Made In China
11.5ft x 16ft Rectangular Professional
Got a Problem building your trampoline?
Call us on 0344 800 4060 and we can help
Patent no: DE602006006495D1, EP1721640B1 and US7628731
WARNING: Read these assembly instructions carefully
before attempting to assemble or use this product. Keep
this user guide in a safe place for future reference.
User Guide
Advertisement
Related Manuals for Jumpking JKR1116PRO
Summary of Contents for Jumpking JKR1116PRO
- Page 1 User Guide Made In China 11.5ft x 16ft Rectangular Professional Got a Problem building your trampoline? Call us on 0344 800 4060 and we can help Patent no: DE602006006495D1, EP1721640B1 and US7628731 WARNING: Read these assembly instructions carefully before attempting to assemble or use this product. Keep this user guide in a safe place for future reference.
- Page 6 2pcs B marking 2pcs C marking 2 pcs B, 2 pcs C and 4 pcs without marking...
- Page 7 Top tube B marking x 2 & C marking x 2 Top tube 2xB & 2xC marking Top tube C1 / C2 marking (6 spring holes) Centre leg Top tube D1 / D2 marking (7 spring holes) L -leg Top Tube A D marking (10 Spring holes) 8 x Part 22: T-connector + welded tube (2xb, 2xc &...
- Page 9 Attach Parts C1 /D1 and C2 / D2 between the T-Connector Welded tubes B & C - Ensure black caps are on the inside of the frame T-connector+welded tube Top view of frame： The black caps on part 4 & 5 should be on the inside of the frame...
- Page 10 Please attach the 7" Springs (part 9) in the sequence shown (1 - 23), please note you will need two people to attach the springs opposite each other on the long side. Then add the 5" spring (Part 21) to 24 - 27. Continue adding the remaining springs in the same sequence, making sure the next spring attached is on the opposite side to even out the tension.
- Page 11 Slot the springs onto the V-rings as shown. Important: Springs must be slotted on the right way around. Slot the other end of the spring into one of the spring slots in the top of the frame. IMPORTANT: Ensure the spring is fully inserted into the slot on the top of the frame.
- Page 12 Tie the outer elastic straps on the underside of the frame pad around the top tubes of the frame.
- Page 15 Stand on the inside of the trampoline and insert one of the exposed sections of the Black G3 pole into a plastic grip on top of one of the enclosure tubes hanging the netting on the inside of the poles.
- Page 19 JKR1116PRO (Ax2, Bx2, Cx2, Dx2)
