Preface
About this document
Provides an overview of the manual's content and scope.
Configuration of safety instructions
Explains the structure and levels of safety instructions and their symbols.
Markup elements
Details text formatting, symbols, and special notations used in the document.
Introduction
Delivery package
Describes the contents and packaging of the delivered probes and stylus systems.
Warranty and standards
Outlines warranty information and applicable standards for the probing system.
Description
Overview of Probing Systems
Introduces contact probing systems, categorizing them by triggering and measuring types.
RST-P Probe Description
Details the RST-P probe, including its product photo, application, and components.
XDT TL3 Probe Description
Covers the XDT TL3 probe, its product photo, application, and system requirements.
VAST XXT Probe Description
Details the VAST XXT probe, its product photo, application, and system requirements.
Stylus Systems Overview
Explains the various components that make up a stylus system.
Technical Specifications
RST-P Technical Data
Lists dimensions, weight, and ambient conditions for the RST-P probe.
VAST XXT Technical Data
Provides dimensions, weight, and ambient conditions for VAST XXT probe versions.
Renishaw Probes Technical Data
Specifies dimensions, weight, and ambient conditions for TP6 and TP20 probes.
Handling
Essential Handling Knowledge
Covers types of measurement, discrete-point probing, and trigger probing systems.
Notes on Measuring Operation
Discusses stylus checking, magnetic fields, and temperature influence during operation.
RST-P Handling and Operation
Details admissible zones, critical probings, and stylus vector for RST-P.
VAST XXT Handling and Operation
Explains dead-weight offset, probe deflection, and operational modes for VAST XXT.
Stylus System Assembly Procedures
Covers precautions, weight/length limits, and assembly methods for stylus systems.
Errors and Malfunctions
Troubleshooting Faults During Operation
Lists common errors, their causes, and recommended remedies for probing systems.
Care and Inspection
General Care and Inspection Guidelines
Emphasizes cleanliness requirements for the sensitive measuring system.
Stylus System Inspection
Outlines regular checks for styli, components, and replacement of damaged parts.
Care and Cleaning Procedures
Provides instructions for cleaning stylus tips, removing deposits, and caring for adapter plates.
Disposal
Packaging Disposal
States that country-specific regulations apply to packaging material disposal.
Probing System Disposal Guidelines
Advises on disposing of electronic components according to WEEE directives.
