Tempest i5000PT
S5383
Revision 1.10
Copyright
Copyright © TYAN Computer Corporation, 2006. All rights reserved. No part of this manual
may be reproduced or translated without prior written consent from TYAN Computer Corp.
Trademark
All registered and unregistered trademarks and company names contained in this manual
are property of their respective owners including, but not limited to the following.
TYAN,
Tempest i5000PT
are trademarks of TYAN Computer Corporation.
Intel, Blackford, and combinations thereof are trademarks of Intel Corporation.
AMIBIOS are trademarks of AMI Technologies.
Microsoft, Windows are trademarks of Microsoft Corporation.
SuSE, is a trademark of SuSE AG.
IBM, PC, AT, and PS/2 are trademarks of IBM Corporation.
Notice
Information contained in this document is furnished by TYAN Computer Corporation and
has been reviewed for accuracy and reliability prior to printing. TYAN assumes no liability
whatsoever, and disclaims any express or implied warranty, relating to sale and/or use of
TYAN products including liability or warranties relating to fitness for a particular purpose or
merchantability. TYAN retains the right to make changes to product descriptions and/or
specifications at any time, without notice. In no event will TYAN be held liable for any direct
or indirect, incidental or consequential damage, loss of use, loss of data or other malady
resulting from errors or inaccuracies of information contained in this document.
1
http://www.TYAN.com
Advertisement
Table of Contents
Related Manuals for TYAN TEMPEST I5000PT
Summary of Contents for TYAN TEMPEST I5000PT
- Page 1 TYAN retains the right to make changes to product descriptions and/or specifications at any time, without notice. In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.
-
Page 2: Table Of Contents
BIOS Advanced Menu……………….…………………………………... 45 3.3.1 Advanced Chipset Control…………………………………………………….. 47 3.3.1.1 ICH USB Control Sub-Menu……………………………………………..49 3.3.1.2 LAN Control Sub-Menu………………………………………………………… 50 3.3.2 Advanced Processor Options…………………………………………………. 51 3.3.3 I/O Device Configuration………………………………………………………. 53 3.3.4 DMI Event Logging………………………………………………………..54 3.3.5 Hardware Monitor………………………………………………………………. 55 http://www.TYAN.com... - Page 3 3.3.5.1 Voltage Monitoring ……..……………………………………………………… 56 3.3.6 IPMI ……..………………………………………………………………………. 57 3.3.7 Console Redirection……………………………………………………………. 59 Power Menu………………………………………………………………..61 Boot Menu………………………………………………………………………. 62 Exit Menu………………………………………………………………………... 63 Chapter 4: Diagnostics Beep Codes……………………………………………………………………… Flash Utility……………………………………………………………………….. Glossary http://www.TYAN.com...
-
Page 4: Before You Begin
2 x CPU Heatsink CEK 1 x TYAN Driver CD 1 x Tempest i5000PT User’s Manual 1 x Tempest i5000PT Quick Reference Guide If any of these items are missing, please contact your vendor/dealer for replacement before continuing with the installation process. -
Page 5: Chapter 1: Introduction
Chapter 1: Introduction 1.1 – Congratulations! You are now the owner of one of the most powerful Intel processor solutions, the Tempest i5000PT ® (S5383). The Tempest i5000PT (S5383) is a flexible Intel platform for multiple applications, based ® ®... - Page 6 RAID 0, 1, 5 and 10 support (RAID 10 only BSMI (Optional) supported under windows) Integrated SAS Controller (WG2NR version only) ® 1068E SAS controller with PCI-E x 8 interface Eight (8) SAS/SATA connectors RAID 0, 1 and 1E (Mirroring Enhanced) support http://www.TYAN.com...
