Tempest i5000PW
S5382
Revision 1.00
Copyright
Copyright © TYAN Computer Corporation, 2006. All rights reserved. No part of this manual
may be reproduced or translated without prior written consent from TYAN Computer Corp.
Trademark
All registered and unregistered trademarks and company names contained in this manual
are property of their respective owners including, but not limited to the following.
TYAN,
are trademarks of TYAN Computer Corporation.
Tempest i5000PW
Intel, Blackford, and combinations thereof are trademarks of Intel Corporation.
PhoenixBIOS are trademarks of Phoenix Technologies.
Microsoft, Windows are trademarks of Microsoft Corporation.
SuSE,is a trademark of SuSE AG.
IBM, PC, AT, and PS/2 are trademarks of IBM Corporation.
Notice
Information contained in this document is furnished by TYAN Computer Corporation and
has been reviewed for accuracy and reliability prior to printing. TYAN assumes no liability
whatsoever, and disclaims any express or implied warranty, relating to sale and/or use of
TYAN products including liability or warranties relating to fitness for a particular purpose or
merchantability. TYAN retains the right to make changes to product descriptions and/or
specifications at any time, without notice. In no event will TYAN be held liable for any direct
or indirect, incidental or consequential damage, loss of use, loss of data or other malady
resulting from errors or inaccuracies of information contained in this document.
1
http://www.TYAN.com
Advertisement
Table of Contents
Related Manuals for TYAN TEMPEST I5000PW
Summary of Contents for TYAN TEMPEST I5000PW
- Page 1 TYAN retains the right to make changes to product descriptions and/or specifications at any time, without notice. In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.
-
Page 2: Table Of Contents
Getting Help…………………………………………………………………….. 3.1.3 In Case of Problems……………………………………………………………. 3.1.4 Setup Variations………………………………………………………………... BIOS Main Menu……………………………………………………………….. 3.2.1 IDE Primary/Master/Slave Setup……………………………………………... 3.2.2 Memory Cache………………………………………………………………….. 3.2.3 Boot Features……………………………………………………………... BIOS Advanced Menu……………….…………………………………... 3.3.1 Advanced Chipset Control…………………………………………………….. 3.3.1.1 ICH USB Control Sub-Menu……………………………………………..3.3.1.2 LAN Control Sub-Menu………………………………………………………… http://www.TYAN.com... - Page 3 3.3.2 Advanced Processor Options…………………………………………………. 3.3.3 I/O Device Configuration………………………………………………………. 3.3.4 DMI Event Logging………………………………………………………..3.3.5 Hardware Monitor………………………………………………………………. 3.3.5.1 Voltage Monitoring ……..……………………………………………………… 3.3.6 IPMI ……..………………………………………………………………………. 3.3.7 Console Redirection……………………………………………………………. Power Menu………………………………………………………………..Boot Menu………………………………………………………………………. Exit Menu………………………………………………………………………... Chapter 4: Diagnostics Beep Codes………………………………………………………………………… Flash Utility………………………………………………………………………….. Glossary http://www.TYAN.com...
-
Page 4: Before You Begin
2 x CPU Heatsink CEK 1 x TYAN Driver CD 1 x Tempest i5000PW User’s Manual 1 x Tempest i5000PW Quick Reference Guide 2 x M5382 (Memory riser card) 2 x Memory Riser Card Bracket (with 4 Press Brackets and 4 screws) - Page 5 2 x Bracket Holder 1 x Backplate 10 x Screws 4 x Hand Screws 4 x Screw Nuts If any of these items are missing, please contact your vendor/dealer for replacement before continuing with the installation process. http://www.TYAN.com...
-
Page 6: Chapter 1: Introduction
Chapter 1: Introduction 1.00 – Congratulations! You are now the owner of one of the most powerful Intel processor solutions, the Tempest i5000PW ® (S5382). The Tempest i5000PW (S5382) is a flexible Intel platform for multiple applications, based ® ®... - Page 7 Six SATA2.0 ports from Intel ESB2 BSMI (Optional) Integrated Host RAID 0, 1, 5 and 10 support (Windows support) Integrated SAS Controller ® 1068E SAS controller with PCI-E x 4 interface Eight SAS/SATA connectors Host RAID 0, 1 and 1E (Mirroring Enhanced) support http://www.TYAN.com...
