May, 2021
BP-AVLAT
AVALON ROUND ACCENT TABLE
Assembly Instructions - Important:
Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when
assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or
information on other products, please visit our website: www.officestar.net or call or write us.

Advertisement

loading
Need help?

Need help?

Do you have a question about the AVALON BP-AVLAT and is the answer not in the manual?

Questions and answers

Related Manuals for OSP Home Furnishings AVALON BP-AVLAT

Summary of Contents for OSP Home Furnishings AVALON BP-AVLAT

  • Page 1 May, 2021 BP-AVLAT AVALON ROUND ACCENT TABLE Assembly Instructions - Important: Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or information on other products, please visit our website: www.officestar.net or call or write us.

  • Page 2: Limited Warranty

    Monday through Friday 8:00 a.m. - 3:30 p.m. Pacific Time. To make a warranty claim, contact Parts Department. Provide model number, proof of purchase, description of the problem and obtain return authorization. At its option OSP Home Furnishings will: (a) Supply compatible ®...

  • Page 3: Parts List

    PARTS LIST (1) Top Panel (1 PC) (2) Connection Panel (1 PC) (3) Post (1 PC) (4) Base Panel (1 PC) (5) Foot Pad (3 PCS)

  • Page 4: Hardware List

    HARDWARE LIST...
  • Page 5 STEP 1 Attach Connection Panel (2) to Post (3) using three Flat Washers (B), three Spring Washers (C) and three Bolts (A). TIGHTEN ALL BOLTS USING WRENCH (D). STEP 2 Attach Connection Panel (2) to Top Panel (1) using four Flat Washers (B), four Spring Washers (C) and four Bolts (A). TIGHTEN ALL BOLTS USING WRENCH (D).
  • Page 6 STEP 3 Attach Base Panel (4) to Post (1) using three Flat Washers (B), three Spring Washers (C) and three Bolts (A). TIGHTEN ALL BOLTS USING WRENCH (D). STEP 4 Attach Foot Pads (5) to Base Panel (4) using one Flat Washer (B), one Spring Washer (C) and one Bolt (A) for each Foot Pad (5).
  • Page 7 STEP 5 Adjust levelers to level table.
