Voxx Electronics Pursuit PRO9056TWE Installation Manual

Vehicle remote start system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Table Of Contents:
Before You Begin
Wire Harnesses Quick View
Mounting Of The Major Components
Pin Power Harness Wiring
12 Pin Accessory Input/Output Harness Wiring
4 Pin GND, Alarm Bypass Output & Parking Light Harness
Door Unlock Harness Wiring
Telematic Port Information
6 Pin Antenna Harness
Diesel Engine Setting Information
DBI Port Information
Engine Monitoring Selections, (Voltage Tach, DBI, Hybrid,)
Tach Programming
Diagnostics Access & Information
Testing Your Installation Hood Pin Safety
Manual Override Safety Testing and Operation
Manual Override Safety Testing and Operation
Completing Your Installation
Programming Transmitters
Programming Alarm Feature Bank 2
Tach Programming
Circuit Wiring Layout
PATENTED: www.voxxintl.com/company/patents
Model PRO9056TWE
Installation Manual
Vehicle Remote Start System
Page 2
Page 3 - 4
Page 5
Page 6 - 7
Page 7 - 9
Page 11
Page 12 - 13
Page 13
Page 13
Page 14
Page 14
Page 14
Page 14 & 21
Page 15
Page 15
Page 15 - 16
Page 15 - 16
Page 18
Page 19
Page 19 & 20
Page 14 & 21
Page 23
1
128-9296
1/24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit PRO9056TWE and is the answer not in the manual?

Questions and answers

Related Manuals for Voxx Electronics Pursuit PRO9056TWE

Summary of Contents for Voxx Electronics Pursuit PRO9056TWE

  • Page 1 Model PRO9056TWE Installation Manual Vehicle Remote Start System Table Of Contents: Before You Begin Page 2 Wire Harnesses Quick View Page 3 - 4 Mounting Of The Major Components Page 5 Pin Power Harness Wiring Page 6 - 7 12 Pin Accessory Input/Output Harness Wiring Page 7 - 9 4 Pin GND, Alarm Bypass Output &...
  • Page 2 Before You Begin PROFESSIONAL INSTALLATION IS STRONGLY RECOMMENDED Roll down window to avoid locking the keys in the vehicle during installation Avoid mounting components or routing wires near hot surfaces or near moving parts like the steering wheel as it may prevent proper operation of the vehicle Tape or loom wires under the hood and dash for protection as well appearance...
  • Page 3 12 Pin Main Wiring Harness #1124295 1 Green/Orange Tachometer Input 2 Green/Yellow Glow Plug Input 3 Green Door Unlock 4 Brown/Black (+) Inhibit /Shutdown To Brake Switch 5 Brown (+) Inhibit / Shutdown To Brake Switch 6 Gray (-) Inhibit Neutral Start Switch 7 Black/Yellow Pulse During Crank Output (-) 8 Black/Red...
  • Page 4 6 Pin Power / Start Harness #1123742 1 Blue Ignition 1 (+) 2 Red/White Battery 1 - 12V (+) 3 Green Ignition 2 (+) 4 Purple Accessory (+) 5 Red Battery 2 - 12V (+) 6 Yellow Starter Output 4 Pin 2nd Main Harness #1124294 1 Black Chassis Ground 2 White/Red...

