- Page 1 Fender Flares QP.BXG-007 (1)Contents: (2)Tools required: a.13/14mm Wrench; b.13/14mm Socket Wrench; c.One Drill; d.11mm Drill bit; e.M8 Pneumatic Rivet Nut Setting Kit...
-
Page 2: Installation Instruction
(3)Installation time: About 2 hours, 2-3 persons needed. Installation time is different according to individual person （ ） (4)Installation instruction: Step 1: Remove the original fender flares,and then ready to install the new fender flares. As shown below. Step 2: Install the front part first. - Page 3 Step 3: Tighten the front fender flare with PART”J”, PART”L” & PART”M”, by 13/14mm wrench & 13/14mm socket wrench. Step 4: Repeat the same method like “Step 2”.
- Page 4 Step 5: Install the PART”B”(the drive side). (1)Install the PART“N” on the bolt holes by the M8 Pneumatic Rivet Nut Setting Kit. (2)Then install the fender flare with PART“H” or PART“I” & PART“K”. Use PART“H” or PART“I” is according to the length.
- Page 5 (3)The figure shows there are two bolt holes,just install with PART“H” or PART“I”,this is according to the length too.And don’t forget to tighten it. Step 6: Repeat above steps to install another side.
- Page 6 Step 7: Installation completed.
