Page 1: Service Information
SERVICE INFORMATION ACM604 MIXER AMPLIFIER CONTENTS: OPERATION MANUAL SCHEMATIC DIAGRAMS Australian Monitor 1 Clyde Street, Silverwater NSW 2128 Australia +61 2 9647 1411 www.australianmonitor.com.au... - Page 2 ACM604 4 x 60w Mixer Amplifier Operating Manual...
-
Page 3: Product Description
Product Description The ACM604 is a 4 x 60 watt mixer amplifier designed for commercial installations. It features 4 independent 60 watt mixer amplifiers within the one 2 rack unit chassis. Each amplifier features 3 balanced microphone/line input channels and outputs for either low impedance (8 ohm) or 70v/100v line speaker systems. -
Page 4: Rear Panel Features
Rack Mounting The ACM604 is supplied with rack ears attached to allow mounting within a standard 19” equipment rack. As is the case with almost all audio products, adequate ventilation and air flow is required. When installing multiple ACM amplifiers within the one rack, it is recommended that at least 1 rack unit of ventilation space is left between every two amplifiers. - Page 5 VOX Muting The ACM604 includes a VOX muting circuit which is independent for each amplifier. The unit is factory set so that input 1 of each amplifier has VOX priority over inputs 2 and 3 for that amplifier. Basically, when signal is present on input 1, audio from inputs 2 and 3 is muted.
-
Page 6: Important Safety Information
Important Safety Information 13. Do not block fan intake or exhaust ports. Do not 1. Save the carton and packing material even if the equip- operate equipment on a surface or in an environment ment has arrived in good condition. Should you ever which may impede the normal flow of air around the need to ship the unit, use only the original factory pack- ing. - Page 7 120K X3/1 100P SW2/1 220K 680R IC2A 220K 680R SW2/2 100P SW2/3 100P SW3/1 15VDC 220K 680R IC2B 220K 680R SW3/2 100P SW3/3 ACM604 MIC INPUT Title CD6258-1 Size Number Revision Date: 16-Oct-2002 Sheet of File: C:\Protel Files\CDTRAX\CD6258-1.DDB Drawn By:...
- Page 8 16C54 100K TONE OUT 9VDC 100K .47u LM358 IC4B .47u EVAC BELL 100R ALERT PRE AN 100u 15VDC 9VDC 100R LM741 BC546 100u ACM604 TONE GEN Title CD6264-1 Size Number Revision Date: 16-Oct-2002 Sheet of File: C:\Protel Files\CDTRAX\CD6264-1.DDB Drawn By:...
- Page 9 10K/NTC 330R SFH615-A2 +30VDC -30VDC TO OTHER AMPS 470u 470u 8 OHM IN PUT OT60 RN1B RN1A LM3876 LM3876 220P 220P 100P 100P ACM604 POWER AMP Title CD6251-1 Size Number Revision Date: 16-Oct-2002 Sheet of File: C:\Protel Files\CDTRAX\CD6251-1.DDB Drawn By:...
- Page 10 33VDC 5A/SB .15R 470u LM7818 470R 0.1u PRE AMP TIP42C LM1458 TIP36C BD139 IC1A INPUT .47u BC640 BD139 100R 330R BC546 24VDC 100u 120P MUTE BD140 .47u LM78L05 BC639 8OHM BD140 .47u 120P HI TEMP 330R 100DEG 100R 12C509A 18VDC IC1B 100R BD139...