-
Page 8: Software Specifications
Red Hat Enterprise Linux 4 Advanced Server Update 3 (32bit & EM64T) Novell SuSE Linux Enterprise Server 10 (32bit & EM64T) LSI SAS RAID Driver support, please refer to below web site: http://www.lsilogic.com/cm/LookupDownloads.do?role=1&geo=ALL&category=2059&family=-1#Dri TYAN reserves the right to add support or discontinue support for any OS with or without notice. http://www.TYAN.com... -
Page 9: Chapter 2: Board Installation
Chapter 2: Board Installation Installation You are now ready to install your motherboard. The mounting-hole pattern of the Tempest i5000PW (S5382) matches the E-ATX specification. Before continuing with installation, confirm that your chassis supports an E-ATX motherboard. How to install our products right…. the first time! The first thing you should do is to read this user’s manual because the important information... -
Page 10: Board Image
This picture is representative of the latest board revision available at the time of publishing. The board you receive may or may not look exactly like the picture above. The following page includes details on the vital components of this motherboard. http://www.TYAN.com... -
Page 11: Block Diagram
2.01 – Block Diagram Tempest i5000PW S5382 Block Diagram http://www.TYAN.com... -
Page 12: Board Parts, Jumpers And Connectors
2.02 – Board Parts, Jumpers and Connectors This jumper diagram is representative of the latest board revision available at the time of publishing. The board you receive may not look exactly like the diagram above. http://www.TYAN.com... -
Page 13: Jumper Settings
LAN0 & LAN1 Enable/Disable Jumper See Section 2.17 JP24 Integrated VGA Enable/Disable Jumper See Section 2.18 JP25 Onboard Buzzer Enable/Disable Jumper See Section 2.19 JP31,JP32 LAN0 & LAN1 LED Header See Section 2.20 LPT1 LPT PIN Header (13-Pin x 2) See Section 2.21 http://www.TYAN.com... -
Page 14: Audio Front Panel (J15)
Without jumper cover CLOSED - Jumper ON With jumper cover To indicate the location of pin-1 To indicate the location of pin-1 2.04 – Audio Front Panel Header (J15) Signal Signal Description Description MIC2-L MIC2-R PRESENT# LINE2-R MIC2-JD SENSE LINE2-L LINE2-JD http://www.TYAN.com... -
Page 15: Smdc Con25X2_M3291 (J79)
2.05 – SMDC CON25X2_M3291 (J79) For connection with the Tyan Server Management Daughter Card (SMDC). The SMDC connector is only compatible with the Tyan M3291 (SMDC). 2.06 – IPMB Pin Header (J80) (Optional) Pin_4 : NC Pin_3 : IPMB CLK... -
Page 16: Com Port Pin Header (J88)
2.08 – IEEE 1394a Pin Header (J91, J96) Note: The IEEE 1394a Pin Header is colored black in order to distinguish from the USB Header (5-Pin x 2) Signal Signal Description Description TPA - TPA + TPB + TPB - +12V +12V http://www.TYAN.com... -
Page 17: Front Panel (Jp16)
PWR LED - Reset Button - Button + Reset Button + Button - 3.3VSB INTRUDER# 2.10 – USB Header (5-Pin x 1) (P25) Pin_5: GND Pin_4: GND Pin_3 : DATA + Pin_2 : DATA - Pin_1 Pin_1 : +5VPWR http://www.TYAN.com... -
Page 18: Usb Header (5Pin X 2) (P93)
+5V PWR +5V PWR DATA1 - DATA2 - DATA1+ DATA2 + 2. 12 – FAN Connectors (4-Pin x 1) (P12, P13, P92, P8, P9) Pin_1 Pin_1: Pin_2: Pin_3: Pin_4: + 12V TACH Note: P8, P9 can only support 3-PIN Fan http://www.TYAN.com... -
Page 19: Cd-In (4Pin X 1) (P94)
2.13 – CD-IN (4-Pin x 1) (P94) Pin_4: CD-R Pin_3 : CD-GND Pin_2 : CD-GND Pin_1 Pin_1 : CD-L 2.14 – AUX-IN (4-Pin x 1) (P95) Pin_4: AUX-R Pin_3 : GND Pin_2 : GND Pin_1 Pin_1 : AUX-L http://www.TYAN.com... -
Page 20: Intel High Definition Audio Digital Header (P96)
Power off system and disconnect both power connectors from the motherboard Use jumper cap to close Pin_2 and Pin_3 for several seconds to Clear CMOS Put jumper cap back to Pin_1 and Pin_2 (default setting) Reconnect power & power on system http://www.TYAN.com... -
