- Page 1 DS-K1T671TM-3XF Face Recogni�on Terminal Quick Start Guide UD19286B-E...
- Page 2 Appearance Thermographic Module 116.5 mm 36.7 mm IR Light IR Light Camera Camera TAMPER Touch Screen Card Presenting Area Thermographic Module Debugging Port Interface (For debugging only) Power Interface Wiring USB Interface Terminal Network PSAM Card Slot (Reserved) Interface The figures are for reference only.
-
Page 3: Installation
Installation Installa�on Environment: Avoid backlight, direct sunlight, and indirect sunlight. For be�er recogni�on, there should be light source in or near the installa�on environment. Backlight Direct Sunlight Indirect Sunlight through Window Close to Light Direct Sunlight through Window Temperature Measurement Environment: Sunlight, wind, hot/cool air from air condi�oner and other external factors, which may affect surface temperature, will create the devia�on of the temperature measurement. - Page 4 Steps: Make sure the output of external power supply fulfils LPS. Drill holes on the wall or other surface and install the gang box. Use two supplied screws (4_KA4×22-SUS) to secure the moun�ng plate on the gang box. Use another 4 supplied screws to secure the moun�ng plate on the wall. Route the cables through the cable hole of the moun�ng plate, and connect to the corresponding external devices’...
- Page 5 Device Wiring (Normal) When connec�ng door magne�c sensor and exit bu�on, the device and the RS-485 card reader should use the common ground connec�on. The Wiegand terminal here is a Wiegand input terminal. You should set the face recogni�on terminal’s Wiegand direc�on to “Input”. If you should connect to an access controller, you should set the Wiegand direc�on to “Output”.
- Page 6 (NC) (COM) (NO) Door Contact Network Interface...
- Page 7 Device Wiring (With Secure Door Control Unit) Face Recognition Terminal Secure Door Control Unit Power Input Black Door Contact Green/Brown SENSOR Sensor Input Black Secure Door The secure door control unit Exit Bu�on Control Unit should connect to an external Wiring Terminal BUTTON Green/Black...
- Page 8 Adding Face Information 1 Hold the screen surface and verify the iden�ty to enter the main page. 2. Enter the User Management page, tap + to enter the Add User page. 3. Set the user parameters according to actual needs. 3.
-
Page 9: Tips When Collecting/Comparing Face Picture
Tips When Collecting/ Comparing Face Picture Expression Keep your expression naturally when collec�ng or comparing face pictures, just like the expression in the picture on the right. Do not wear hat, sunglasses, or other accessories that can affect the facial recogni�on func�on. Do not make your hair cover your eyes, ears, etc. - Page 10 Positions When Collecting/ Comparing Face Picture (Recommended Distance: 0.5m) Too High Recommended Height: 1.43m to 1.90m Too Low 1.4m 1.4m 0.5m 0.5m Too Far Too Close 1.4m 1.4m...
-
Page 11: Regulatory Information
Regulatory Information FCC Information Please take a�en�on that changes or modifica�on not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 12 MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS...
