April, 2024
AC60L
L-DESK
Assembly Instructions - Important:
Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling
the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or information on other
products, please visit our website: www.officestar.net or call or write us.
Advertisement
Related Manuals for OSP Home Furnishings AC60L
Summary of Contents for OSP Home Furnishings AC60L
- Page 1 April, 2024 AC60L L-DESK Assembly Instructions - Important: Carefully unpack and identify each component before attempting to assemble. Refer to parts list. Please take care when assembling the unit and always set the parts on a clean, soft surface. If you require any assistance with assembly, parts or information on other...
- Page 2 Friday 8:00 a.m. - 3:30 p.m. Pacific Time. To make a warranty claim, contact Parts Department. Provide model number, proof of purchase, description of the problem and obtain return authorization. At its option OSP Home Furnishings will: (a) Supply compatible components of current ®...
- Page 3 CAM LOCK INSTALLATION Screw in Cam Bolt and fully tighten. Align hole in panel with Cam Bolt and attach. 180º Screw Cam Lock in. Turn clockwise until you feel Cam Lock securely fasten to Cam Bolt. Fully tighten Cam Lock.
- Page 4 PARTS (A) Main Desk Add-On Shelf (1 Pc) (B) Main Desk Top Panel (1 Pc) (C) Return Desk Top Panel (1 Pc) (D) Return Desk Bottom Panel (1 Pc) (E) Back Panel (1 Pc) (F) Return Desk Side Panel (1 Pc) FRONT (G) Return Desk Middle Panel (1 Pc) (H) Door (1 Pc)
- Page 5 PARTS (K) Front Support (1 Pc) (L) Back Support (1 Pc) (M) Main Desk Side Frame (1 Pc) (N) Main Desk Support Tube (3 Pcs) (O) Return Desk Support Tube (2 Pcs) (P) Main Desk Upper Crossbar (2 Pcs) (Q) Main Desk Lower Crossbar (1 Pc) (R) Return Desk Side Frame (1 Pc) (S) Power Outlet (1 Pc) (T) Plastic Cup Holder (1 Pc)
- Page 6 HARDWARE DRAWING DESCRIPTION SIZE QUANTITY Glue 1 Pc Wood Dowel 8 x 30mm 13 Pcs +1 extra Cam Lock 15 x 11mm 18 Pcs +2 extra Cam Bolt 4 Pcs Cam Bolt 14 Pcs +1 extra Handle 1 Pc Phillips Bolt 5/32"...
- Page 7 STEP 1 STEP 2 FULLY TIGHTEN BOLTS (7)
- Page 8 STEP 3 STEP 4 FULLY TIGHTEN ALL BOLTS...
- Page 9 STEP 5 FRONT STEP 6...
- Page 10 STEP 7 FULLY TIGHTEN ALL BOLTS STEP 8...
- Page 11 STEP 9 FULLY TIGHTEN ALL BOLTS LOCKED STEP 10 UNLOCKED (BACK VIEW) (BACK VIEW) 1. Check to make sure that the latch slider switch on pre-assembled Latches (ZB) are located in the position. DOWN UNLOCKED 2. Place the pre-assembled Rollers (ZA), which are attached to the of Door (H) assembly, down in the groove on Bottom Panel (D).
- Page 12 STEP 11 FULLY TIGHTEN ALL BOLTS STEP 12 FULLY TIGHTEN ALL BOLTS...
- Page 13 STEP 13 FULLY TIGHTEN ALL BOLTS STEP 14 FULLY TIGHTEN ALL SCREWS...
- Page 14 STEP 15 FULLY TIGHTEN ALL BOLTS...
- Page 15 FCC INSTRUCTIONS NOTE: This equipment has been tested and found to comply with the limits for the Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferences in a residential installation. This equipment generates, uses and can radiate frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