-
Page 7: Software Specifications
Red Hat Enterprise Linux 4 Update4 Novell SuSE Linux Enterprise Server 10 LSI SAS RAID Driver support, please refer to below web site: http://www.lsilogic.com/cm/LookupDownloads.do?role=1&geo=ALL&category=2059&family=-1#Dri TYAN reserves the right to add support or discontinue support for any OS with or without notice. http://www.TYAN.com... -
Page 8: Chapter 2: Board Installation
Chapter 2: Board Installation You are now ready to install your motherboard. The mounting-hole pattern of the Tempest i5000PT (S5383) matches the E-ATX specification. Before continuing with installation, confirm that your chassis supports an E-ATX motherboard. How to install our products right…. the first time! The first thing you should do is to read this user’s manual because the important information... -
Page 9: Board Image
The following page includes details on the vital components of this motherboard. This picture is representative of the latest board revision available at the time of publishing. The board you receive may or may not look exactly like the picture above. http://www.TYAN.com... -
Page 10: Block Diagram
2.2 – Block Diagram Tempest i5000PT S5383 Block Diagram NOTE: ** is reserved feature of S5383. http://www.TYAN.com... -
Page 11: Board Parts, Jumpers And Connectors
This jumper diagram is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the diagram above. NOTE: * is only available on S5383WG2NR version. ** is reserved feature of S5383. http://www.TYAN.com... -
Page 12: Jumper Settings
CPU0/ 1 FAN, SYS_FAN FAN Connectors See Section 2.4.15 1/ 2/ 3/ 4 Jumper Legend OPEN - Jumper OFF Without jumper cover CLOSED - Jumper ON With jumper cover To indicate the location of pin-1 To indicate the location of pin-1 http://www.TYAN.com... -
Page 13: Fan Connectors For Barebone (J3)
2.4.1 – Fan connectors for Barebone (J3) Signal Signal Description Description FAN_TACH1 FAN_TACH2 FAN_TACH3 FAN_TACH4 FAN_TACH5 FAN_TACH6 FAN_TACH7 FAN_TACH8 FAN_TACH9 2.4.2 – USB Header (5-Pin x 2) (J11) Signal Signal Description Description +5VPWR +5VPWR DATA1- DATA2- DATA1+ DATA2+ http://www.TYAN.com... -
Page 14: Front Panel Header For Barebone (J13)
Description Description LAN1 LED+ LAN1 LED- LAN2 LED+ LAN2 LED- LAN3 LED+ LAN3 LED- ID LED+ ID LED- ID Button+ ID Button- RSVD 2.4.4 –LCD Module Header for Barebone (3-Pin x 2) (J14) Signal Signal Description Description +5VCC +5VSB http://www.TYAN.com... -
Page 15: Smdc Con25X2_M3291 (J79)
For connection with the TYAN Server Management Daughter Card (SMDC), the SMDC connector is only compatible with the TYAN M3291 (SMDC). 2.4.6 –IPMB Pin Header (J80) Pin_1 : IPMB DATA Pin_2 : GND Pin_3 : IPMB CLK Pin_4 : NC... -
Page 16: Com Port Pin Header (J88)
2.4.7 –COM PORT Pin Header (J88) Signal Signal Description Description 2.4.8 –LAN4 LED Pin Header (JP6) (Option) PIN_1 Note: LAN4 is the lower LAN port of the stacked RJ45, which is close to mounting hole. Signal Signal LED+ LED- http://www.TYAN.com... -
Page 17: Clear Cmos Jumper (Jp10)
2.4.10 – LAN3 / LAN4 / LAN1 / LAN2 Enable / Disable Jumper (JP3, JP4, JP7, JP8) Normal Pin_3 Pin_1 Disable Pin_3 Pin_1 Jumper Pin_1 Pin_2 Pin_3 GPIO LAN3_Disable# GPIO LAN4_Disable# GPIO LAN1_Disable# GPIO LAN2_Disable# Note: JP3, JP4 are optional. http://www.TYAN.com... -
Page 18: Front Panel Header (Jp16)
HDD LED - PWR LED - Reset Button - Button + Reset Button + Button - 3.3VSB INTRUDER# 2.4.12 – Integrated VGA Enable / Disable Jumper (JP24) Pin_3 Close Pin1 and Pin2: Normal Pin_1 Pin_3 Close Pin2 and Pin3: Disable Pin_1 http://www.TYAN.com... -
Page 19: Onboard Buzzer Enable/Disable Jumper (Jp25)
2.4.13–Onboard Buzzer Enable / Disable Jumper (JP25) Pin_1 Close Pin3 and Pin4: Normal Pin # Signal Description VCC5 Buzzer IN SPKR 2.4.14–LSI SAS 1068E Disable Jumper (JP26) Pin_3 Close Pin1 and Pin2: Normal Pin_1 Pin_3 Close Pin2 and Pin3: Disable Pin_1 http://www.TYAN.com... -
Page 20: Fan Connectors (Cpu0 Fan, Cpu1 Fan, Sys_Fan1/2/3/4)
2.4.15–FAN Connectors (CPU 0/1 FAN, SYS_FAN 1/2/3/4) PIN1 Use these connectors to connect processor and chassis cooling fans to your motherboard. This 4-pin fan connector supports a new standard fan with integrated fan speed control on the fan itself for better fan life. http://www.TYAN.com... -
Page 21: Tips On Installing Motherboard In Chassis
If there is any stud missing, you will know right away since the motherboard will not be able to be securely installed. Tempest i5000PT（S5383） Mounting Hole Placement http://www.TYAN.com... - Page 22 Some chassis include plastic studs instead of metal. Although the plastic studs are usable, Tyan recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look like and how they should be installed.
