Installation and operation manual
Central Controller Unit
U-Match Inverter Systems
MultiSplit Inverter Systems
TCONTCCMHCM04A
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
April 2021
SAFETY WARNING
MS-SVX082A-EN
Confidential and proprietary Trane information
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trane TCONTCCMHCM04A
Summary of Contents for Trane TCONTCCMHCM04A
- Page 1 Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are attached to the equipment. MS-SVX082A-EN April 2021 Confidential and proprietary Trane information...
-
Page 2: Table Of Contents
TCONTCCMHCM04A Wiring & Operating Instructions............. 2 Appearance ........................2 Specification ........................3 Interface Features ......................3 Wiring Instructions ......................4 Indoor Unit Dip Switch......................6 TCONTCCMHCM04A Configuration File Replacement Instructions ....... 8 TCONTCCMHCM04A IP Modifying Instructions ............... 11 Attached document ......................14 1 / 14... -
Page 3: Tcontccmhcm04A Wiring & Operating Instructions
BACnet protocol, implement Modbus device integration into BACnet network. That is, the gateway acts as a Modbus Master (master station) and supports connection of 4 Modbus Slaver devices. TCONTCCMHCM04A is a standard BACnet network device in the BACnet network, and the user can map the device data points in the MODBUS network one by one to the data points in the BACnet network. -
Page 4: Specification
Specification Function Specification Power supply AC and DC rated voltage 24V, working range 12V to 24V. 256M Flash 64M DDR2 -20°C -- 70°C，5--90%RH (non-condensing) Working condition -40°C -- 85°C，5--95%RH (non-condensing) Storage Conditions Ethernet communication Specification High-performance 100M/10M adaptive Industrial Network Card, support AUTO Protocol BACnet IP... -
Page 5: Wiring Instructions
RESET RESET Press the button 8 S continuously to restart the factory settings. Wiring Instructions TCONTCCMHCM04A default network port parameters are as follows： IP address192.168.1.88 Subnet mask 255.255.255.0 Default gateway 192.168.1.1 TCONTCCMHCM04A should be used with gateway TCONTADPYCJA2A. 4 / 14... - Page 6 The specific connection diagram is as follows： Connect to TCONTADPYCJA2A: 5 / 14...
-
Page 7: Indoor Unit Dip Switch
Indoor Unit Dip Switch The address cannot be duplicated between the gateways connected to the same TCONTCCMHCM04A. COM1 interface connect the gateway whose address is 1&2; COM2 interface connect the gateway whose address is 3&4. The indoor unit addresses under the same gateway cannot be duplicated, and the address range is 1~32. - Page 8 Indoor Unit Dip Switch The address dip switch of the indoor unit is SW03, ON is 1, OFF is 0; The address dip switch range is 1~32, dip switch setting as follows: SW03 Address ….. ….. ….. ….. ….. ….. ….. ….. …..
-
Page 9: Tcontccmhcm04A Configuration File Replacement Instructions
TCONTCCMHCM04A Configuration File Replacement Instructions 1. The default IP of TCONTCCMHCM04A is 192.168.1.88 . 2. First, set the IP of the computer to the same network segment as TCONTCCMHCM04A. Then “ping” the IP “192.168.1.88” to see if it can work;... - Page 10 In the dialog box, select the project file that you want to burn Click "Gateway" on the menu bar to choose "Upload " or click on the toolbar upload the project. In the pop up dialog box enter the gateway IP address, click the "Upload". 9 / 14...
- Page 11 After uploading, the pop-up dialog prompt succeed to upload. Note: the IP address of the gateway must be correct. the default gateway IP address is 192.168.1.88, the IP address of PC to set up to he same network segment, the project can be uploaded after successfully Ping.
-
Page 12: Tcontccmhcm04A Ip Modifying Instructions
TCONTCCMHCM04A IP Modifying Instructions X2BACnet.exe First double click to open “ ” debugging software. Click "File" on the menu bar to choose "Open… " or click on the toolbar to Open the project. 11 / 14... - Page 13 In the dialog box, select the project file that you want to burn In the gateway monitoring mode, click on the menu bar "Gateway" and select "Settings". In the dialog box that pops up, enter the user name and password. The user name is fixed to “admin”...
- Page 14 Network port setting: You can change the IP address of the hardware gateway. The default IP address of the gateway is 192.168.1.88, the default subnet mask is 255.255.255.0, and the default gateway is 192.168.1.1. Click OK after setting. The “Ping” function tests whether the current IP address is successful. The “Login Page Function”...
-
Page 15: Attached Document
Attached document 1. Debugging Software “X2BACnet.exe” 2. Standard Configuration File Connected to TCONTADPYCJA2A Configuration 32+32 TCONTADPYCJA2A——20201210 14 / 14... - Page 16 For more information, please visit trane.com or tranetechnologies.com. Trane has a policy of continuous product and product data improvement and reserves the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
