- Page 1 User Manual Gas Hobs BG6xA - BG6xB - BG6xC BG6xD - BG6xE...
- Page 2 The following symbols are used throughout the manual, and they have the following meanings: INFORMATION! Information, advice, tip, or recommendation WARNING! Warning general danger GAS CONNECTION! Warning gas connection ELECTRIC SHOCK! Warning danger of electric shock HOT SURFACE! Warning danger of hot surface DANGER OF FIRE! Warning danger of fire...
-
Page 3: Table Of Contents
Contents Safety regulations ........................READ CAREFULLY AND KEEP IT FOR FUTURE REFERENCE! ..........Gas hob ............................ Safe use ........................... User Manual ..........................Models ............................Description ..........................Information according to regulation (EU only) 66/2014 ............Use ............................Burner position: ........................Cleaning: ........................... Faults table .......................... -
Page 4: Safety Regulations
Safety regulations READ CAREFULLY AND KEEP IT FOR FUTURE REFERENCE! General The manufacturer cannot be held liable for any damage resulting from failure to follow the safety instructions and warnings. Damage caused by incorrect connection, incorrect fitting, or incorrect use is not covered by the warranty. WARNING! This appliance and the accessible parts will become hot during use. -
Page 5: Danger Of Fire
DANGER OF FIRE! WARNING: Danger of fire: do not store items on the cooking surfaces. WARNING: Cooking with fat or oil on a hob without supervision can be dangerous and can lead to a fire. CAUTION! The cooking process has to be supervised. A short-term cooking process has to be supervised continuously. -
Page 6: Electric Shock
If a drawer underneath the appliance is permitted (see the installation instructions), without an intermediate bottom, this should not be used to store highly flammable objects/materials. Ensure that there is adequate clearance of a few centimetres between the bottom of the hob and the contents of any drawers. -
Page 7: Gas Hob
The cooking zones/burners heat up during use and stay hot for a while afterwards. Keep young children away from the hob during and immediately after cooking. Gas hob CAUTION! The use of a gas cooking appliance results in the production of heat, moisture and products of combustion in the room in which it is installed. -
Page 8: Safe Use
Safe use Never cover the appliance with a cloth or something similar. If the appliance is still hot or is switched on, there is a risk of fire. Do not use the appliance as a worktop. The appliance may accidentally be switched on or still be hot, which means objects could melt, become hot or catch fire. -
Page 9: User Manual
User Manual Models BG6xA Aa - Auxiliary burner Bb - Semi-rapid burner Cc - Rapid burner Dd - Wok burner BG6xB / BG6xC BG6xD BG6xE... -
Page 10: Description
Description G20 - 20 mbar Burner Power BG6xA BG6xB BG6xC BG6xD BG6xE Auxiliary 1.05 kW Semi-rapid 1.80 kW Rapid 3.00 kW 3.50 kW 4.05 kW G30/G31 - 28-30/37 mbar Burner Power / Mass flow BG6xA BG6xB BG6xC BG6xD BG6xE Auxiliary 1.05 kW / 76 g/h Semi-rapid 1.70 kW / 122 g/h... -
Page 11: Information According To Regulation (Eu Only) 66/2014
Information according to regulation (EU only) 66/2014 Measurements according to EN60350-2 Model identification BG6xA BG6xB BG6xD BG6xC BG6xE Type of hob Gas hob Gas hob Number of gas burners Heating technology Gas burner Gas burner Energy efficiency per gas Semi-rapid burner: 58.1 58.1 burner (EE... -
Page 12: Cooking Timer Function
Control: (1) Push (2) Turn left + hold (3) Hold down 3 sec. high setting low setting Cooking timer function: Depending on the model, your hob can have a cooking timer function. For both left cooking zones, the cooking time can be set (from 1 to 99 minutes). - Page 13 How to set the cooking timer 1. Ignite the burner of the cooking zone. 2. Touch the sensor key on the knob for about 2 seconds. 3. You hear an acoustic signal and ‘- 00 +’ appears. 4. Touch key ‘+’ or key ‘-’ to set the desired cooking time. After 5 seconds, key ‘+’...
