2w led high voltage triangular cabinet downlight

Advertisement

ROBUS
QUALITY PRODUCTS BY LED GROUP

Specification:

Installation:

1. Please note the requirement to dispose of Waste Electrical & Electronic Equipment separately from household waste (WEEE
marked with crossed out wheelie bin symbol).
2. Please consider your role in contributing to re-use and recycling by returning this product at end of life to a collection centre
for waste electrical equipment or a Civic Amenity site, or to a retail outlet from which you are purchasing a replacement.
3. This equipment may contain substances that are hazardous to health and the environment if disposed of carelessly. It is
important that it is separated from normal household waste and recycled in the WEEE chain
4. The "crossed out wheelie bin symbol" on a product indicates this equipment must not be disposed of in normal household
waste, but should be disposed of according to local WEEE regulations
The Installation must be carried out by an electrician
LED Group
Western Retail Park
Nangor Road
Dublin 12
Ireland
Issue 1 210214
2W LED High Voltage
Triangular Cabinet Downlight
R
R3011LED240CW-13
Please read instructions before commencing installation and
retain for future reference.
Model No.
Supply Voltage:
Power Consumption:
Lumen Output:
Colour Temperature:
CRI:
Beam Angle:
Operating Temp Range:
IP Rating:
Safety Classification:
Dimensions:
Weight:
Warranty:
Installation:
Complete with 1.5m Cable
Warning! To prevent overheating, the fitting must not be covered by thermal
insulation
!Electrical products can cause death or injury, or damage to property. This product must
be installed only by a competent electrician.
1 Ensure mains supply is switched off before commencing work
2 Remove circular fitting body from triangular surround
3 Choose suitable location for mounting the fitting, mark appropriate fixing points on wall
or ceiling; check that fixings will not impinge on concealed cables of pipes before fixing
the fitting
4 Fix surround to surface with screws provided
5 Connect cables brown (Live) and blue (Neutral) to supply
6 Push fitting body into place in triangular surround
Note: for recessed installation, make 55 mm cut-out in mounting surface and push in
circular fitting body into place, discard triangular surround.

Information for the Product user

Tel: +353 1 7099000
Fax: +353 1 7099060
Email: info@led.ie
Website: www.led.ie
R3011LED240CW-13
220-240V~50/60Hz
2W
95 lm
4000K - 4200K
>75
120°
-5°C < ta < 45°C
20
Class II
Width 120mm, height 140mm, depth 44mm
0.25 Kg
2 year
surface or recessed mounting
ISO 9001:2008
Q UAL IT Y ASSU RE D CO MPANY
Page 1
