HIKVISION DS-K1T642 Series Quick Start Manual

DS-K1T642 Series Face Recognition Terminal
Quick Start Guide
UD17692B-C
©2020 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instruc ons for using and managing the Product. Pictures, charts, images
and all other informa on hereina er are for descrip on and explana on only. The informa on
contained in the Manual is subject to change, without no ce, due to firmware updates or other
reasons. Please find the latest version of this Manual at the Hikvision website
(h ps://www.hikvision.com/).
Please use this Manual with the guidance and assistance of professionals trained in suppor ng
the Product.
Trademarks
and other Hikvision's trademarks and logos are the proper es of Hikvision in various
jurisdic ons.
Other trademarks and logos men oned are the proper es of their respec ve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND
"WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS
FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO
EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE
LATER PREVAILS.
Data Protec on
During the use of device, personal data will be collected, stored and processed. To protect data,
the development of Hikvision devices incorporates privacy by design principles. For example,
for device with facial recogni on features, biometrics data is stored in your device with
encryp on method; for fingerprint device, only fingerprint template will be saved, which is
impossible to reconstruct a fingerprint image.
As data controller, you are advised to collect, store, process and transfer data in accordance
with the applicable data protec on laws and regula ons, including without limita on,
conduc ng security controls to safeguard personal data, such as, implemen ng reasonable
administra ve and physical security controls, conduct periodic reviews and assessments of the
effec veness of your security controls.
Scan the QR code to get the user manual for detailed informa on.
1 Appearance
microUSB Loudspeaker
Camera Camera
118 mm
IR Light IR Light
Screen
Card Presen ng Area Fingerprint Module
(Supported by Parts of
Device Models)
The figures are for reference only.
micro USB to USB cable is available.
3 Wiring (Normal)
Use only power supplieslisted in the user instruc ons:
Model Manufacture Standard
ADS-26FSG-12 12024EPG Shenzhen Honor Electronic Co.,Ltd PG
MSA-C2000IC12.0-24P-DE MOSO Technology Co.,Ltd PDE
ADS-26FSG-12 12024EPB Shenzhen Honor Electronic Co.,Ltd PB
ADS-26FSG-12 12024EPCU/EPC Shenzhen Honor Electronic Co.,Ltd PCU
ADS-26FSG-12 12024EPI-01 Shenzhen Honor Electronic Co.,Ltd PI
ADS-26FSG-12 12024EPBR Shenzhen Honor Electronic Co.,Ltd PBR
2 Installa on
This s cker means"Hot parts! Burned fingers when handling
the parts. Wait one-half hour a er switching off before
Installa on Environment:
handling parts."It is to indicate that the marked item can be
hot and should not be touched without taking care. For device
Indoor and outdoor installa on are supported. If installing the device indoors, the
with this s cker, this device is intended for installa on in a
device should be at least 2 meters away from the light, and at least 3 meters away
restricted access loca on, access can only be gained by service
from the window or the door. If installing the device outdoors, you should apply
persons or by users who have been instructed about the
Silicone sealant among the cable wiring area to keep the raindrop from entering.
reasons for the restric ons applied to the loca on and about
any precau ons that shall be taken.
The addi onal force shall be equal to three mes the weight of the equipment but not
less than 50N. The equipment and its associated moun ng means shall remain secure during
the installa on. A er the installa on, the equipment, including any associated moun ng
Debugging Port plate, shall not be damaged.
(For debugging only)
Wall Mounting:
1
Drill holes on the wall or other surfaces according to the
instruc ons on the moun ng template.
Align the holes to the moun ng plate and secure the plate on the
wall with 4 supplied screws (KM3X6-H2-SUS).
Network
2 Route the cables through the cable hole of the moun ng plate,
Interface and connect to the corresponding external devices' cables.
Align the device with the moun ng plate and hang the terminal
on the moun ng plate.
Wiring Terminal
TEMPER
Power Input
RS-485
Group B
Wiegand
Door Lock
Group D
Network Interface
Backlight
Use 1 supplied screw (KM3X6-H2-SUS) to secure the device
3
on the moun ng plate.
Red
Black
Yellow
B1
Blue
B2
12V External
GND Red/Black
B3
Power Supply
Green
C1
Wiegand
White
C2
White/Black Card Reader
GND
C3
Eletric Dropbolt
(NC)
White/Purple
D1
(COM)
White/Yellow
D2
(NO) Power Supply
White/Red
D3
Yellow/Green
D4
GND Black Door Contact
Eletric Strike
D5
NO
BUTTON Yellow/Gray
D6
COM
GND Yellow/Black
D7 NC
NO
COM
NC
Exit Button
Direct Direct Sunlight Indirect Sunlight Close to Light
Sunlight through Window through Window
For base moun ng, see the user manual.
When connec ng door contact and exit bu on,
the device and the RS-485 card reader should
use the same common ground connec on.
The Wiegand terminal here is a Wiegand input
terminal. You should set the device's Wiegand
direc on to "input". If you should connect to
an access controller, you should set the
Wiegand direc on to "Output". For details, see
the user manual.
The suggested external power supply for door
lock is 12 V, 1 A.
The suggested external power supply for
Wiegand card reader is 12 V, 1 A.
For wiring the fire system, see the user manul.
Do not wire the device to the electric supply
directly.