Page 21: Lan0/Lan1 Disable (Jp7 Jp8)
Pin_1 Pin_3 Close Pin2 and Pin3: LAN0 Disable; LAN1 Disable; PIN1 PIN2 PIN3 Pin_1 LAN1_DISABLE# LAN1_DISABLE# 2.18 – Integrated VGA Enable / Disable Jumper (JP24) Pin_3 Close Pin1 and Pin2: Normal Pin_1 Pin_3 Close Pin2 and Pin3: Disable Pin_1 http://www.TYAN.com... -
Page 22: Onboard Buzzer Disable (Jp25)
2.19 – Onboard Buzzer Enable / Disable Jumper (JP25) PIN3-PIN4: Normal PIN1 PIN2 PIN3 PIN4 VCC5 Buzzer SPKR 2.20 – LAN0 & LAN1 LED Header (JP31, JP32) PIN_1 PIN1 LAN LED + PIN2 LAN LED - http://www.TYAN.com... -
Page 23: Lpt Pin Header (13Pin X 2) (Lpt1)
2.21 – LPT Pin Header (13-Pin x 2) (LTP1) Signal Signal Configuration Configuration STB# AFD# LPD0 ERR# LPD1 INIT# LPD2 SLIN# LPD3 LPD4 LPD5 LPD6 LPD7 ACK# BUSY SLCT http://www.TYAN.com... -
Page 24: Tips On Installing Motherboard In Chassis
If there are any studs missing, you will know right away since the motherboard will not be able to be securely installed. Tempest i5000PW（S5382） Mounting Hole Placement http://www.TYAN.com... - Page 25 Some chassis include plastic studs instead of metal. Although the plastic studs are usable, Tyan recommends using metal studs with screws that will fasten the motherboard more securely in place. Below is a chart detailing what the most common motherboard studs look like and how they should be installed.
-
Page 26: Installing The Processor(S)
2.23 – Installing the Processor Your Tempest i5000PW (S5382) supports Dempsey / Woodcrest / Clovertown dual core processors from Intel. Only Intel processors are certified and supported with this motherboard. Refer to the Tyan website for further details: www.tyan.com Processor Installation The processor should be installed carefully. - Page 27 Lift the metal cover to expose the socket interior and place the socket in as shown. Pin 1 Close the cover and return the locking lever to its locked position. Repeat this entire procedure for the second processor. http://www.TYAN.com...
-
Page 28: Heatsink Installation Procedures
(which should already be attached to the heatsink) to the motherboard. The following diagram illustrates how to connect fans onto the motherboard. After you’re finished installing all the fans you can connect your drives (hard drives, CD-ROM drives, etc.) to your motherboard. http://www.TYAN.com... -
Page 29: Installing The Memory
The following diagram shows the common type of FBDIMM modules you may encounter: AMB Only Heatsink. Full-DIMM Heatsink Spreader (Recommended Solution) Here are a few key points to note before installing memory into your Tempest i5000PW; • Intel processors support 64bit (non-interleaved) or 128bit (interleaved) memory configurations. -
Page 30: Memory Configuration
DIMM 5 Riser DIMM 6 Socket DIMM 7 DIMM 8 DIMM 1 DIMM 2 Fully DIMM 3 Buffered DIMM DIMM 4 Riser DIMM 5 Socket DIMM 6 DIMM 7 DIMM 8 Not all possible combinations are listed in the table. http://www.TYAN.com... -
Page 31: Memory Installation Procedures
YOU MUST ALWAYS unplug the power connector to the NOTE motherboard before performing system hardware changes, to avoid damaging the board or expansion device. http://www.TYAN.com... -
Page 32: Installing The Memory Riser Cards
Note: If you just need one Memory Riser Card, insert it into FBDIMM Riser Socket 1 (please refer to the placement in 2.02). Memory Riser Card Installation Procedure Step 1: Fasten the hand screws and screw nuts to the memory riser card. http://www.TYAN.com... - Page 33 Fasten the Backplate to the Memory Riser Card Bracket with the four screws. Step 5: Fasten the press brackets a and b to the Memory Riser Card Bracket with the four screws. You have finished installing the memory riser card(s). http://www.TYAN.com...