-
Page 23: Installing The Processor(S)
2.6 – Installing the Processor Your Tempest i5000PT (S5383) supports Dempsey / Woodcrest / Clovertown dual core processors from Intel. Only Intel processors are certified and supported with this motherboard. Refer to the Tyan website for further details: www.tyan.com Processor Installation The processor should be installed carefully. -
Page 24: Heatsink Installation Procedures
(which should already be attached to the heatsink) to the motherboard. The following diagram illustrates how to connect fans onto the motherboard. After you’ve finished installing all the fans, you can connect your drives (hard drives, CD-ROM drives, etc.) to your motherboard. http://www.TYAN.com... -
Page 25: Installing The Memory
AMB Only Heatsink. Full-DIMM Heatsink Spreader (Recommended Solution) Here are a few key points to note before installing memory into your Tempest i5000PT; • Always install memory beginning with DIMM1. • At least ONE 240-Pin FBDIMM module must be installed for the system to turn on and POST (power on self test). -
Page 26: Memory Configuration
DIMM 2 DIMM 3 DIMM 4 DIMM 5 DIMM 6 DIMM 7 DIMM 8 DIMM 9 DIMM 10 DIMM 11 DIMM 12 DIMM 13 DIMM 14 DIMM 15 DIMM 16 Not all possible combinations are listed in the table. http://www.TYAN.com... -
Page 27: Memory Installation Procedures
FBDIMM modules and sockets have only one key, which is slightly near the center of the module/socket. Follow these instructions to install memory modules into the Tempest i5000PT (S5383). Press the locking levers in the direction shown in the following illustration. -
Page 28: Attaching Drive Cables
Attaching IDE drive cabling is simple. The cable is “keyed” to only allow it to be connected in the correct manner. Tyan motherboards have one on-board IDE channel, which supports two drives. Attaching IDE cables to the IDE connectors is illustrated below: Simply plug in the BLUE END of the IDE cable into the motherboard IDE connector, and the other end(s) into the drive(s). - Page 29 The Tempest i5000PT is equipped with 6 Serial ATA (SATA) connectors and 8 SAS/SATA connectors. There is no need to set Master/Slave jumpers on SATA/SAS drives. Tyan has supplied four SATA cables, two SATA power adapters and two Standard SAS (actual cables vary dependant on versions purchased).
- Page 30 Usually signifies that the cable on the drive is on backwards, which is a Drive activity light is constantly on common issue. Reverse the cable at the floppy drive end and try again. http://www.TYAN.com...
-
Page 31: Installing Add-In Cards
This allows air to circulate within the chassis more easily, providing improved cooling for all installed devices. YOU MUST ALWAYS unplug the power connector to the motherboard NOTE before performing system hardware changes, to avoid damaging the board or expansion device. http://www.TYAN.com... -
Page 32: Connecting External Devices
LED states. 10/100/1000 Mbps LAN Link/Activity LED Scheme Left LED Right LED Link Green 10 Mbps Active Blinking Green Link Green Green 100 Mbps Active Blinking Green Green Link Green Yellow 1000 Mbps Active Blinking Green Yellow No Link http://www.TYAN.com... -
Page 33: Installing The Power Supply
2.12 – Installing the Power Supply PWR2: 4-pin 12V power connecto (for Memory and MCH) PWR3: 24-pin EPS 12V power connector PWR1: 8-pin 12V power connector (for CPU) There are three power connectors on the Tempest i5000PT (S5383). +3.3V +3.3V +3.3V -12V PS_ON... -
Page 34: Finishing Up
NOTE: The Tempest i5000PT (S5383) peripheral drive power connector must be independent of any other devices. A device such as a DVD/CD-ROM drive, hard drive, or any other devices cannot be attached onto the same power line. If connected, system stability is compromised. -
Page 35: Chapter 3: Bios Setup
Changes settings. 3.1.2 Getting Help Pressing [F1] will display a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press [ESC] or the [F1] key again. http://www.TYAN.com... -
Page 36: In Case Of Problems
Chipset section unless you are absolutely sure of what you are doing. The Chipset defaults have been carefully chosen either by TYAN or your system manufacturer for best performance and reliability. Even a seemingly small change to the Chipset setup options may cause the system to become unstable or unusable. -
Page 37: Bios Main Menu
This displays the date of BIOS build. Legacy Diskette A Defines the floppy drive type NONE / 360K, 5.25 in / 1.2 M, 5.25 in / 720 K, 3.5 in / 1.44 M, 3.5 in / 2.88 M, 3.5 http://www.TYAN.com... - Page 38 System Memory This display allows you to change the amount of system memory present on the system. Extended Memory This displays/allows you to change the amount of extended memory present on the system. http://www.TYAN.com...
