Please read instructions before beginning installation. Check the kit hardware against the kit contents shown below. Be
sure you have all needed parts and know where they go.
If question exist, please call us @1-800-222-7023. We will be happy to answer any questions concerning this product.
Check all fasteners for proper torque. Check to ensure for adequate clearance between all components.
Periodically check all hardware for tightness.
KIT CONTENTS:
Driver Side Rail
Passenger Side Rail
4 - Cross Rail
Rear Panel
Solid Front Plate (no light)
Cut-Out Front Plate (light bar kit)
Torque Specs:
Size
Grade 5
5/16"
15 ft/lbs
3/8"
30 ft/lbs
7/16"
45 ft/lbs
1/2"
65 ft/lbs
9/16"
95 ft/lbs
5/8"
135ft/lbs
3/4"
185ft/lbs
POLARIS XPEDITION ADV-5-1000 ROOF RACK
Thank you for choosing Rough Country for all your vehicle needs.
Grade 8
Size
20ft/lbs
6MM
35ft/lbs
8MM
60ft/lbs
10MM
90ft/lbs
12MM
130ft/lbs
14MM
175ft/lbs
16MM
280ft/lbs
18MM
TOOLS NEEDED:
10mm Wrench
13mm Wrench
4mm Allen Wrench
T40 Torx
Class 8.8
Class 10.9
5ft/lbs
18ft/lbs
32ft/lbs
55ft/lbs
85ft/lbs
130ft/lbs
170ft/lbs
HARDWARE INCLUDED:
26 - 6mm Lock Nut
52 - 6mm Flat Washer
26 - 6mm x 20mm Button Head Bolt
10 - 8mm Oversized Washer
10 - 8mm x 45mm Bolt
9ft/lbs
23ft/lbs
45ft/lbs
75ft/lbs
120ft/lbs
165ft/lbs
240ft/lbs
921931700
Advertisement
Related Manuals for rough country 93173
Summary of Contents for rough country 93173
- Page 1 921931700 POLARIS XPEDITION ADV-5-1000 ROOF RACK Thank you for choosing Rough Country for all your vehicle needs. Please read instructions before beginning installation. Check the kit hardware against the kit contents shown below. Be sure you have all needed parts and know where they go.
- Page 2 INSTALLATION INSTRUCTIONS 1. Lay out the roof rack as shown. The RC logo goes toward the front of the vehicle. See Photo 1. 2. Loosely assemble each cross rail to the driver and passenger side rails using the supplied (4) 6mm x 20mm button head bolt, (8) 6mm flat washer, and (4) 6mm lock nut for each of the rails.
- Page 3 4. Install “Warning to Driver” decal on sun visor. By purchasing any item sold by Rough Country, LLC, the buyer expressly warrants that he/she is in compliance with all applicable, State, and Local laws and regulations regarding the purchase, ownership, and use of the item. It shall be the buyers responsibility to comply with all Federal, State and Local laws governing the sales of any items listed, illustrated or sold.
