Reference www.onsemi.com...
  • Page 481 ON Semiconductor www.onsemi.com...
  • Page 482 RSL10 Hardware Reference www.onsemi.com...
  • Page 483 ON Semiconductor www.onsemi.com...
  • Page 484 RSL10 Hardware Reference www.onsemi.com...
  • Page 485 ON Semiconductor www.onsemi.com...
  • Page 486 RSL10 Hardware Reference www.onsemi.com...
  • Page 487 ON Semiconductor www.onsemi.com...
  • Page 488 RSL10 Hardware Reference www.onsemi.com...
  • Page 489 ON Semiconductor www.onsemi.com...
  • Page 490 RSL10 Hardware Reference www.onsemi.com...
  • Page 491 ON Semiconductor www.onsemi.com...
  • Page 492 RSL10 Hardware Reference www.onsemi.com...
  • Page 493 ON Semiconductor www.onsemi.com...
  • Page 494 RSL10 Hardware Reference www.onsemi.com...
  • Page 495 ON Semiconductor www.onsemi.com...
  • Page 496 RSL10 Hardware Reference www.onsemi.com...
  • Page 497 ON Semiconductor www.onsemi.com...
  • Page 498 RSL10 Hardware Reference www.onsemi.com...
  • Page 499 ON Semiconductor www.onsemi.com...
  • Page 500 RSL10 Hardware Reference www.onsemi.com...
  • Page 501 ON Semiconductor www.onsemi.com...
  • Page 502 RSL10 Hardware Reference www.onsemi.com...
  • Page 503 ON Semiconductor www.onsemi.com...
  • Page 504 RSL10 Hardware Reference www.onsemi.com...
  • Page 505 ON Semiconductor www.onsemi.com...
  • Page 506 RSL10 Hardware Reference www.onsemi.com...
  • Page 507 ON Semiconductor www.onsemi.com...
  • Page 508 RSL10 Hardware Reference www.onsemi.com...
  • Page 509 ON Semiconductor www.onsemi.com...
  • Page 510 RSL10 Hardware Reference www.onsemi.com...
  • Page 511 ON Semiconductor www.onsemi.com...
  • Page 512 RSL10 Hardware Reference www.onsemi.com...
  • Page 513 ON Semiconductor www.onsemi.com...
  • Page 514 RSL10 Hardware Reference www.onsemi.com...
  • Page 515 ON Semiconductor www.onsemi.com...
  • Page 516 RSL10 Hardware Reference www.onsemi.com...
  • Page 517 ON Semiconductor www.onsemi.com...
  • Page 518 RSL10 Hardware Reference www.onsemi.com...
  • Page 519 APPENDIX B Glossary The following abbreviations and terms are used in this manual: analog control system analog-to-digital converter analog front-end cyclic redundancy check digital-to-analog converter digital input/output direct memory access error correcting code generic access profile general-purpose input/output GPIO high impedance inter-IC communication protocol inter-IC sound protocol integral non-linearity...
  • Page 520 RSL10 Hardware Reference phase-locked loop power management unit pulse width modulation power-on-reset random-access memory radio-frequency front-end RFFE read-only memory real-time clock serial clock (part of I C bus) serial data (part of I C bus) serial peripheral interface serial wire debug, two-wire interface used for communication with ARM cores...
  • Page 521 PUBLICATION ORDERING INFORMATION LITERATURE FULFILLMENT: N. American Technical Support: 800-282-9855 Toll ON Semiconductor Website: www.onsemi.com Literature Distribution Center for ON Semiconductor Free USA/Canada P.O. Box 5163, Denver, Colorado 80217 USA Europe, Middle East and Africa Technical Support: Order Literature: http://www.onsemi.com/orderlit...

Table of Contents

Save PDF