-
Page 39: Ide Primary/Master/Slave Setup
Extended CHS or large mode, or it may be done using a different algorithm called LBA-assist translation. The translated geometry is still what is presented to the operating system for use in Int 13h calls. The difference http://www.TYAN.com... - Page 40 Ultra DMA uses Cyclical Redundancy Checking (CRC), offering a new level of data protection. Disabled / Mode 0 / Mode 1 / Mode 2 / Mode 3 / Mode 4 / Mode 5 http://www.TYAN.com...
-
Page 41: Memory Cache
As such, it would be a waste of L2 cache bandwidth to cache the video BIOS instead of data that are more critical to the system's performance. In addition, if any program http://www.TYAN.com... - Page 42 These feature allows you to control caching of D000-D3FF/D400-D7FF/D800-D8FF/DC00-DFFF memory. Disabled / Write Through / Write Protect / Write Back Cache E000-E3FF/Cache E400-E7FF These feature allows you to control caching of C8000-CBFF/CC00-CFFF memory. Disabled / Write Through / Write Protect / Write Back http://www.TYAN.com...
-
Page 43: Boot Features
Spin up the hard disks as soon as power is supplied (or as soon as possible) Initialize only critical parts of the chipset Read memory size from the SPD (Serial Presence Detect) chip on the memory modules Eliminate logo delays http://www.TYAN.com... - Page 44 After a few error-free test runs, you should enable this feature for much faster booting. Enabled / Disabled Extended Memory Testing Determine to the tests that will be run on extended memory (memory above 1MB) during boot up. Normal / Just zero it / None http://www.TYAN.com...
-
Page 45: Bios Advanced Menu
ESCD. So, there is no need for you to manually disable this feature after rebooting. Yes / No Large Disk Access Mode This option determines whether a hard drive with more than 1024 cylinders, more than http://www.TYAN.com... - Page 46 When enabled, the BIOS takes control of the ROM Placement. Enable this if your system hangs during boot. Please restart the system and come here to change the setting. Disabled / E000 Extension by PFA / Temporary Relocation by PFA / E000 Extension by Size / Temporary Relocation by Size http://www.TYAN.com...
-
Page 47: Advanced Chipset Control
256MB / 512MB / 1.0GB / 2.0GB Memory Branch Mode This option is used to select the type of memory operation mode. Interleave / Sequential / Mirror Branch 0 Rank Sparing This option is used to enable/disable Branch 0 rank/DIMM sparing feature. http://www.TYAN.com... - Page 48 This feature is used to select SATA controller mode. In “compatible mode”, SATA and PATA drives are auto-detected and placed in Legacy mode. In “Enhanced (non-AHCI) mode”, SATA and PATA drives are auto-detected and placed in Native IDE mode. Compatible / Enhanced (non-AHCI) http://www.TYAN.com...
-
Page 49: Ich Usb Control Sub-Menu
Enabled / Disabled USB Device 29, F3 only Enable or Disable the USB function by setting item to the desired value. Enabled / Disabled USB Device 29, Function 7: Control USB 2.0 functionality through this Setup Item. Enabled / Disabled http://www.TYAN.com... -
Page 50: Lan Control Sub-Menu
Disabled / Enabled LAN4 (82571) This feature is used to enable/disable the function of integrated LAN4 interface. Disabled / Enabled Option ROM Scan This feature is used to enable/disable the Option ROM of integrated LAN4 interface. Disabled / Enabled http://www.TYAN.com... -
Page 51: Advanced Processor Options
By allowing the processor to use on-die resources that would otherwise have been idle, Hyper-Threading Technology provides a performance boost on multi-threading and multi-tasking operations for the Intel NetBurst® microarchitecture. Enabled / Disabled http://www.TYAN.com... - Page 52 This feature is used to set Max CPUID extended function value to 3. Disabled / Enabled Discrete MTRR Allocation This feature is used to configure the MTRR method. Disabling the feature will set the MTRR method in continuous status. Disabled / Enabled http://www.TYAN.com...
