CMS80F761x Reference Manual

CMS80F761x Series

Reference Manual
Enhanced flash 8-bit 1T 8051 microcontroller
Rev. 1.0.4
Please note the following CMS IP policy
＊China Micro Semicon Co., Ltd. (hereinafter referred to as the Company) has applied for patents and holds absolute legal
rights and interests. The patent rights associated with the Company's MCUs or other products have not been authorized for use,
and any company, organization, or individual who infringes the Company's patent rights through improper means will be subject
to all possible legal actions taken by the Company to curb the infringement and to recover any damages suffered by the
Company as a result of the infringement or any illegal benefits obtained by the infringer.
＊The name and logo of Cmsemicon are registered trademarks of the Company.
＊The Company reserves the right to further explain the reliability, functionality and design improvements of the products in the
data sheet. However, the Company is not responsible for the use of the Specification Contents. The applications mentioned
herein are for illustrative purposes only and the Company does not warrant and does not represent that these applications can
be applied without further modification, nor does it recommend that its products be used in places that may cause harm to
persons due to malfunction or other reasons. The Company's products are not authorized for use as critical components in
lifesaving, life-sustaining devices or systems. The Company reserves the right to modify the products without prior notice. For
the latest information, please visit the official website at www.mcu.com.cn.
www.mcu.com.cn
/
Rev. 1.0.4
1
270
