Send_Commands for the IR/Serial/Data Ports (Cont.)
CTON
Sets the IR pulse
(single) on time for
each channel digit
and IR functions.
GET BAUD
Gets the IR/Serial/
Data port's current
communication
parameters.
GET MODE
Gets the IR/Serial/
Data port's current
mode setting.
IROFF
Stops IR output on
the designated
device.
POD
POF
PON
3 3
Axcent and Axcent Pro Integrated Axcess Controllers
CTON sets the pulse length for each digit and CTOF sets the time between digits or
any other pulse.
Syntax:
"'CTON',<time>"
Variables:
<time> = 0 - 255 in tenths of a second; Time is stored in permanent memory. System
default is 5 (.5 second).
Example:
SEND_COMMAND IR_1, "'CTON',20"
Sets the pulse length to 2 seconds.
The port sends the data through the master's PROGRAM port.
Syntax:
'GET BAUD'
Example:
SEND_COMMAND IR_1,'GET BAUD'
System response example:
Device 1,38400,N,8,1
Syntax:
'GET MODE'
Example:
SEND_COMMAND IR_1,'GET MODE'
System response example:
Device 8 IR,CARRIER,IO LINK 0
Syntax:
'IROFF'
Example:
SEND_COMMAND IR_1,'IROFF'
Stops transmitting IR signals.
Syntax:
'POD'
Disables current PON (power on) or POF (power off) command settings. Channel 255
changes are enabled.
Syntax:
'POF'
Sends IR function 28 (if available) or 9 to turn device power off. After three attempts, if
the linked I/O channel still detects a power-on status, the controller starts processing
stored buffer commands. Then, if another IR function 28 or 9 fails to turn the external
device's power off, the controller sends a PUSH and RELEASE of channel 248 and
generates a power failure error. If the device is turned on manually, this command turns
the external device's power off unless a PON (power on) or POD (disable POF) com-
mand is received. Refer to the SET IO LINK command.
Syntax:
'PON'
Sends IR function 27 (if available) or 9 to turn device power on. After three attempts, if
the linked I/O channel still detects a power-off status, the controller starts processing
stored buffer commands. Then, if another IR function 27 or 9 fails to turn the external
device's power on, the controller sends a PUSH and RELEASE of channel 248 and
generates a power failure error. If the device is turned off manually, this command turns
external device power on unless a POF (power off) or POD (disable 'PON' command)
command is received.
