Lutron Electronics Skylark C Manual

Skylark
Skylark C•L Dimmer
Dimmer for CFL, LED, Halogen, and Incandescent
dimmable bulbs.
Features
• On / off rocker switch with a linear-slide dimmer for a
standard designer wallplate opening
• HED Technology: Advanced Lutron dimming
circuitry designed for compatibility with most high
efficacy light bulbs
• ULR Listed to control:
— Dimmable Compact Fluorescent Lamps (CFL) with
integrated ballast
— Dimmable LED with integrated driver
— Halogen
— Incandescent
• Low-end adjustment to accommodate a wide range
of bulbs
• Switch returns load to previous level
• 100% factory tested
Application Requirements
• When dimming CFLs or LEDs, only bulbs marked or
rated as DIMMABLE may be used.
• For a complete list of compatible DIMMABLE CFLs
and LEDs please visit www.lutron.com/dimcflled. For
questions call 1.844.LUTRON1.
• Some DIMMABLE CFLs and LEDs require a
minimum number of bulbs for proper operation. For
details and a list of bulbs, please visit
www.lutron.com/dimcflled.
Model Number
SCL-153P-XX
1, 2
SCL-153PH-XX-C
1, 4
"XX" in the model number represents color/finish code; see
1
"Colors and Finishes" on next page.
For clamshell packaging, add "H" after "153P". Clamshell packaged product
2
available in AL, IV, LA, and WH.
For 3-way and 4-way switching, use Claro switches or other mechanical
3
switches.
Clamshell packaged product for Canada. Available in AL, IV, LA, and WH.
4
S P E C I F I C AT I O N S U B M I T TA L
Job Name:
Job Number:
Single pole / 3-way
3
Single pole / 3-way
3
Model Numbers:
C•L Dimmer
Wallplate sold separately
Wallbox Controls
369684b 1 10.09.17
Select
light level
with slider
Switch on
(to selected
light level),
and off
Page
1
