Voxx Electronics PURSUIT PROSEC Quick Installation Manual

1 3 5
2 4 6
1 White
Parking Light (30) Output
2 Black
Ground Input (-)
3 White/Red Parking Light (87) Input
4 Yellow Ignition Input (+)
5 White/Black Siren Output (+)
6 Red Battery 12V Input (+)
Replacement Part #4120461
1 2 3 4
1 White Data RX
2 Black Ground (-)
3 Blue Data TX
4 Red
Battery 12V (+)
Not Included
1 Blue LED Output (-)
2 Red Battery 12V (+)
1 Black Ground (-)
2 Gray Valet Switch Input
Replacement Part #4120474
87
87A
86 85
30
85 Red Ignition Input (+)
86 Orange Starter Kill Input (-)
87A
Black Starter Interrupt - Key Side
30
White/Black Starter Interrupt - Motor Side
Replacement Part #4360828
P
Replacement Part #4360833
1 2 3 4
1 Green
2 Blue
3 Black
4 Red
Not Included
1 2 3
1
Blue
2 White
3 Black
4 Red
Not Included
PROSEC
Security w/Keyless Entry
System Layout
FLCART Dock
Data RX
Data TX
Ground (-)
Battery 12V (+)
4
Data TX
Data RX
Ground (-)
Battery 12V (+)
Shock Sensor
Part #4700033
4 Red Battery 12V (+)
4
3 Black Data TX
3
2 Green Warn Away Input (-)
2
1 Blue Full Trigger Input (-)
1
20 Blue
Trunk Shunt Input (+)
19 Orange
Starter Kill Relay / Anti-Grind Output (-)
18 Red/Black
Disarm 2 Input
17 Black/White
Horn Output (-) (NOC 9)
19 20
16 Red/Yellow Disarm 1 Input
15 Dk. Blue/Black Ch. 3 Alt Output (-) (NOC 8)
17 18
14 Green/Black Arm 2 Input
15 16
13 Green/White Domelight Output (-) (NOC 7)
13 14
12 Green/Yellow Arm 1 Input
11 Lt. Blue/Green Ch. 5 AUX Output (-) (NOC 6)
11 12
10 Dk. Green
Instant Trigger Input (-)
9 10
9 Green/Lt. Blue
Ch. 4 AUX Output (-) (NOC 5)
7 8
8 Lt. Green
Trunk Trigger Input (-)
5 6 7 Dk. Blue
Trunk Output (-) (NOC 4)
6 Gray/Black
Hood Input (-)
3 4
5 White/Blue
Headlight Output (-) (NOC 3)
1 2
4 Purple/Brown
Door Trigger Input (- / +)
3 Green Unlock Output (-) (NOC 2)
2 Empty Empty
1 Red Lock Output (-) (NOC 1)
4
4 Red Battery 12V (+)
3 Black Ground (-)
3
2 Blue Data TX
2
1
White Data RX
1
19 20
17 18
15 16
13 14
This Harness is included with the FLCART.
11 12
For Wire Information and Diagram Please Refer to Vehicle
Specific FlashLogic Install Guide.
9 10
Visit www.FlashLogic.com for More Information.
7 8
Not Included
5 6
3 4
1 2
Compatible RF Kits
2018 Voxx Electronics. All Rights Reserved.
Replacement Part #4120459
Replacement Part #4120460
Not Included
PR1BZ
PR1BZLR
PR1BTWZ
PR5BZ
