- Page 1 Body Armor QP.BXG-213 (1)Contents: (2)Tools required: a.6mm HEX Socket Wrench; b.One Drill; c.11mm Drill bit; d.M8 Pneumatic Rivet Nut Setting Kit...
-
Page 2: Installation Instruction
(3)Installation time: About 2 hours, 2-3 persons needed. Installation time is different according to individual person （ ） (4)Installation instruction: Step 1: Ready to install the new product. Step 2: Try to confirm the bolt holes .As shown below. - Page 3 Step 3: Drill the bolt holes. And install the PART”I” by the M8 Pneumatic Rivet Nut Setting Kit.
- Page 4 Step 4: Install PART”A2” with PART”H”, PART”J” & PART”K” by the 6mm HEX Socket Wrench.
- Page 5 Step 5: Repeat above steps on another side. Step 6: Installation completed. After Before...
