Voxx Electronics Pursuit PRO9056Z Installation And Reference Manual

Vehicle remote start system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Thank you for trusting Pursuit products! If you are a consumer, please note:
Professional installation is strongly recommended.
This manual assumes the installer has adequate knowledge of the following expertise. Therefore, it does not
cover these topics in detail:
•
12-volt electronics
•
Testing and verifying circuits
•
Making safe and lasting wiring connections
•
Factory ignition, power, lighting, data bus and sensing systems
•
Factory systems and components to avoid
•
Safe wire routing, circuit protection and product placement
•
Access to vehicle-specific technical information
In addition, this manual assumes the installer has the proper tools, skill and facilities to perform a professional installation.
Performing an improper installation could result in damage to the vehicle or its components, improper system function,
unsafe vehicle operation or physical injury. Such instances would not be covered by the vehicle manufacturer's warranty,
nor by Voxx Electronics, Inc.
Detailed Descriptions
2
2
3
4
6
6
RF Antenna Kit
6
6
Telematics
6
7
Setup Options
7
Remote Programming
8
Keyless Control
10
Remote Start Control
14
System Operation
14
Remote Operation
2020 Voxx Electronics Corporation. All rights reserved.
PRO9056Z
Vehicle Remote Start System
Installation and Reference Guide
Quick Reference
15
System Programming
15
Programming Mode Entry / Exit
16
Feature Bank Options
17
Data Port Protocol
17
17
Alarm Override
18
18
18
System Diagnostics
18
19
Wiring Diagrams
19
Door Lock Connections
22
Full System Connections
PRO9056Z_RevD_07/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit PRO9056Z and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Voxx Electronics Pursuit PRO9056Z

Summary of Contents for Voxx Electronics Pursuit PRO9056Z

  • Page 1: Table Of Contents

    Data Bus Interface (DBI) Telematics System Diagnostics Weblink Programming Troubleshooting Remote Start Setup Options Remote Programming Wiring Diagrams Keyless Control Door Lock Connections Remote Start Control Full System Connections System Operation Remote Operation 2020 Voxx Electronics Corporation. All rights reserved. PRO9056Z_RevD_07/20...

  • Page 2: Wire Harness Colors And Functions

    Detailed Descriptions: Wire Harness Colors and Functions Power Connector (6-pin High-Current Connector) See page 22 for the full system diagram. These wires are listed in order of their placement in the harness connector. 1. YELLOW – Starter Output for Remote Start (+) The YELLOW wire supplies 12-Volt (+) to the vehicle’s starter wire when remote start is enabled, and turns off once the vehicle is started.

  • Page 3: Notification Connector

    Detailed Descriptions: Wire Harness Colors and Functions Notification Connector (4-pin connector) See page 22 for the full system diagram. These wires are listed in order of their placement in the harness connector. 1. WHITE – Parking Light Relay Output (Internal Relay Pin 30) At its default setting, the WHITE wire supplies 12-Volt (+) or Ground (-) to the vehicle's park light wire based on the connection of the relay input (WHITE/RED wire).

  • Page 4: Input / Output Connector

    Detailed Descriptions: Wire Harness Colors and Functions Input / Output Connector (14-pin connector) See page 22 for the full system diagram. These wires are listed in order of their placement in the harness connector. 3 5 7 9 11 13 4 6 8 10 12 14 1.
  • Page 5 Detailed Descriptions: Wire Harness Colors and Functions Input / Output Connector (14-pin connector) (Cont.) See page 22 for the full system diagram. These wires are listed in order of their placement in the harness connector. 10. Empty The Trunk Release function is not supported on this model. 11.

