FIBARO DOOR/WINDOW SENSOR 2
CONTENTS
#1: Description and features
#2: Basic activation
#3: Adding/removing the device
#4: Physical installation
#5: Operating the device
O P E R A T I N G
M A N U A L
FGDW-002
3
#6: Association
4
#7: Advanced parameters
5
#8: Specifications
6
#9: Regulations
7
EN
v1.1
9
10
14
15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FIBARO FGDW-002-7
Summary of Contents for FIBARO FGDW-002-7
-
Page 1: Table Of Contents
O P E R A T I N G M A N U A L FIBARO DOOR/WINDOW SENSOR 2 FGDW-002 CONTENTS v1.1 #1: Description and features #6: Association #2: Basic activation #7: Advanced parameters #3: Adding/removing the device #8: Specifications... - Page 2 Compliance with safety standards: The device is designed to be used in Z-wave home automation sys- tems (e.g. FIBARO) and is complaint with IEC/UL/CSA 60950-1. In case of the integration with another system, e.g. alarm system, it is re- quired to verify the compliance with additional standards.
-
Page 3: Fibaro Door/Window Sensor 2
#1: Description and features FIBARO Door/Window Sensor 2 is a wireless, battery powered Hall effect contact sensor, compatible with the Z-Wave Plus standard. Changing the device’s status will automatically send signal to the Z-Wave controller and associated devices. Sensor can be used to trigger scenes and wherever there is a need for information about opening or closing of doors, windows, garage doors, etc. -
Page 4: 2: Basic Activation
#2: Basic activation 1. Take off the cover. 2. Remove the battery blocker. 3. Close the cover. 4. Add the device (see “Adding/removing the device” on page 5). 5. Install the device (see “Physical installation” on page 6). BASIC ACTIVATIOn... -
Page 5: 3: Adding/Removing The Device
#3: Adding/removing the device Adding (Inclusion) - Z-Wave device learning mode, allowing to add NOTE the device to existing Z-Wave network. Adding Security To add the device to the Z-Wave network: Mode must be per- 1. Place the Door/Window Sensor 2 within the direct range of your formed up to 2 meters from the controller. -
Page 6: 4: Physical Installation
#4: Physical installation To install the Door/Window Sensor: NOTE 1. Peel off the protective layer from the sticker on the device. It is possible to in- 2. Stick the device onto the door/window frame. stall the device with screws (not included). 3. -
Page 7: 5: Operating The Device
Controlling the Door/Window Sensor 2 with FIBARO Home Center controller: After adding the Sensor to the FIBARO System, it will be represented by two or three icons in Home Center interface. First icon informs about the status of magnetic sensor (open/close), second icon displays temperature measured by the built-in sensor. - Page 8 “Adding/ removing the device” Replacing the battery: on page 5. In FIBARO Home Center controller current battery level is displayed in the interface. If a battery icon turns red, it means the battery needs replacement. Notification report: NOTE...
-
Page 9: 6: Association
#6: Association Association (linking devices) - direct control of other devices within NOTE the Z-Wave system network e.g. Dimmer, Relay Switch, Roller Shutter or scene (may be controlled only through a Z-Wave controller). Association allows transfer control commands between devices without par- The Door/Window Sensor 2 provides the association of three ticipation of the main controller. -
Page 10: 7: Advanced Parameters
#7: Advanced parameters The Door/Window Sensor 2 allows to customize its operation to user’s NOTE needs. Settings are available in the FIBARO interface as simple op- tions that may be chosen by selecting the appropriate box. Entering invalid value of parameter will re-... - Page 11 3. Associations in Z-Wave network Security Mode This parameter defines how commands are sent in specified associa- tion groups: as secure or non-secure. Parameter is active only in Z-Wave network Security Mode. It does not apply to 1st group “Lifeline”. Available settings: 0 - none of the groups sent as secure 1 - 2nd group ”On/Off”...
- Page 12 15. Association for closing - time delay Time that must elapse from closing to send the command frame to devices in 2nd association group. Available settings: 0-32400 - time in seconds 2 [bytes] Default setting: Parameter size: 30. Tamper - alarm cancellation delay Time period after which a tamper alarm will be cancelled.
- Page 13 53. Temperature offset The value to be added to the actual temperature, measured by the sen- sor (temperature compensation). Available settings: -1000–1000 (-100–100°C, 0.1°C step) 0 (0°C ) 2 [bytes] Default setting: Parameter size: 54. Temperature alarm reports Temperature alarms reported to the Z-Wave controller. Thresholds are set in parameters 55 and 56.
-
Page 14: 8: Specifications
#8: Specifications Power supply: 3.6V DC battery CAUTION Using batteries other Battery type: ER14250 ½ AA than specified may result in explosion. Battery life: est. 2 years (default settings) Dispose of properly, observing environ- EU directives compliance: RoHS 2011/65/EU mental protection RED 2014/53/EU rules. -
Page 15: 9: Regulations
All information, including, but not limited to, information regarding the features, functionality, and/or other product specification are subject to change without notice. Fibaro reserves all rights to revise or upda- te its products, software, or documentation without any obligation to notify any individual or entity. - Page 16 Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.manuals.fibaro.com WEEE Directive Compliance Device labelled with this symbol should not be disposed with other household wastes.
