Quick Links

Lock/Arm
Check with your installation center for features and functions operational on your system.
To Operate System:
1) Press the lock button to lock the doors and arm the alarm if installed.
2) Press the unlock button to unlock the doors and disarm the alarm if installed.
3) Press and hold the Trunk/Start button for 3 seconds to unlock the trunk.
4) Press the Trunk/Start button two times in succession to start the vehicle. The vehicle will start
and run the predetermined time set up during installation (5 to 60 minutes selectable).
Anytime during the run cycle, enter the vehicle by first unlocking the doors with your transmitter,
insert your key and turn it to the run, NOT START, position, then step on the brake, the vehicle is
now in control of the ignition key.
NOTE: For push to start vehicle systems, simply enter the vehicle with your key in hand, and
step on the brake.
Consult your installation center for operation and information on convenience options 1 & 2
which may have been connected or added to your vehicle.
PATENTED: www.voxxintl.com/company/patents
Model PE2LCD
Operators Manual
RF Upgrade Kit
PRESTIGE
S
24
A
Trunk Release/ Remote Start
1 2
Z
Z
Option
F Function Button
IGN
INHIBIT
AM
PM
Unlock/Disarm
128-9452
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Prestige PE2LCD and is the answer not in the manual?

Questions and answers

Summary of Contents for Voxx Electronics Prestige PE2LCD

  • Page 1 Model PE2LCD Operators Manual RF Upgrade Kit PRESTIGE Trunk Release/ Remote Start Option F Function Button INHIBIT Lock/Arm Unlock/Disarm Check with your installation center for features and functions operational on your system. To Operate System: 1) Press the lock button to lock the doors and arm the alarm if installed. 2) Press the unlock button to unlock the doors and disarm the alarm if installed.
  • Page 2 Quick Stop Mode: With vehicle running, if you wish to make a quick stop and leave the vehicle running, once you arrive at your destination: a) place the gear selector in Park, b) set the parking brake, c) with your foot off the brake, press the transmitter button two times in succession. The vehicle will now be under control of the remote start system.
  • Page 3 BUTTON TO SELECT To program parking meter countdown timer, select tone or vibrate, alarm clock set on/off, Fahr- enheit or Celsius scale, or operate a second vehicle with similar Voxx Electronics remote start alarm system follow the chart below. TRANSMITTER...
  • Page 4 ADDITIONAL REMOTE FEATURES: The two way remote control unit allows you to access status information from the vehicle, check temperature, light the display, toggle the transmitter from beep tones to vibrate mode, initiate daily start timer, and temperature start. Selection of these and other features are shown below: NOTE: Transmitter must be within operating range of the vehicle, approximately 2500ft.
  • Page 5: Battery Indicator

    NOTE: To insure accurate 24 Hour Start up, it is advisable to reset the start time periodically as time may drift slightly each day. Timing Count Down The unit offers an additional count down timer for situations where an alert tone may be needed to remind you of something important.
  • Page 6: Alarm Clock

    ALARM CLOCK This icon will be toggled on and off when the “F” + Trunk/Key buttons are pressed simul- taneously. The feature must be set in the feature selection menu of the transmitter. COUNT DOWN TIMER The unit offers an additional count down timer for situations where an alert tone may be needed to remind you of something important.
  • Page 7 The one way transmitter included with this kit operates in a similar fashion as the two way trans- mitter with respect to the buttons and are shown below for your reference. Lock Button Press once to lock and arm alarm. Unlock Button Press and hold 3 seconds for panic Press once to unlock and disarm alarm.
  • Page 8 (Alarm & Keyless Systems Only) PROGRAMMING YOUR CUSTOM OVERRIDE CODE Unlike override switches easily found, and defeated, this security system allows the consumer to program a personal override code, offering a higher level of security. To take advantage of this option, programmable feature # 9 must be selected for the Custom Code Option.
  • Page 9: Remote Starting The Vehicle

    (Alarm Systems Only) MANUALLY OVERRIDING YOUR SYSTEM: USING THE CUSTOM CODE OVERRIDE Assuming the override code programmed has not been changed, and the default override code of 11 is in the system’s memory. 1) Enter the vehicle and turn the ignition switch to the on position. NOTE: The siren will sound.
  • Page 10 OPERATING ON AUTOMATIC START UP TIMER MODE Your system has the ability to automatically start the vehicle every 2 or 4 hours over a 48 hour period. This feature is especially useful in cold climates where the only means to keep the engine and engine fluids warm is to periodically start the engine.
  • Page 11 From step 3 above: a) Press and release the valet/programming button 3 additional times to get to channel 4, then Press any unused transmitter button or button combination to program channel 4. b) From a, press and release the valet/programming button 1 time to get to channel 5, then press any unused transmitter button or button combination to program.channel 5 c) From b, press and release the valet/programming button 1 time to get to channel 6, then press any unused transmitter button or button combination to program channel 6 .
  • Page 12: Fcc Compliance

    NOTE: The manufacturer is not responsible for any radio or TV interference caused by unau- thorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment © 2015 Voxx Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 128-9452 Page 12...