-
Page 14: Burner Position
Accessories (to be obtained via After Sales): Following accessories are optional and can be ordered separately: Suits wok burner Suits Auxiliary burner Code: 806206 Code: 537584 Burner position: Cleaning: Faults table Following is some advice on rectifying some common problems. What happened...? Possible cause What to do? - Page 15 Table continued from last page What happened...? Possible cause What to do? The grid has discoloured in the This is a commonplace phe- Clean the grid with a metal care burner area? nomenon resulting from high detergent. temperatures. Electric power supply, in gener- The fuse may be blown.
-
Page 16: Installation Instruction
Installation instruction Safety regulations Faulty parts may only be replaced by original parts. The manufacturer can only guarantee that original parts meet safety requirements. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. - Page 17 A safety hose may not be bent and must not come into contact with moving parts of kitchen units. The gas supply valve must always be placed in an easily accessible position. The worktop into which the hob is fitted should be flat. The walls and the worktop surrounding the appliance must be heat resistant up to at least 105 °C.
-
Page 18: Preparations For Installation
Preparations for installation Free space around the appliance A (mm) B (mm) C (mm) D (mm) min. 650 min. 600 min. 450 min. 120 Dimensions Appliance: A (mm) B (mm) C (mm) D1 (mm) D2 (mm) BG6xA/B/C BG6xD/E Built-in:... -
Page 19: Sealing Tape
A (mm) B (mm) C (mm) D (mm) E (>mm) F (mm) G (mm) Sealing tape Stainless steel drip tray Glass drip tray BGH6xxA/B BGR6xxA/B worktop Gas connection PTFE tape... -
Page 20: Accessibility
Accessibility oven safety hose metal oven Built-in Min. 20 mm only for 75+90 cm Max. 50 mm... -
Page 21: Connecting & Testing
Connecting & testing WARNING! Check if connections are gas-tight. -
Page 22: Conversion Instruction
Conversion instruction WARNING! Adjusting for a different gas type! WARNING! Attention! Performing these instructions by a non-qualified person can lead to dangerous situations. The supplier is not responsible for the consequences (the arising of a hazardous situation and/or damage to persons or goods) caused by the incorrect performance of these instructions by engineers who are not employees of the supplier. -
Page 23: Power Table (Kw-G/H)
Gas type P mbar Modification (BG6xB/E) (BG6xC) nozzle nozzle 20 / 25 Convert from G20 - 20 mbar or from G20 - 25 mbar to: Replace nozzle & no action bypass G30/G31 28-30/37 Replace nozzle & screw in bypass (see 3A) (PL) Replace nozzle &... -
Page 24: Tools Needed
Tools needed: T1 Socket spanner (7 mm) T2 Screwdriver flat blade (4 mm) T3 Nose pliers T4 Open-end spanner (7 mm) T5 Leak test spray Converting nozzles NOTE! Please note: disconnect the appliance from the power supply. Prevent damage of the worktop. Lay down parts of the appliance on a protected base. For converting to a different type of gas, the nozzles have to be changed. -
Page 25: Check For Gas Tightness And Operation
3B. Remove the by-pass screws by using the flat-blade screwdriver (T2) and the nose pliers (T3). Place the new by-pass screws with the nose pliers and screw the by-pass screws of all gas taps in, by using the flat-blade screwdriver. 3C. -
Page 26: Environmental Considerations
Environmental considerations Disposal of the appliance and packaging Sustainable materials have been used during the manufacture of this appliance. The appliance packaging is recyclable. The following may have been used: cardboard; paper; polyethylene film (PE); CFC-free polystyrene (PS-rigid foam); polypropylene tape (PP). Dispose of these materials in a responsible manner and in accordance with government regulations. -
Page 27: Your Notes
Your notes... - Page 28 830509-a10...