  • Page 6: External Components

    Detailed Descriptions: External Components RF Antenna / LED / Programming Port The long-range antenna kit (included) plugs into a 6-pin connector on the Pursuit module. 1. Mount the supplied antenna/receiver to a clear spot on the vehicle’s windshield that will not block the driver’s vision.
  • Page 7 Detailed Descriptions: Setup Options Bank 1: Add / Remove Remote Controls See page 15 for Programming Instruction. Remote programming is located in Feature Bank 1. This system will Auto Program basic functions of the remote with one (1) button press. Basic functions are channels 1-3, Lock, Unlock, and Trunk / Start. Feature Bank 1 Descrip�on 1 Auto Program / Start...
  • Page 8 Detailed Descriptions: Setup Options Keyless Control (Bank 2) See page 15 for Programming Instruction. Op�ons Feature Bank 2 1 Chirp 2 Chirp 3 Chirp 4 Chirp 5 Chirp 6 Chirp 1 Lock / Unlock Func�on 500ms 3.5sec 500ms L, DBL UL DBL L, 500ms UL DBL L, DBL UL 500ms L, 350ms UL...
  • Page 9 Detailed Descriptions: Setup Options Keyless Control (Bank 2) (cont.) See page 15 for Programming Instruction. Feature 8: Horn Output Duration Function: Set the horn output to activate for a set time. Setting Choices: • Option 1 - Output pulses for 16 milliseconds. •...
  • Page 10 Detailed Descriptions: Setup Options Remote Start Control (Bank 3) See page 15 for Programming Instruction. Op�ons Feature Bank 3 1 Chirp 2 Chirp 3 Chirp 4 chirp 5 Chirp 6 Chirp 1 Defrost Output 2 RS Start No�fica�on 15min 3 RS Run�me 20min 45min 60min...
  • Page 11 Detailed Descriptions: Setup Options Remote Start Control (Bank 3) (cont.) See page 15 for Programming Instruction. Feature 5: Engine Confirmation Function: Determine how the system knows if remote start was successful. Setting Choices: • Option 1 - Determined by measurement from the Purple/White Tach Input wire. •...
  • Page 12 Detailed Descriptions: Setup Options Remote Start Control (Bank 3) (cont.) See page 15 for Programming Instruction. Feature 12: Diesel (Pre-Start) Delay Function: After remote start ignition is activated, set delay of crank to accommodate diesel engines. Setting Choices: • Option 1 - Vehicle starts immediately after remote start ignition. •...
  • Page 13 Detailed Descriptions: Setup Options Remote Start Control (Bank 3) (Cont.) See page 15 for Programming Instruction. Feature 20: Pulse During Crank Output Function (BLACK/YELLOW) Function: Set the functionality of the programmable output. Setting Choices: • Option 1 - Pulse During Crank. •...
  • Page 14 Detailed Descriptions: System Operation Remote Control Operation This system includes two (2) remote controls. The matrix below describes the basic functions of each remote. See Owners Guide for complete remote operation instruction. One Button Remotes (1-Way) - Standard Configuration Bu�on Ac�on Func�on Press 1x...
  • Page 15 Quick Reference: System Programming Programming Mode Entry and Exit Procedure Once the system is installed and powered up, you will use the vehicle ignition, valet button and a programmed remote control to set all system options. Feature options are divided into categories, or Banks, as described throughout this section.
  • Page 16 Quick Reference: System Programming Bank 1: Remote Control Programming Options See page 7 for a detailed description. Feature Bank 1 Descrip�on 1 Auto Program / Start Press Start bu�on on remote Bank 2: Keyless Options See pages 8-9 for detailed descriptions. Op�ons Feature Bank 2 1 Chirp...

  • Page 17: Tach Function

    Quick Reference: System Programming & Diagnostics Data Port Protocol Selection The default data port protocol of this model is ADS (iDatalink 2-Way). This model is capable of detecting the correct data port protocol (ADS or DBI) and automatically configuring Feature Bank 2; Feature 18. To initialize the detection procedure: 1.

  • Page 18: Silent Lock And Unlock

    Quick Reference: System Programming & Diagnostics Silent Lock and Unlock (Security/Keyless Mode Only) Program the Pursuit system to Lock and Unlock without notification beeps. 1. Turn the ignition ON then OFF. 2. Press and release the valet button three (3) times. The system will respond with one (1) beep for ON or two (2) beeps for OFF.
  • Page 19 Quick Reference: Wiring Diagrams Door Lock Connections Negative-Trigger Door Locks Verification: The vehicle wires register Ground when the Lock and Unlock switches are activated. RED ( - ) Lock Output Lock Vehicle Door Lock Control Relays Unlock GREEN ( - ) Unlock Output Positive-Trigger Door Locks Verification: The vehicle wires register 12V+ when the Lock and Unlock switches are activated.
  • Page 20 Quick Reference: Wiring Diagrams Door Lock Connections Single-Wire Negative Multiplex Door Locks (Relays required) Verification: The vehicle wire registers variable Ground values when the Lock and Unlock switches are activated. Please consult the vehicle-specific wire and location chart for resistor values. Ground Fused +12 Volt RED ( - ) Lock Output...
  • Page 21 Quick Reference: Wiring Diagrams Door Lock Connections Reverse-Polarity Door Locks (Relays required) Verification: The vehicle wires rest at Ground and register 12V+ when the Lock and Unlock switches are activated. Fused +12 Volt Battery Souce RED ( - ) Lock Output Lock To Door Lock Motor Unlock...
  • Page 22 Quick Reference: Wiring Diagrams VOXX PRO9056Z_RevD_07/20...