-
Page 34: Attaching Drive Cables
IDE Drives Attaching IDE drive cabling is simple. The cable is “keyed” to only allow it to be connected in the correct manner. Tyan motherboards have one on-board IDE channel, and it supporting two drives. Attaching IDE cables to the IDE connectors is illustrated below: Simply plug in the BLUE END of the IDE cable into the motherboard IDE connector, and the other end(s) into the drive(s). - Page 35 SATA Drives and SAS Drives The Tempest i5000PW is equipped with 6 Serial ATA (SATA) connectors and 8 SAS connectors. There is no need to set Master/Slave jumpers on SATA/SAS drives. Tyan has supplied four SATA cables, two SATA power adapters and two Standard SAS (actual cables vary dependant on versions purchased).
- Page 36 Usually signifies that the cable on the drive is on backwards, which is a Drive activity light is constantly on common issue. Reverse the cable at the floppy drive end and try again. http://www.TYAN.com...
-
Page 37: Installing Add-In Cards
This allows air to circulate within the chassis more easily, providing improved cooling for all installed devices. YOU MUST ALWAYS unplug the power connector to the motherboard NOTE before performing system hardware changes, to avoid damaging the board or expansion device. http://www.TYAN.com... -
Page 38: Connecting External Devices
LED states. 10/100/1000 Mbps LAN Link/Activity LED Scheme Left LED Right LED Link Green 10 Mbps Active Blinking Green Link Green Green 100 Mbps Active Blinking Green Green Link Green Yellow 1000 Mbps Active Blinking Green Yellow No Link http://www.TYAN.com... -
Page 39: Installing The Power Supply
The VGA port, GbE LAN (Gilgal) port and Audio ports are covered with soft metal which can be disassembled easily by hand. 2.32 – Installing the Power Supply PWR1: 24-pin EPS 12V power connector PWR2: 8-pin EPS 12V power connecto (for Memory and MCH) PWR3: 8-pin EPS 12V power connector (for CPU) http://www.TYAN.com... -
Page 40: Finishing Up
There are three power connectors on the Tempest i5000PW S5382. +3.3V +3.3V +3.3V -12V PS_ON PWR1: 24-pin EPS 12V power connector PWR GOOD Reset 5VSB +12V +12V +3.3V +12V +12V +12V +12V PWR2: 8-pin EPS 12V power connecto (for Memory and MCH) -
Page 41: Chapter 3: Bios Setup
Changes settings. 3.1.2 Getting Help Pressing [F1] will display a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window, press [ESC] or the [F1] key again. http://www.TYAN.com... -
Page 42: In Case Of Problems
NOTE: The following pages provide the details of BIOS menu. Please be noticed that the BIOS menu are continually changing due to the BIOS updating. The BIOS menu provided are the most updated ones when this manual is written. Please visit Tyan’s website at http://www.tyan.com for the information of BIOS updating. -
Page 43: Bios Main Menu
SS Seconds System Date: Adjusts the system date. MM Months DD Days YYYY Years BIOS Version This displays the version of BIOS. BIOS Build Date This displays the date of BIOS build. Legacy Diskette A Defines the floppy drive type http://www.TYAN.com... - Page 44 NONE / 360K, 5.25 in / 1.2 M, 5.25 in / 720 K, 3.5 in / 1.44 M, 3.5 in / 2.88 M, 3.5 in System Memory This display allows you to change the amount of system memory present on the system. Extended Memory This displays/allows you to change the amount of extended memory present on the system. http://www.TYAN.com...
-
Page 45: Ide Primary/Master/Slave Setup
Auto / CD/DVD / Not Installed / ARMD Multi-Sector Transfers This option allows you to specify the number of sectors per block for multiple sector transfers. 16 Sectors / 2 Sectors / 4 Sectors / 8 Sectors /Disabled LBA Mode Control Enables or disables LBA Mode. http://www.TYAN.com... - Page 46 Ultra DMA uses Cyclical Redundancy Checking (CRC), offering a new level of data protection. Disabled / Mode 0 / Mode 1 / Mode 2 / Mode 3 / Mode 4 / Mode 5 http://www.TYAN.com...
