Installation Instructions
®
Tracer
Order Numbers:
X13651695001 (SC+)
Note: Includes 18 months software maintenance plan.
Packaged Contents
• One (1) Tracer
• Two (2) 4-position terminal block plugs
• Six (6) 3-position terminal block plugs
• One (1) Installation sheet
Only qualified personnel should install and service the equipment. The installation,
starting up, and servicing of heating, ventilating, and air-conditioning equipment
can be hazardous and requires specific knowledge and training. Improperly
installed, adjusted or altered equipment by an unqualified person could result in
death or serious injury. When working on the equipment, observe all precautions
in the literature and on the tags, stickers, and labels that are attached to the
equipment.
May 2023
SC+ System Controller
®
SC+ module
SAFETY WARNING
BAS-SVN037D-EN
©2023 Trane
X3964132001
Advertisement
Table of Contents
Related Manuals for Trane Tracer SC+
Summary of Contents for Trane Tracer SC+
- Page 1 When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are attached to the equipment. BAS-SVN037D-EN May 2023 ©2023 Trane...
-
Page 2: Warnings, Cautions, And Notices
Trane advocates the responsible handling of all refrigerants. Important Responsible Refrigerant Practices Trane believes that responsible refrigerant practices are important to the environment, our customers, and the air conditioning industry. All technicians who handle refrigerants must be certified according to local rules. For the USA,... - Page 3 WARNING Proper Field Wiring and Grounding Required! Failure to follow code could result in death or serious injury. All field wiring MUST be performed by qualified personnel. Improperly installed and grounded field wiring poses FIRE and ELECTROCUTION hazards. To avoid these hazards, you MUST follow requirements for field wiring installation and grounding as described in NEC and your local/state/national electrical codes.
-
Page 4: Revision History
Il est très important qu’une pile compatible soit utilisée. Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change. -
Page 5: Required Tools
Note: Compatible battery - BR2032. Required Tools • 5/16 in. (8 mm) slotted screwdriver • 1/8 in. (3 mm) slotted screwdriver Specifications ® Table 1. Tracer SC+ specifications Power Requirements 24 Vac @ 30 VA Class 2 Tracer ® plug-in power supply with single barrel connector- Output: 0.75A max at 24 Vdc @ 50C. - Page 6 Mounting the Tracer SC+ • The mounting location must meet the temperature and humidity specifications as outlined in Table • Do not mount on a flat surface, such as on a floor or on top of a table. Mount in an upright position with the front facing outward. ®...
- Page 7 ® 3. If repositioning, push on the Tracer SC+ until the slotted release clip snaps back into place. Figure 2. Removing the Tracer® SC+ Wiring and Applying Power ® The Tracer SC+ controller can be powered in one of three ways: •...
- Page 8 Current draw Each USM Port 500mA Max Trane Wi-Fi Module (X13651743001) 250mA Trane U60 LON Adapter 110mA Trane USB Cellular Module (Version, USA) 450mA ® Tracer SC+ DC Power Budget ® Depending on the power source, Tracer SC+ has a maximum current available for peripheral devices.
- Page 9 Transformer (Preferred Method) This procedure involves wiring 24Vac to the XFMR pins of the 4-position terminal ® block on the Tracer SC+ controller. See Figure 3 for details. 1. Using the provided 4-position terminal block, wire the 24 Vac input connection ®...
- Page 10 Note: For complete instructions and more information, refer to the Power Supply Module IOM (BAS-SVX33*-EN). 1. Connect one end of the provided IMC power cable to the IMC connection on ® the Tracer SC+. Connect the other end of the IMC power cable to the IMC connection on the power supply module.
-
Page 11: Service Parts
MOD01702 X13651538010 PM014 24 Vac to 1.4A 24 Vdc PLU1323 X13770352001 Plug-in Power Supply ® KIT18458 X13651698001 Tracer USB Lon Module MOD01786 X1365152401 Trane BACNET Terminator (TBT) ® MOD03121 X13651743001, 2 Tracer USB Wifi Module KIT18459 X13690281001 Micro SD Card... - Page 12 Table 5. Accessories (continued) Service Part # Part Number Description ® BMCL100US0100000 Tracer USB Cellular Module, NB, 1M Cable ® BMCL100USB100000 Tracer USB Cellular Module, 1M Cable ® BMCL100USB290000 Tracer USB Cellular Module, 2.9M Cable Table 6. Enclosures Service Part # Part Number Description X13651559010...
- Page 13 Front Tracer SC+ Use either IMC connection BACnet- BACnet Terminator 24 Vac/Vdc (red wire) BACnet+ Ground (black wire) Agency Listings and Compliance The European Union (EU) Declaration of Conformity is available from your ® local Trane office.
- Page 14 American Standard create comfortable, energy Trane hasTrane and American Standard have a policy of continuous product and product data improvement and reserves the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