-
Page 53: I/O Device Configuration
This defines how the first serial port is detected and configured. Auto/ Enabled / Disabled Base I/O address: This defines the base I/O address for serial port B. 3F8/ 2F8 / 3E8 / 2E8 Interrupt: This defines the interrupt for serial port B. IRQ3/ IRQ4 http://www.TYAN.com... -
Page 54: Dmi Event Logging
Select Enabled to allow logging of ECC events Enabled/ Disabled Mark DMI events as read Press <Enter> to mark DMI events as read. Clear all DMI event logs Setting this to ‘Yes’ will clear the DMI event log after rebooting. Options: No / Yes http://www.TYAN.com... -
Page 55: Hardware Monitor
Fan1 (CPU0 Fan) Fan2 (CPU1 Fan) Fan3 (SYS_FAN1) Fan4 (SYS_FAN2) Fan5 (SYS_FAN3) Fan6 (SYS_FAN4) CPU0 Temp. CPU1 Temp. Auto Fan Control ↑↓ Help Select Item Change Values Setup Defaults ← → Exit Select Menu Enter Select Sub-Menu Previous Values http://www.TYAN.com... -
Page 56: Voltage Monitoring
Voltage Monitoring Item Specific Help +12V -12V ESB2 VCC FSB VTT +3.3V CPU0 Vcore CPU1 Vcore FBD_AMB0 FBD_DDR0 FBD_AMB1 FBD_DDR1 5VSB ↑↓ Help Select Item Change Values Setup Defaults ← → Exit Select Menu Enter Select Sub-Menu Previous Values http://www.TYAN.com... -
Page 57: Ipmi
Disabled / Enabled SYS Firmware Progress This feature is used to enable/disable the logging of POST progress. Disabled/ Enabled BIOS POST Errors This feature is used to enable/disable the logging of POST errors. Enabled/ Disabled BIOS POST Watchdog http://www.TYAN.com... - Page 58 This feature is used to choose the type of date field to be shown. MM DD YYYY/ DD MM YYYY/ YYYY MM DD Date Separator This feature is used to choose which character to use in date entries. / / . http://www.TYAN.com...
-
Page 59: Console Redirection
This feature is used to indicate whether the console is connected directly to the system or a modem is used to connect. Direct / Via modem Continue C.R. after POST This feature is used to enable console redirection after OS has loaded. Off / On http://www.TYAN.com... - Page 60 #of video pages to support: This is the number of video pages to allocate for Console Redirection when video hardware is not available. IP Address Displays the IP address http://www.TYAN.com...
-
Page 61: Power Menu
This feature is used to enable/disable the function: when chassis open event is detected, BIOS will record the event. No / Yes After Power Failure Specifies the mode of operation after the system recovers from a power loss. Stay off / Last State / Power on http://www.TYAN.com... -
Page 62: Boot Menu
Select Menu Enter Select Sub-Menu Previous Values The boot menu will list all bootable devices. Use <Enter> to expand or collapses devices with a ‘+’ or ‘-‘. Use <+> or <-> to arrange the priorities of all bootable devices. http://www.TYAN.com... -
Page 63: Exit Menu
Exit Discarding Changes This exits BIOS setup after discarding the changes made. Load Setup Defaults Loads the factory default values. Discard Changes Discards all changes made without exiting BIOS setup. Save Changes Saves all changes made without exiting BIOS http://www.TYAN.com... -
Page 64: Chapter 4: Diagnostics
(2) Graphics initialization failed Before contacting your vendor or Tyan Technical Support, be sure that you note as much as you can about the beep code length and order that you experience. Also, be ready with information regarding add-in cards, drives and O/S to speed the support process and come to a quicker solution. -
Page 65: Glossary
4GB of regular memory. Closed and open jumpers: jumpers and jumper pins are active when they are “on” or “closed”, and inactive when they are “off” or “open”. CMOS (Complementary Metal-Oxide Semiconductors): chips that hold the basic startup information for the BIOS. http://www.TYAN.com... - Page 66 EEPROM (Electrically Erasable Programmable ROM): also called Flash BIOS, it is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep up with changes in the BIOS programs without having to buy a new chip. TYAN’s BIOS updates can be found at http://www.tyan.com ESCD (Extended System Configuration Data): a format for storing information about Plug-n-Play devices in the system BIOS.
- Page 67 RAID level 1 also allows for faster access time and fault-tolerance, since either hard drive can be read at the same time. RAID level 0+1 is both striping and mirroring, providing fault-tolerance, striping, and faster access all at the same time. http://www.TYAN.com...
- Page 68 ZIF Socket (Zero Insertion Force socket): these sockets make it possible to insert CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shifts the processor over and down, guiding it into the board and locking it into place. http://www.TYAN.com...
-
Page 69: Technical Support
You may obtain service by calling the manufacturer for a Return Merchandise Authorization (RMA) number. The RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed prepaid. TYAN will pay to have the board shipped back to you... - Page 70 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. Document #: D1814-110 http://www.TYAN.com...
