FIBARO FGMS-001 Operating Manual

Motion sensor
Hide thumbs Also See for FGMS-001:
Table of Contents

Advertisement

Quick Links

FIBARO MOTION SENSOR
CONTENTS
O P E R A T I N G
M A N U A L
FGMS-001
3
4
5
6
7
EN
v2.1
9
10
11
18
19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FGMS-001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FIBARO FGMS-001

Summary of Contents for FIBARO FGMS-001

  • Page 1: Table Of Contents

    O P E R A T I N G M A N U A L FIBARO MOTION SENSOR FGMS-001 CONTENTS v2.1 #1: Description and features #6: Association #2: Basic activation #7: Z-Wave range test #3: Adding/removing the device #8: Advanced parameters...
  • Page 2 Compliance with safety standards: The device is designed to be used in Z-wave home automation sys- tems (e.g. FIBARO) and is complaint with IEC/UL/CSA 60950-1. In case of the integration with another system, e.g. alarm system, it is re- quired to verify the compliance with additional standards.

  • Page 3: 1: Description And Features

    The sensor has a built-in accelerometer to detect any tampering of the device. FIBARO Motion Sensor is battery powered device and designed to be installed quickly and easily on any surface.

  • Page 4: 2: Basic Activation

    #2: Basic activation 1. Turn the cover counter-clockwise and open it. 2. Remove the battery blocker. 3. Add the device (see “Adding/removing the device” on page 5). 4. Wake up the sensor by triple clicking the B-button. B-button 5. Close the cover and turn it clockwise. 6.

  • Page 5: 3: Adding/Removing The Device

    #3: Adding/removing the device Adding (Inclusion) - Z-Wave device learning mode, allowing to add NOTE the device to existing Z-Wave network. Adding security To add the device to the Z-Wave network: mode must be per- 1. Open the cover. formed up to 2 meters from the controller.

  • Page 6: 4: Physical Installation

    #4: Physical installation Detection range: Detection range of the Motion Sensor is shown below. Actual range of the Sensor can be influenced by environmental conditions. Installation location and working conditions: The Motion Sensor should be installed in a corner of the room or per- pendicularly to the doors.

  • Page 7: 5: Operating The Device

    To wake up the sensor manually triple click the B-button located in- side the housing. Controlling the Motion Sensor with FIBARO Home Center controller: The Motion Sensor has a bulit-in motion detector, temperature sensor and light intensity sensor, which make it a multi-channel device. In the home Center interface it will be presented as three devices.
  • Page 8 Seismograph mode: The Motion Sensor can be configured to work as a simple earthquake detector, by setting the parameter 24 value to 1. Reports with scale of the vibrations (in the Modified Mercalli Scale) will be sent immediate- ly after vibrations have been detected. Minimal power of vibrations that will be reported, can be set in parametr 20.

  • Page 9: 6: Association

    #6: Association Association (linking devices) - direct control of other devices within NOTE the Z-Wave system network e.g. Dimmer, Relay Switch, Roller Shutter or scene (may be controlled only through a Z-Wave controller). Association allows di- rect transfer of control commands between devices, is performed The Motion Sensor provides the association of four groups:...

  • Page 10: 7: Z-Wave Range Test

    #7: Z-Wave range test The Motion Sensor has a built in Z-Wave network main controller’s CAUTION range tester. To make Z-Wave range test possible, the de- vice must be added Follow the below instructions to test the main controller’s range: to the Z-Wave control- ler.

  • Page 11: 8: Advanced Parameters

    #8: Advanced parameters The Motion Sensor allows to customize its operation to user’s needs. The settings are available in the FIBARO interface as simple options that may be chosen by selecting the appropriate box. In order to configure the Motion Sensor (using the home Center con- troller): 1.
  • Page 12 3. Motion detection - pulse counter This parameter determines the number of moves required for the PIR sensor to report motion. The higher the value, the less sensitive the PIR sensor is. It is not recommended to modify this parameter settings! Available settings: 0 - 1 pulse 1 - 2 pulses 2 - 3 pulses...
  • Page 13 9. Motion detection - night/day This parameter defines the difference between night and day in terms of light intensity, used in parameter 8. Available settings: 1-32767 (1-32767 lux) 200 (200 lux) Parameter size: 2 [bytes] Default setting: 12. BASIC command class configuration NOTE This parameter determines the command frames sent to 2nd associa- values of BASIC On...
  • Page 14 20. Tamper - sensitivity This parameter determines the change in force acting on the device, that will result in reporting tamper alarm - g-force acceleration. Available settings: 0 - tamper inactive 1-121 - (0.08-2g; every 0.016g) Default setting: 20 (0.4g) Parameter size: 1 [byte] 22.
  • Page 15 This parameter provides backward compatibility with controllers not supporting Z-Wave+. Available settings: 0 - backward compatible tamper alarm sent to 5th association group 1 - backward compatible tamper alarm sent in broadcast mode Default setting: Parameter size: 1 [byte] 40. Illuminance report - threshold This parameter determines the change in light intensity level result- ing in illuminance report being sent to the main controller.
  • Page 16 66. Temperature offset The value to be added to the actual temperature, measured by the sensor (temperature compensation). Available settings: -1000 - 1000 (-100 - 100°C, 0.1°C step) 0 (0°C) 2 [bytes] Default setting: Parameter size: 80. Visual LED indicator - signalling mode NOTE This parameter determines the way in which visual indicator behaves Flashlight...
  • Page 17 83. Visual LED indicator - illuminance for high indicator brightness Light intensity level above which brightness of visual indicator is set to 100%. Available settings: value of parameter 82 to 32767 (in lux) 1000 2 [bytes] Default setting: Parameter size: 86.

  • Page 18: 9: Specifications

    #9: Specifications Power supply: 3.0v DC battery CAUTION Using batteries other Battery type: CR123A than specified may result in explosion. EU directives compliance: RohS 2011/65/EU Dispose of properly, RED 2014/53/EU observing environ- mental protection Radio protocol: Z-Wave (500 series chip) rules.

  • Page 19: 10: Regulations

    All information, including, but not limited to, information regarding the features, functionality, and/or other product specification are subject to change without notice. Fibaro reserves all rights to revise or upda- te its products, software, or documentation without any obligation to notify any individual or entity.
  • Page 20 Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.manuals.fibaro.com WEEE Directive Compliance Device labelled with this symbol should not be disposed with other household wastes.