  • Page 5: Installation Of The Major Components

    This Remote Start is to be used in vehicles with AUTOMATIC TRANSMISSIONS only! Although this system is a sophisticated device with many advanced features, IT MUST NOT be installed into a vehicle with manually operated transmission. Doing so may result in serious personal injury and property damage! INSTALLATION OF THE MAJOR COMPONENTS: CONTROL MODULE: PART # 1365394 Select a mounting location inside the passenger compartment (up behind the dashboard).
  • Page 6 IMPORTANT! DO NOT PLUG THE EIGHT PIN MAIN POWER HARNESS OR THE MULTI PIN INPUT / OUTPUT HARNESS INTO THE CONTROL MODULE UNTIL ALL CONNECTIONS TO THE VEHICLE HAVE BEEN MADE. AFTER SELECTING YOUR TARGET WIRES AS DEFINED BELOW, DISCONNECT THE NEGATIVE BATTERY CABLE FROM THE VEHICLE BATTERY PRIOR TO MAKING ANY CONNECTIONS.
  • Page 7 In both mechanical and electrical neutral start switch configurations, the connection of the Yellow wire will be made to the low current start solenoid wire of the ignition switch harness. This wire will have +12 volts when the ignition switch is turned to the start (crank) position only. This wire will have 0 volts in all other ignition switch positions.
  • Page 8 3 Green Wire: Door Unlock (-) Output The Green wire provides a (-) Negative Pulse when the transmitter is used, while the vehicle is running by remote start, to unlock the doors. See Page 12-13 for use of this unlock output. 4 Brown w/ Black trace Wire: Positive Inhibit Input The Brown w/ Black Trace wire provides an instant shutdown for the Remote Start Control module whenever it gets + 12 volts.
  • Page 9 9 Black w Blue trace Wire: Pulsed Ground Output Before Start The Black w/ Blue Trace wire will provide a 1 second 300 mA pulsed ground output 500mS before GWR becomes active as well as when the transmitter is used to disarm the system. Typical use for this output would be to disarm a factory theft deterrent system to prevent false triggering of the factory alarm when the remote start unit engages or when the system is used to unlock the doors.
  • Page 10 A. Sensor By Pass: If there is a Non Plug in Sensor used with the alarm system and it is not shunted during the Remote Start activation period, then vibration or noise from the running vehicle can cause the alarm to trigger. In this case, connect the Light Blue Wire to terminal #86 of a external relay.
  • Page 11 4 Pin Additional Harness: Parking Light Flasher I/O Siren & Ground 1 Black: Chassis Ground Connect the Black wire to a known vehicle ground source or to a solid clean metal part of the chassis. Be certain to remove any paint or grease and secure this wire with a self tapping screw and ring terminal. 2 White w/ Red trace Wire: Parking Light Relay Input Wire This wire is the common contact of the on board parking light flasher relay.
  • Page 12 3 Wire Ground Switched Door Lock Circuits: Use of Green wire from main connectors harness. In this application, the Green wire of the main wiring harness provides a ground pulse when the transmitter button is pressed and held for 3 seconds while running under control of the remote start. Connect the Green wire to the low current ground signal wire from the factory door unlock switch to the factory door unlock relay.
  • Page 13 Resistive Circuits, Multiplex Circuits As Well As 4 Wire Polarity Reversal and 5 Wire Alternating 12 Volt Door Lock Control Circuits These applications require the use of additional components which may include relays, fixed resistor, a door lock interface, or a data module. You can search the vehicle @ www.avxtech1.com, Flash-It.com for vehicle specific information, or contact our tech service line or web site for additional information.
  • Page 14 DIESEL ENGINE SETTINGS: NOTE: When selecting Diesel operation, (Bank 3 Feature #12), over gasoline, the only change is to the ignition circuits. When Diesel is selected, the ignition circuits will power up 10, 15, or 20 seconds before the start circuit. The intent of this feature is to allow the glow plug warming required by some diesel engines.

  • Page 15: Testing Your Installation

    DIAGNOSTICS: Enter Bank 3 and turn on selectable feature # 10 as described on the front pages of this manual. NOTE: Diagnostic mode is a temporary mode. Once you have accessed the diagnostic mode, the unit will pause for two seconds then begin to flash the last stored shut down code. This code will be displayed three times in succession, then the unit will automatically exit the diagnostic on mode.

  • Page 16: Mechanical Neutral Safety Switch Considerations

    To Exit Remote Start Override Mode: 1) With the system disarmed, Press and Hold the PBLED on. 2) Turn the ignition switch on, off, on, off, on, off. 3) The LED turns off indicating that the R/S unit is fully functional one again. DO NOT RELEASE THIS VEHICLE TO THE CONSUMER UNTIL YOU CONFIRM THE OPERATION OF THE MANUAL SHUT DOWN / ENABLE FEATURE.

  • Page 17: Key In Sensor Circuits

    KEY IN SENSOR CIRCUITS: If the vehicle you are working on does not have or you cannot locate the ECM reference wire, there are two alternatives available. Although not preferred, the vehicle Key In Sensor may be reconfigured to allow a margin of safety and will prevent the vehicle with a Mechanical Neutral Start Switch from starting in gear.

  • Page 18: Completing The Installation

    NOTE: A second 4002 series diode may be required to maintain the integrity of the hood open, shut down circuit. If this is the case, it must be installed as shown in the diagram above. The anode (Non Striped) side must be connected to the Gray/Black wire of the Remote Start Unit.

  • Page 19: Programming Bank 1 (Transmitters)

    The transmitters are pre-programmed from the factory, If you find you need to program new or additional transmitters follow the instructions below. PROGRAMMING BANK 1 (TRANSMITTERS): 1) Turn the ignition key to the ON position. 2) Press and release the valet/programming switch 3 times (Siren Chirps Once). 3) Press the start button of each transmitter you want programmed until you hear a chirp from the horn or siren or until the lights flash.
  • Page 20 128-9296 20/24...

  • Page 21: Programming Bank 3 (Remote Start )

    PROGRAMMING BANK 3 (REMOTE START ): You can enter Bank 3 from Bank 2 by turning the ignition key off then on after you've made the changes you wanted in Bank 2, (Siren Chirps 3 times), You can also go right to bank 3 by: 1) Turn the ignition key to the on position.
  • Page 22 128-9296 22/24...
  • Page 23 NOTES: 128-9296 23/24...
  • Page 24 Black/Red (- Pulse After Shut Down Output) Brown (+ Inhibit Wire) Green (Unlock Output) Black/LT.Green (- Pulse After Start Output) Black/Blue (- Pulse Before Start Output) Brown/Black (+ Inhibit/Shut Down From Brake Switch) 2014 Voxx Electronics Corporation 150 Marcus Blvd. Hauppauge, N.Y. 11788 128-9296 128-9296 24/24...
