FIBARO FGFS-101 Manual

EN
FIBARO FLOOD SENSOR
FIBARO Flood Sensor
flood and temperature sensor. It is designed to be placed on a floor
or on a wall with the flood sensor probes extended by a connected
wire. Device can be battery or VDC powered. It has built-in LED
indicator, acoustic alarm, and is equipped with a tilt sensor, reporting
tilt or movement of it. LED diode signals flood, operating mode or the
Z-Wave network communication range. FIBARO Flood Sensor is
compatible with any Z-Wave Controller and may be connected to any
alarm system.
For full instruction manual and technical
specification please visit our website:
manuals.fibaro.com/en/flood-sensor
IMPORTANT
Read the manual before attempting
to install the device!
Basic activation of the device
1) Open the cover by turning it counter-clockwise.
2) Remove battery blocker.
3) Locate the sensor nearby the main Z-Wave controller.
4) Set the main Z-Wave controller into adding mode.
5) Quickly, triple click the TMP button located inside the casing.
TMP
button
6) Wait for the device to be added into the system.
Successful adding will be confirmed by the controller.
7) Close the cover by turning it clockwise.
8) Place the sensor onto a surface prone to flooding. Three
electrodes underneath the device should evenly touch the surface.
Specifications
Power supply:
Battery type:
External power supply voltage:
Operating temperature:
Measured temperature range:
Maximum voltage at output terminals:
Dimensions (diameter x height):
FGFS-101
is a universal, Z-Wave Plus compatible,
TMP button location
FCC ID:
2AA9MFGFS101Z5
IC number:
20430-FGFS101Z5
battery / DC adapter
CR123A (3V)
12-24V DC
32 to 104°F
-4 to 212°F
24V DC / 20V AC
2.83" x 1.1"
