AURATON Aquila mini SET
Instruction manual version 20220902
This document contains information regarding the safety, installation, and operation of the AURATON
Aquila Mini SET device.
Wireless thermostat with heating device controller
AURATON Fornax (set)
AURATON Aquila Mini SET is a set of a wireless thermostat with a controller of the AURATON Fornax
heating device, designed to work with a gas or electric heating device.
Factory-installed lithium battery
The AURATON Aquila Mini R wireless thermostat is equipped with a high-quality
î
lithium battery, ensuring uninterrupted operation of the thermostat for up to 10
years. Market-available thermostats generally require battery replacement once a
year. Therefore, a standard thermostat usually needs 10 to 20 batteries in the same
period. This results in additional costs and introduces harmful substances into the
environment.
Work under load up to 16 A/10 A
16A
The AURATON Fornax receiver is equipped with a relay that can operate under a load
of up to 16 A/10 A. The low-spark technology of switching the mains voltage causes
minimal wear of the relay contacts.
Interference-free communication between devices
ô
AURATON Aquila Mini R and AURATON Fornax communicate at a frequency of 868
MHz. Very short encrypted transmission packets (approx. 0.004 s) ensure efficient
and interference-free operation of the device.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Aquila mini SET and is the answer not in the manual?

Questions and answers

Related Manuals for AURATON Aquila mini SET

Summary of Contents for AURATON Aquila mini SET

  • Page 1 Wireless thermostat with heating device controller AURATON Fornax (set) AURATON Aquila Mini SET is a set of a wireless thermostat with a controller of the AURATON Fornax heating device, designed to work with a gas or electric heating device. Factory-installed lithium battery The AURATON Aquila Mini R wireless thermostat is equipped with a high-quality î...
  • Page 2 ó LEDs LEDs clearly indicate the operating status of the devices. Description of the AURATON Aquila Mini R thermostat Wireless thermostat Data transmission indicator LED. Temperature setting knob. Frost protection temperature setting (7 °C). Temperature sensor. Mounting bracket holes. Pairing indicator LED.
  • Page 3 Choosing the right location for the AURATON Aquila Mini R The correct operation of the AURATON Aquila Mini R is greatly influenced by its location. Placement in a place without air circulation or directly exposed to sunlight may result in incorrect temperature control.

  • Page 4: Mounting The Thermostat To The Wall

    – included in the AURATON Aquila Mini R set) Insert wall plugs (included) Screw the mounting bracket to the wall. “Press” the AURATON Aquila Mini R thermostat onto the mounting bracket so that the holes on the back of the thermostat fit into the catches on the bracket.
  • Page 5 AURATON Fornax (receiver) cooperates with the wireless AURATON Aquila Mini R (transmitter). The receiver is mounted next to the heating device and can work under a load up to 16 A/10 A .
  • Page 6 (transmitter) with AURATON Fornax – heating or air-conditioning device controller (receiver)”. The diode is blinking red – the AURATON Fornax receiver is waiting for the previously paired device to be unpaired – chapter: “Unpairing a thermostat paired with AURATON Fornax – heating or air-conditioning device controller (receiver)”.
  • Page 7 AURATON Fornax. Wires can be routed from the bottom of AURATON Fornax after holes are punched in the mounting plug or from the back of AURATON Fornax if the wires are pulled out of the wall. To connect from the back, break the plug.
  • Page 8 Remove the cover of the front part of Auraton Fornax by unscrewing the screws halfway.
  • Page 9 Connect the heating or air-conditioning device to the clips of the AURATON Fornax control connector. Follow the service manual of the heating or air-conditioning device. COM (common) and NO (normally open circuit) clips are most commonly used. Connect the power supply wires to the clips of the power supply connector of the AURATON Fornax...
  • Page 10 Wire mounting bracket. Once the wires are connected, secure them with the “wire mounting bracket” and screw the cover back onto the AURATON Fornax receiver. Mounting AURATON Fornax – heating or air-conditioning device controller (receiver) onto a wall...
  • Page 11 Mark the location of the holes for the mounting screws on the wall. Drill holes with diameters of the attached plugs (5 mm) where marked. Insert wall plugs into the drilled holes. Screw the AURATON Fornax receiver to the wall with the screws, so that the device is fixed securely. NOTE: If the wall is wooden, there is no need to use wall plugs.
  • Page 12 NOTE: The AURATON Aquila Mini R wireless thermostat (transmitter) sold together with the AURATON Fornax – wireless controller of the heating device (receiver) in the AURATON Aquila Mini SET is already paired. Devices purchased separately require “pairing”. Pairing the AURATON Aquila Mini R (transmitter) with the AURATON Fornax is initiated by pressing the right pairing button ( ) –...
  • Page 13 Successful pairing is indicated by the green LED on the AURATON Fornax receiver ceasing to flash, a single beep, and the receiver returning to normal operation. In case of a pairing error, repeat steps 1 and 2. For subsequent errors, unpair the device by RESETTING the AURATON Fornax receiver, see “RESET –...
  • Page 14 NOTE: If after the RESET, you disconnect the AURATON Fornax receiver from the power supply, and then reconnect the power supply, the receiver will automatically enter the “pairing” mode for 120 seconds. The AURATON Fornax receiver, which is newly purchased (not purchased in a set with AURATON Aquila Mini R) and does not have factory-paired devices, will behave identically.

  • Page 15: Special Situations

    flashing of the LED in red and green). Until the problem is resolved, the receiver will switch to the saved on/off cycle from the last 24 hours. When the signal from the AURATON Aquila Mini R returns, the error is cleared and the AURATON Fornax receiver returns to normal operation.

  • Page 16: Additional Information

    0.2 °C. If the temperature does not change, the AURATON Aquila Mini R sends control data every 5 minutes (this is manifested by a temporary alternating change in the color of the LEDs).
  • Page 17 Control Heating device e.g. a gas furnace Electric heating device...

  • Page 18: Cleaning And Maintenance

    868,850 MHz Radio frequency: 869,000 MHz Radio signal power: Up 11 dBm Degree of protection: IP20 AURATON Aquila Mini R: Power supply: lithium battery (factory installed). Battery non-replaceable. Number of temperature levels: Frost protection temperature: 7 °C Temperature control range: 7 °C;...
  • Page 19 The user is responsible for delivering the devices to a reception point for used-up electric and electronic equipment. Hereby, LARS Andrzej Szymanski declares that the radio equipment type AURATON Fornax is in compliance with Directive 2014/53/EU and 2011/65/EU. The full text of the EU declaration of conformity is available at the following internet address: https://manuals.auraton.pl...
  • Page 20 Declaration of conformity AURATON Fornax...
