ON Semiconductor RSL10 User Manual

RSL10 USB Dongle User Guide
1.
When developing Bluetooth low energy applications, you often need to establish a connection between a
peripheral that is being developed and a central device that can help verify and diagnose the behavior of the
peripheral.
To serve this purpose, ON Semiconductor developed the combination of the RSL10 USB Dongle and the
Bluetooth® Low Energy Explorer. The Dongle is plugged into a computer that has the Bluetooth Low Energy
Explorer software installed. The Dongle can then act as a generic central device with which a software developer can
do anything that a typical central application would do, such as advertising scanning, establish a connection, and list
services and characteristics.
1. RSL10 USB D
ONGLE
1.1 Key Features
• Bluetooth v.5.0, single (Bluetooth low energy) mode compliant
• Supports Master and Slave Modes
• Supports up to four connections
• Integrated Bluetooth low energy stack
• Radio performance
• Transmit power: +6 dBm to -17 dBm
• Receiver sensitivity: -94 dBm
• Host interfaces
• USB (virtual COM port emulation)
• Bluetooth Low Energy Explorer software to diagnose Bluetooth low energy connections during application
development
• Bluetooth 5, CE, FCC, IC and Japan certified
1.2 Electrical Characteristics
NOTE: The ratings in Table 1 are absolute maximum ratings beyond which the module can be
permanently damaged. These are not maximum operating conditions. The maximum
recommended operating conditions are in Table 2.
Table 1. Absolute Maximum Ratings
Rating Min
Storage Temperature -40
VBUS -0.3
Table 2. Recommended Operating Conditions
Rating
Operating Temperature Range
VBUS
Max Unit
+85 °C
6.5 V
Min Max Unit
-40 +85 °C
3.6 5.5 V
www.onsemi.com
1
D N M-20847-002
OCUMENT UMBER
