LED Group ROBUS R8MU Instructions

Specification:
Installation:
Accessories:
1. Please note the requirement to dispose of Waste Electrical & Electronic Equipment separately from household
waste (WEEE marked with crossed out wheelie bin symbol).
2. Please consider your role in contributing to re-use and recycling by returning this product at end of life to a
collection centre for waste electrical equipment or a Civic Amenity site, or to a retail outlet from which you are
purchasing a replacement.
3. This equipment may contain substances that are hazardous to health and the environment if disposed of carelessly.
It is important that it is separated from normal household waste and recycled in the WEEE chain
4. The "crossed out wheelie bin symbol" on a product indicates this equipment must not be disposed of in normal
household waste, but should be disposed of according to local WEEE regulations
The Installation must be carried out by an electrician
LED Group
Tel: +353 1 7099000
Western Retail Park
Fax: +353 1 7099060
Nangor Road
Email: info@led.ie
Dublin 12
Website: www.led.ie
Ireland
Issue 1 161110
R8MU & R8MUST
Maintained and Non-maintained
emergency bulkhead
Please read instruction before commencing installation
and retain for future reference.
Model No.
Operating mode
Lamp
Dimensions
Insulation
Supply voltage
Supply current
Ballast lumen factor
Rated luminaire output
Discharge Duration
Battery
Battery Life
Storage temperature
Operating ambient temperature
Weight
Case material
Diffuser material
Cut-out
Flammability
Ingress Protection
Suitable for mounting on a normally flammable surface
Green LED indicator indicates battery charging mode
Safety and performance in accordance with EN60598-1, EN60598-2-22
EN50082-1, EN61000-3-2, EN61000-3-3
Suitable for Indoor use, wall or ceiling mounted
Complies with EN60598 (Bs4533)
! Warning. Isolate mains supply before installing or servicing
Surface mounting
1. Remove diffuser by pressing the latch on the side of the unit and sliding the cover off.
2. Using a screwdriver remove the 2 screws and pull the gear tray away from fitting.
3. Mark appropriate fixing points on wall or ceiling; check that fixings will not impinge
on concealed cables of pipes before drilling holes.
4. Drill out cable entry hole and introduce supply cable. ( Normally, the emergency
fitting must be powered from the lighting circuit feed)
5. Line up the keyholes in the fitting with the 2 screws in the wall
6. Push the fitting against the wall and slide down, tighten the screws making sure the
fitting is secure.
7. Please proceed to stage point 8. Below.
Dropped Glass legend accessory R8MULK
Information for the Product user
R8MU R8MUST
Maintained Self Test
T5 8W fluorescent tube
348mm x 173mm x 77mm
Class I, Must be earthed
240VAC 50Hz
0.1A 0.03A
0.24
70 Lumens
>3 hours after minimum 24Hr charge
2.4V 4Ah Ni-Cd (2x1.2V cells)
up to 4 years normal use
-5°C ~ +60°C
5°C ~ +25°C
1.2Kg
ABS
Polycarbonate
280mm x 135mm
Withstands 850°C Glow wire test
IP40
Q UAL IT Y ASSU RE D CO MPANY
ISO 9001:2008
