AUSTRALIAN MONITOR ACM604P Brochure

ACM604P
4 Channel Amplifier
60 Watts per Channel

Description

The ACM604P features four individual 60 watt power amplifiers in a 2RU chassis and is suit-
able for rack or desk mounting. This amplifier includes a rack mount kit and signal present LED
(per channel).
Inputs
Each of the four power amplifiers features balanced XLR inputs with a parallel balanced XLR
output. A rear panel level control is available per channel.
Outputs
The ACM604P features 100 volt, 70 volts, 8 ohm isolated transformer outputs per amplifier
module.
Protection
Internal current limiting protects the amplifier from both overload and overdrive conditions. The
ACM604P features generous heat sinking to allow reliable operation in extreme conditions.
Australian Monitor Installation Series amplifiers feature a protection network that provides
greater stability and performance. Our amplifiers are recognised
worldwide for their reliability and this is due to the extensive levels of
current limiting which protect the amplifiers from both overload and
overdrive conditions.

Applications

With 4 x 60 watt power amplifiers in a two rack unit chassis, the ACM604P becomes a great
way to save space in multi zone installations. Used in conjunction with the Australian Monitor
Installation Series Pagenet 88 Zone Paging System, a client can enjoy eight channels of power
amplification, routing, multi zone paging, muting, chimes and EQ in just 6 rack units. This
makes the system easy to install and user friendly.
