Installation
Program connector (front and rear panels)
Connect a programming cable to the PROGRAM connector on the controller. The table below
shows the DB-9 connector pins and signals for the PROGRAM connector. Use the PROGRAM
connector to download Axcess programs, and to set up control communication options using the
OpenAxcess software program.
Program Connector and Pinouts
Pin 1
PROGRAM pins 1, 6, 8, and 9 are not used. Pins 4, 5, and 7 are for an ALF
Programming Unit.
Axcess card slot connector (Axcent
FIG. 10 shows the 16-pin (male) connector that provides connection to the Axcess Control Cards.
After installing control cards, refer to the literature provided with the control card for wiring and
Axcess programming information.
FIG. 10 Axcess Control Card 16-pin connector
8
Pin
Signal
2
RXD
3
TXD
4
+12 VDC
Pin 9
5
GND
7
+12 VDC
3
PRO only)
SLOT 4
Axcent
3
3
and Axcent
Pro Integrated Axcess Controllers
