Setma E01MT24009 Installation Instructions

Steering wheel control interface for select mitsubishi vehicles

Download this manual

Left to Right:

i. OEM USB Retention Connector

ii. Vehicle Specific Connector

iii. Vehicle Specific Connector

iv. Additional Flying Wires

APPLICATION

Mitsubishi Montero Sport

Mitsubishi Pajero Sport

Mitsubishi Shogun Sport

For amplified vehicles, does not support fade.

FEATURES

• Retains Factory Steering Wheel Control Functionality

• Retains Factory Phone Button Functionality

• Retains OEM Amplifier

• Retains OEM USB Input

• Retains 360 Panoramic Camera

• Provides Outputs for Park Brake, Speed Pulse & Reverse

• Software Updatable

The information provided in this document is subject to change without notice due to manufacturer changes and/or improvements to the product/s. This

instruction manual is based on documented data and research. The manufacturer of this product cannot be held responsible for any changes made to the

vehicle by the manufacturer or damages that may occur through the installation of this product in accordance with the steps outlined herein.

Steering Wheel Control Interface

v. ISO Power/Speaker Connector

vi. Aux RCA + 360 Camera RCA

vii. Interface Box

viii. OEM USB Retention Connector

2016 - 2019

(contact supplier for more information)

DISCLAIMER

for select Mitsubishi vehicles

Note: Application data is subject to change at any time

E01MT24009

Need help?

Do you have a question about the E01MT24009 and is the answer not in the manual?

Page 1 E01MT24009 Steering Wheel Control Interface for select Mitsubishi vehicles Left to Right: i. OEM USB Retention Connector v. ISO Power/Speaker Connector ii. Vehicle Specific Connector vi. Aux RCA + 360 Camera RCA ii. Vehicle Specific Connector vii. Interface Box iii. Vehicle Specific Connector viii.
Page 2 PRODUCT INFORMATION E01MT24009 The E01MT24009is a CAN Bus steering wheel control interface for select Mitsubishi vehicles. This interface aids in the retention of crucial steering wheel controls, the OEM amplifier, as well as access and control of the Mitsubishi’s 360 Panoramic Camera functions.
Page 3 Please ensure that the correct tools are used during the installation to avoid damage to the vehicle or product. SETMA can not be held responsible for the installation of this product. INSTALLATION GUIDE See wiring diagram on Pg.4 for more information...
Page 4 360 CAMERA FUNCTIONALITY Access of the 360 Camera: When not in reverse - a short initial press of the ‘360 view’ button on the steering wheel will showcase the ‘front view & 360 panoramic view’ (Figure 1). A second short press of the button will then switch the display to the ‘front view &...
