LED Group ROBUS R8MLED Quick Start Manual

Specification:
Installation:
1. Please note the requirement to dispose of Waste Electrical & Electronic Equipment separately from household waste (WEEE
marked with crossed out wheelie bin symbol).
2. Please consider your role in contributing to re-use and recycling by returning this product at end of life to a collection centre
for waste electrical equipment or a Civic Amenity site, or to a retail outlet from which you are purchasing a replacement.
3. This equipment may contain substances that are hazardous to health and the environment if disposed of carelessly. It is
important that it is separated from normal household waste and recycled in the WEEE chain
4. The "crossed out wheelie bin symbol" on a product indicates this equipment must not be disposed of in normal household
waste, but should be disposed of according to local WEEE regulations
The Installation must be carried out by an electrician
LED Group
Western Retail Park
Nangor Road
Dublin 12
Ireland
Issue 1 271212
R8MLED&R8NMLED
R8MLEDDE(accessory for R8MLED or
R8NMLED)
IP65 Maintained and Non-maintained
LED bulkheads
Please read instructions before commencing installation and retain for
future reference.
Model No
Operating mode
Lamp type
Total power
Dimensions
Weight
Insulation
Supply voltage
Discharge Duration
Battery
Operating ambient temperature
Case material
Diffuser material
Ingress Protection
Suitable for mounting on a normally flammable surface
Green LED indicator indicates battery charging mode
Safety and performance in accordance with EN60598-1,EN60598-2-22
EN55015,EN61000-3-2,EN61000-3-3,EN61547
Suitable for indoor or outdoor use, wall or ceiling mounted
! Electrical products can cause death or injury, or damage to property. If in any doubt about
the installation or use of this product, consult a competent electrician.
1 Ensure mains supply is switched off before commencing installation.
2.Remove the front diffuser from the body by removing the 2 fixing screws.
3.Release the gear tray by easing the plastic clips away from the tray and lifting the
tray away from the base.
4.Knock out the intended cable entry hole suitable for your installation;Fit cable gland(if
weatherproofing necessary)
5. Mark appropriate fixing points on wall or ceiling; check that fixings will not impinge on concealed
cables or pipes before drilling holes.
6. Fix luminaire to the wall/ceiling using suitable screws.
7. Write installation date on battery and connect battery
8. Connect wires from unswitched supply to terminals on gear tray, brown to L,Blue to N and
green/yellow to earth (Non Maintained)； In the maintained emergency unit: for LEDs always on ,
link terminal "Ls" to terminal "L". LEDs controlled by switch connect switched live wire to terminal
Ls and permanent live to L
Note: if "Ls" terminal not connected, fitting works as non-maintained.
9. Reassemble gear tray and diffuser.
10. Switch on suppy: the green LED should come on indicating conrrect battery charge has
started. In the non-maintained unit,the LEDs only lights if the mains supply fails; In the
maintained unit,the LEDs will light(if switched live on),when the mains supply fails,battery
will operate LEDs emergency mode.
Information for the Product user
Tel: +353 1 7099000
Fax: +353 1 7099060
Email: info@led.ie
Website: www.led.ie
R8MLED-01 R8NMLED-01
maintained non-maintained
27X0.05watt white LED strip
2.6W
(L)352mmX(W)110mmX(H)57mm
0.57kg
Class I, Must be earthed
220-240V~ 50/60HZ
>3 hours after minimum 24Hr charge
3.6V 1.5Ah Ni-Cd cells
0 o C~+25 o C
Polycarbonate
Polycarbonate
IP65