-
Page 47: Memory Cache
This feature is only valid when the video BIOS is shadowed. It enables or disables the caching of the video BIOS ROM at C0000h-C7FFFh via the L2 cache. This greatly speeds up accesses to the video BIOS. However, this does http://www.TYAN.com... - Page 48 These feature allows you to control caching of D000-D3FF/D400-D7FF/D800-D8FF/DC00-DFFF memory. Disabled / Write Through / Write Protect / Write Back Cache E000-E3FF/Cache E400-E7FF These feature allows you to control caching of C8000-CBFF/CC00-CFFF memory. Disabled / Write Through / Write Protect / Write Back http://www.TYAN.com...
-
Page 49: Boot Features
In addition, it will also perform the following to further speed up the booting process: Spin up the hard disks as soon as power is supplied (or as soon as possible) Initialize only critical parts of the chipset http://www.TYAN.com... - Page 50 After a few error-free test runs, you should enable this feature for much faster booting. Enabled / Disabled Extended Memory Testing Determines the tests that will be run on extended memory (memory above 1MB) during boot up. Normal / Just zero it / None http://www.TYAN.com...
-
Page 51: Bios Advanced Menu
However, sometimes, the BIOS may not be able to detect the hardware changes. A serious resource conflict may occur and the operating system may not even boot as a result. This is where the Reset Configuration Data BIOS feature comes http://www.TYAN.com... - Page 52 When enabled, the BIOS takes control of the ROM Placement. Enable this if your system hangs during boot. Please restart the system and come here ot change the setting. Disabled / E000 Extension by PFA / Temporary Relocation by PFA / E000 Extension by Size / Temporary Relocation by Size http://www.TYAN.com...
-
Page 53: Advanced Chipset Control
This feature is used to select the granularity of PCI hole for PCI resource. If MTRRs are not enough, we may use this option to reduce the MTRR occupation. 256MB / 512MB / 1.0GB / 2.0GB Memory Branch Mode This option is used to select the type of memory operation mode. http://www.TYAN.com... - Page 54 This feature is used to select SATA controller mode. In “compatible mode”, SATA and PATA drives are auto-detected and placed in Legacy mode. In “Enhanced (non-AHCI) mode”, SATA and PATA drives are auto-detected and placed in Native IDE mode. Compatible / Enhanced (non-AHCI) http://www.TYAN.com...
-
Page 55: Ich Usb Control Sub-Menu
Enabled / Disabled USB Device 29, F3 only Enable or Disable the USB function by setting item to the desired value. Enabled / Disabled USB Device 29, Function 7: Control USB 2.0 functionality through this Setup Item. Enabled / Disabled http://www.TYAN.com... -
Page 56: Lan Control Sub-Menu
Disabled / Enabled LAN2 (Gilgal) This feature is used to enable/disable the function of integrated LAN2 interface. Disabled / Enabled Option ROM Scan This feature is used to enable/disable the Option ROM of integrated LAN2 interface. Disabled / Enabled http://www.TYAN.com... -
Page 57: Advanced Processor Options
NetBurst® microarchitecture. Enabled / Disabled Intel® Virtualization Technology This feature is used to enable Virtualization Technology. Enabled / Disabled C1 Enhanced Mode This feature is used to enable the C1 Enhanced mode. Enabled / Disabled No Execute Mode Mem Protection http://www.TYAN.com... - Page 58 This feature is used to set Max CPUID extended function value to 3. Disabled / Enabled Discrete MTRR Allocation This feature is used to configure the MTRR method. Disabling the feature will set the MTRR method in continuous status. Disabled / Enabled http://www.TYAN.com...
-
Page 59: I/O Device Configuration
This defines how the first serial port is detected and configured. Auto/ Enabled / Disabled Base I/O address: This defines the base I/O address for serial port B. 3F8/ 2F8 / 3E8 / 2E8 Interrupt: This defines the interrupt for serial port B. http://www.TYAN.com... - Page 60 IRQ3/ IRQ4 Parallel port: This defines how the parallel port is detected and configured. Disabled / Enabled http://www.TYAN.com...
