Summary of Contents for HIKVISION MinMoe DS-K1T671TM-3XF
Page 1
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team DS-K1T671TM-3XF MinMoe Temperature Screening Face Recognition Terminal Installation Guide Date Content Person Version 2020/04/26 Create Morgen...
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team Content 1. System structure & Function description ......................... 3 2. Installation process ................................4 3. System implementation considerations ........................... 4 3.1 Site survey precautions ............................. 4 3.2 Precautions when measuring human temperature.................... 4 4.
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team 1. System structure & Function description This solution is designed to control the entrance and exit of office building, factory, cell and so on through temperature measurement and face verification, and the event can be managed and monitored on iVMS-4200 client software or HikCentral Professional platform.
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team 4. Preparation before installation Please read and follow the requirements before using the devices. 4.1 Safety instruction Precautions for use Do not point the device directly to the strong light such as lights and sunlight; ...
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team 4.3 Site survey Installation site survey Project Name Note Entrance Name Installation environment (Indoor, Photos and videos for outdoor) site Power supply and network cable (surface installation or bury in the tube) Device installation method (surface or with stand)...
Page 7
MinMoe Temperature Screening Terminal Installation Guide Hikvision Product Support Team 5.1.2 Device wiring 1. Install bracket on the stand with 4 screws, connect network, power and other external devices' cables to device interface; 2. Install device on the bracket(unscresw 2 screws on both sides, press device bottom and secure 2...
Page 8
MinMoe Temperature Screening Terminal Installation Guide Hikvision Product Support Team 3. Connect 220V AC power cable and power cable to floor stand 5.1.3 Device debugging and configuration 5.1.3.1 Debugging process 5.1.3.2 Temperature measurement configuration 1) Activate terminal with SADP/iVMS-4200 or from device local UI 2)...
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team 5.1.3.3 Face with mask configuration Default enable: must wear face mask or authentication will be failed 1:N : face comparison similarity Default disable: after enable, authentication will not be granted without face mask Default disable: after enable, device will show prompt and play audio 5.2 Temperature displayed on the screen 1) Normal face recognition, normal and abnormal body temperature...
After checking and filling as required, the acceptance form and related videos / pictures shall be reported. Hikvision technical engineers shall conduct inspection. after the inspection is correct, the delivery acceptance list shall be provided to Party A for signature and retention.
Page 11
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team 6.1.1 Construction acceptance Construction Acceptance List Content Meets the Remark standard(√/×) Whether it is installed in a Outdoor environment is greatly affected by environmental room with constant changes such as temperature, wind, and humidity, which temperature, no wind and will affect the temperature measurement accuracy of the no direct sunlight...
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team Take video confirmation of normal temperature and Record video to confirm abnormal temperature, test comparison video Whether the device normally uploads photo Take pictures and record video to capture, temperature and other information confirm 7.
Page 13
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team 2) Open device menu and check whether terminal can get video stream from thermal camera or not. 3) Temperature measurement result is not accurate 1) In order to get an accurate temperature, after the device is powered on, you should wait for 90 min to warm the device up.
Page 14
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team Export from device local to USB drive, CSV format, including employee id, card no, name, time, attendance status, temperature info, overtemperature or not, with mask or not Monitoring will not show temperature information. Real time event in Event Center, temperature, captured normal and thermal pictures are available.
Page 15
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team Search event in iVMS-4200, please select device type as Access Control, then you can find temperature, captured normal and thermal picture (without temperature OSD information) Export captured picture and event from iVMS-4200 to PC, CSV format for event log and captured pictures...
Page 16
MinMoe Temperature Screening Terminal Installation Guide Mercury SD Product Support Team...
