SPARC T3-4 Server
Getting Started Guide
This guide describes the minimum steps you must perform to power on and boot Oracle's SPARC T3-4 server
for the first time using the preinstalled Oracle Solaris Operating System (Oracle Solaris OS).
For complete installation instructions, refer to the SPARC T3-4 Server Installation Guide.
SPARC T3-4 Server
FIGURE 1
Shipping Contents
Quantity
Item
1
Server
4
AC power cords (if ordered)
1
RJ-45 to DB-9 crossover adapter
1
RJ-45 to DB-25 crossover adapter
1
Ethernet cable
1
Antistatic wrist strap
1
Rackmount kit
Various documents
1
Advertisement
Table of Contents
Related Manuals for Sun Oracle SPARC T3-4
Summary of Contents for Sun Oracle SPARC T3-4
- Page 1 SPARC T3-4 Server Getting Started Guide This guide describes the minimum steps you must perform to power on and boot Oracle’s SPARC T3-4 server for the first time using the preinstalled Oracle Solaris Operating System (Oracle Solaris OS). For complete installation instructions, refer to the SPARC T3-4 Server Installation Guide.
-
Page 2: Before You Begin
Before You Begin For quick installation and configuration, follow these steps. For more detailed information, refer to the complete online product documentation set at: http://docs.sun.com/app/docs/prod/sparc.t3.4#hic Understand the following information before you set up the server for the first time: Do not apply power until instructed to do so – This system includes a service processor (SP) that is used to ■... -
Page 3: Quick Setup Instructions
FIGURE 1 2. Place the server in its intended location for verification. For rackmounting instructions, refer to the online SPARC T3-4 Server Installation Guide. 3. Connect a serial cable between the server’s SER MGT port and a terminal device ( FIGURE 2 This connection provides your initial communication with the SP. - Page 4 Server Connections FIGURE 2 4. (Optional) Connect an Ethernet cable between the server’s NET MGT port and the network to which future connections to the SP and host will be made ( FIGURE 2 After the initial configuration of the system using the SER MGT port, communication with the SP and host is usually performed through this Ethernet interface.
- Page 5 7. At the terminal device, log in to the SP as root with a password of changeme. SUNSP00144FAC732F login: root Password: changeme . . . -> After a brief delay, the SP prompt is displayed (->). At this point, there are many commands you can perform using the Integrated Lights Out Manager (ILOM) interface.
-
Page 6: Accessing Additional Information
Accessing Additional Information You can view, print, and download additional information for this product from the following URLs: Oracle’s SPARC T3-4 server documentation set, including important documents such as product notes: ■ http://docs.sun.com/app/docs/prod/sparc.t3.4#hic A broad selection of Oracle Sun documentation, including localized versions: ■...
