LED Group Robus R8EM Quick Start Manual

Specification:
Installation:
1. Please note the requirement to dispose of Waste Electrical & Electronic Equipment separately from household waste (WEEE
marked with crossed out wheelie bin symbol).
2. Please consider your role in contributing to re-use and recycling by returning this product at end of life to a collection centre
for waste electrical equipment or a Civic Amenity site, or to a retail outlet from which you are purchasing a replacement.
3. This equipment may contain substances that are hazardous to health and the environment if disposed of carelessly. It is
important that it is separated from normal household waste and recycled in the WEEE chain
4. The "crossed out wheelie bin symbol" on a product indicates this equipment must not be disposed of in normal household
waste, but should be disposed of according to local WEEE regulations
The Installation must be carried out by an electrician
LED Group
Western Retail Park
Nangor Road
Dublin 12
Ireland
Issue 1 220110
R8EM
Maintained Exit sign bulkheads
Please read instructions before commencing installation and
retain for future reference.
incl.
Model No.
Operating mode
Lamp
Dimensions
Insulation
Supply voltage
Lumen oupput
Supply current
Discharge Duration
Battery
Battery Life
Storage temperature
Operating ambient temperature
Case materials
Flammability
Connection:
Suitable for mounting on a normally flammable surface
Green LED indicator indicates battery charging mode
Safety and performance in accordance with EN60598-1, EN60598-2-22
EN50082-1, EN61000-3-2, EN61000-3-3
Suitable for Indoor use, wall mounted
! Warning. Isolate mains supply before installing or servicing
1. Remove front panel and gear tray and knock out relevant cable entry point
2. Mark appropriate fixing points on wall; check that fixings will not impinge on
concealed cables of pipes before drilling holes.
3. Introduce supply cable. ( Normally, the emergency fitting must be
powered from the lighting circuit feed)
4. Write installation date on battery
5. Connect wires from unswitched supply from a tamper proof test switch (key operated
with automatic re-set), brown to "PL", Blue to "N" and green/yellow to earth marked
terminals on gear tray. In the maintained emergency unit;
for lamp always on, link "PL" to terminal "SL"
for lamp switched connect switched live wire to terminal "SL"
Note: if "SL" not connected, fitting works as non-maintained
6. Fix gear tray in position and refit appropriate panel.
7. Switch on supply: In the non-maintained unit the green led should come on indicating
correct battery charge has started. The lamp only lights if the mains supply fails.
In the maintained unit, the green led will come on indicating correct battery charge has
started and the lamp will light (if switched live on). When supply to the unswitched live
is lost, battery will operate lamp in emergency mode.
Information for the Product user
Tel: +353 1 7099000
Fax: +353 1 7099060
Email: info@led.ie
Website: www.led.ie
R8EM
maintained
T5 8W fluorescent tube
(L)430mm x (H)200mm x 60mm
Class I, Must be earthed
240V 50Hz
15
0.1A
>3 hours after minimum 36Hr charge
2.4V x 4Ah Ni-Cd cells
up to 4 years normal use
-5°C ~ +60°C
5°C ~ +25°C
Steel/ PC sign panel
With stands 850°C Glow wire test
Screw terminals
ISO 9001:2008
Q UAL IT Y ASSU RE D CO MPANY
