Summary of Contents for HIKVISION DS-K1T642 Series
- Page 1 DS-K1T642 Series Face Recognition Terminal Quick Start Guide UD17692B...
- Page 2 Installation Installation Environment: Indoor installation is supported. The device should be at least 2 meters away from the light, and at least 3 meters away from the window or the door. The additional force shall be equal to three times the weight of the equipment but not less than 50N.
- Page 3 Appearance This sticker means“Hot parts! Burned fingers when handling the parts. Wait one-half hour after switching off before handling parts.”It is to indicate that the marked item can be hot and should not be touched without taking care. For device with this sticker, this device is intended for microUSB Loudspeaker installation in a restricted access location, access can only be gained by service persons or by users...
-
Page 4: Connect Network Cable
When connecting door magnetic sensor and exit button, the device and the RS-485 card reader should use the common ground connection. The Wiegand termimal here is a Wiegand input terminal. You should set the face recognition terminal’s Wiegand direction to “Input”. If you connect to an access controller, you should set the Wiegand direction to “Output”. - Page 5 Device Wiring (With Secure Door Control Unit) Face Recognition Terminal Secure Door Control Unit Power Input Black Door Contact Green/Brown SENSOR Sensor Input Black Secure Door Yellow Control Unit Exit Button Blue RS-485 Wiring Terminal Green/Black BUTTON Red/ Exit Button Black Black White/Purple...
- Page 6 Activation Power on and wire the network cable after installation. You should activate the device before the first login. Activate Device If the device is not activated yet, it will enter the Activate Device page after powering on. Enter 8 to 16 characters. Steps: 1.
- Page 7 Two-Way Audio After adding the device to the client software, you can call the device from the client software, call the client software from the device, call the center from the device, or call the indoor station from the device. Call Client Software from Device After adding the device on the client software, tap ->...
- Page 8 Add Face Picture 1. Use finger to hold the screen surface for 3 s and slide to right/left and enter the activation password to enter the Home page. 2. Enter the User Management page, tap + to enter the Add User page.
-
Page 9: Tips When Collecting/Comparing Face Picture
Tips When Collecting/ Comparing Face Picture Expression Keep your expression naturally when collecting or comparing face pictures, just like the expression in the picture on the right. Do not wear hat, sunglasses, or other accessories that can affect the facial recognition function. Do not make your hair cover your eyes, ears, etc. - Page 10 Positions When Collecting/ Comparing Face Picture (Recommended Distance: 0.5m) Too High Recommended Height: 1.43m to 1.90m Too Low 1.4m 1.4m 0.5m 0.5m Too Far Too Close 1.4m 1.4m 0.5m 1.2m...
-
Page 11: Regulatory Information
Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 12 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
- Page 13 This Manual is subject to domestic and international copyright protection. Hangzhou Hikvision Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This manual cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