-
Page 61: Dmi Event Logging
Select Enabled to allow logging of ECC events Enabled/ Disabled Mark DMI events as read Press <Enter> to mark DMI events as read. Clear all DMI event logs Setting this to ‘Yes’ will clear the DMI event log after rebooting. Options: No / Yes http://www.TYAN.com... -
Page 62: Hardware Monitor
Main Advanced Power Boot Exit Hardware Monitor Item Specific Help Fan Speed Control [Full Speed] CPU Temp Reading [Diode] Realtime Sensors ↑↓ Help Select Item Change Values Setup Defaults ← → Exit Select Menu Enter Select Sub-Menu Previous Values http://www.TYAN.com... -
Page 63: Voltage Monitoring
Rear Fan (Fan3) Front Fan (Fan2) PCI Area Fan (Fan4) CPU0 VCore Voltage CPU1 VCore Voltage VCC5V VCC3.3V WB-12V VCC12V Battery ↑↓ Help Select Item Change Values Setup Defaults ← → Exit Select Menu Enter Select Sub-Menu Previous Values http://www.TYAN.com... -
Page 64: Ipmi
Disabled / Enabled SYS Firmware Progress This feature is used to enable/disable the logging of POST progress. Disabled/ Enabled BIOS POST Errors This feature is used to enable/disable the logging of POST errors. Enabled/ Disabled http://www.TYAN.com... - Page 65 This feature is used to choose the type of date field to be shown. MM DD YYYY/ DD MM YYYY/ YYYY MM DD Date Separator This feature is used to choose which character to use in date entries. / / . http://www.TYAN.com...
-
Page 66: Console Redirection
This feature is used to indicate whether the console is connected directly to the system or a modem is used to connect. Direct / Via modem Continue C.R. after POST This feature is used to enable console redirection after OS has loaded. Off / On http://www.TYAN.com... - Page 67 #of video pages to support: This is the number of video pages to allocate for Console Redirection when video hardware is not available. IP Address Displays the IP address http://www.TYAN.com...
-
Page 68: Power Menu
This feature is used to enable/disable the function: when chassis open event is detected, BIOS will record the event. No / Yes After Power Failure Specifies the mode of operation after the system recovers from a power loss. Stay off / Last State / Power on http://www.TYAN.com... -
Page 69: Boot Menu
Select Menu Enter Select Sub-Menu Previous Values The boot menu will list all bootable devices. Use <Enter> to expand or collapses devices with a ‘+’ or ‘-‘. Use <+> or <-> to arrange the priorities of all bootable devices. http://www.TYAN.com... -
Page 70: Exit Menu
Exit Discarding Changes This exits BIOS setup after discarding the changes made. Load Setup Defaults Loads the factory default values. Discard Changes Discards all changes made without exiting BIOS setup. Save Changes Saves all changes made without exiting BIOS http://www.TYAN.com... -
Page 71: Chapter 4: Diagnostics
(2) Graphics initialization failed Before contacting your vendor or Tyan Technical Support, be sure that you note as much as you can about the beep code length and order that you experience. Also, be ready with information regarding add-in cards, drives and O/S to speed the support process and come to a quicker solution. -
Page 72: Glossary
4GB of regular memory. Closed and open jumpers: jumpers and jumper pins are active when they are “on” or “closed”, and inactive when they are “off” or “open”. CMOS (Complementary Metal-Oxide Semiconductors): chips that hold the basic startup information for the BIOS. http://www.TYAN.com... - Page 73 EEPROM (Electrically Erasable Programmable ROM): also called Flash BIOS, it is a ROM chip which can, unlike normal ROM, be updated. This allows you to keep up with changes in the BIOS programs without having to buy a new chip. TYAN’s BIOS updates can be found at http://www.tyan.com ESCD (Extended System Configuration Data): a format for storing information about Plug-n-Play devices in the system BIOS.
- Page 74 RAID level 1 also allows for faster access time and fault-tolerance, since either hard drive can be read at the same time. RAID level 0+1 is both striping and mirroring, providing fault-tolerance, striping, and faster access all at the same time. http://www.TYAN.com...
- Page 75 ZIF Socket (Zero Insertion Force socket): these sockets make it possible to insert CPUs without damaging the sensitive CPU pins. The CPU is lightly placed in an open ZIF socket, and a lever is pulled down. This shifts the processor over and down, guiding it into the board and locking it into place. http://www.TYAN.com...
-
Page 76: Technical Support
Tyan also ranks high for its commitment to fast and friendly customer support through email. By offering plenty of options for users, Tyan serves multiple market segments with the industry's most competitive services to support them. - Page 77 Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by manufacturer. Dispose of used battery according to manufacturer instructions and in accordance with your local regulations. Document #: D1791-100 http://www.TYAN.com...
